CHECK THE RELATIVE
CIRCUIT OF BLANKING
OK
CHECK R821 ON VIDEO PCB,
CHECK G1 RELATIVE CIRCUIT
FBT PIN 5 ON MAIN PCB
6-4-1. NO RASTER (DISCONNECT WITH SIGNAL CABLE)
CHECK IC101 PIN 16 ABOUT 5 VDC
CHECK IC101 PIN20 WAVE FORM
ABOUT 3Vpp
CHECK THE COLLECTOR VOLTAGE
OF Q402 ABOUT 14Vpp
CHECK THE COLLECTOR VOLTAGE
OF Q403 ABOUT 1200Vpp AT FH:31KHz
ViewSonic Corporation
6-3 NO BLANKING
NG
6-4 HOR./OSC/DEF/HV CIRCUIT FAULT
NG
OK
NG
OK
NG
OK
NG
20
CHECK THE RELATIVE CIRCUIT
OF FBT
CHECK IC101 PIN 5 RELATIVE CIRCUIT
CHECK IC101 PIN20
RELATIVE CIRCUIT
CHECK Q402, T401
RELATIVE CIRCUIT
CHECK T401, T402, Q402, Q403,
D408, C418, C419, H-DY, B+
