Contact your dealer should you desire an isolator for your protection.
Two types are available, mechanical type, or solid state which is the
best and most expensive.
#1 – Black/Ground (8 Gauge)
#2 – Blue/Brakes
#3 – Green/Running
#4 – Red/Positive (8 Gauge)
#5 – Red/Left Turn
CONVERTER
#6 – Brown/Right Turn
#7 – Yellow/Back Up
A
D
#2
#1
#6 #5
#7
#4 #3
Exterior Lights and Connector, 12 Volt
Power for exterior lights, such as tail lights, turn, clearance and
brake lights, is supplied by the tow vehicle.
Note the diagram (above) showing the color code and numbers from
the seven way connector and how power is fed to the exterior lights.
The positive red wire is attached to the battery to transfer power to
the coach.
The connector between the recreational vehicle and the tow vehicle
may build up corrosion due to moisture. You may need to clean
these terminals occasionally to insure good electrical contact.

Porch Lights

Porch lights are placed on sidewalls, left and right side. Switches for
these lights, depending on models, will be in the interior, right ( door
side ) side wall. Occasionally, the switch will be on the light itself.

Brake Wiring

The 10 inch electric brakes operate on 12-volt power supplied from
the tow vehicle, transferred through the blue-positive and white-
negative in the seven way harness. There are no fuses or breakers
installed in this brake wiring. More information on the brake system
is found in Chapter Three - Using Your RV.
www.pdffactory.com
(-)
C
(+)
B
E
+
-
AUXILIARY
BATTERY
70
A – Breakaway Switch
B – 30 Amp Breaker
C – Fuse Panel
D – Brakes
E – Junction Box
