- Page 2 Aviation Restrictions Please refer to relevant regulations of the International Civil Aviation Organization, local airspace control and UAV management rules. Other- wise it may incur liabilities for violation of laws or regulations. Once this product is used, it will be assumed that the user has acknowledged and accepted all the contents of this statement.
-
Page 3: Table Of Contents
Contents Reminder Reading Instructions Symbols Suggested Use Video GHOST Basic Introduction Parts List Preparation 06-22 Battery G-Box GHOST Propeller Prop guard Gimbal Landing Gears Camera GHOST APP Voice Package GHOST APP 23-26 The interface Flight 27-28 Pre-flight Examination Flight Environment Flight Safety Caution during Flight After-sales... -
Page 4: Reminder
Reminder Black Box Each GHOST drone contains a black box which records all flight information and working parameters of the engine, which is used for flying tests and accidence analysis. Operation Please be careful when using the GHOST. The product contains sensitive electronic components. -
Page 5: Reading Instructions
Symbols Do not operate Attention needed Tips Suggested Use EHANG has a video and the following instructions teaching users how to operate GHOST in order to make sure that you have a pleasant experience with our product. 1.Video Website: www.ghost-drone.com 2.Disclaimer... -
Page 6: Introduction
GHOST Aerial Plus Introduction GHOST is a quadcopter completely controlled by a smartphone APP. It is equipped with an advanced flight controller and the intelligent mobile device can provide functions of flight directing, BVR flight and following. It is easy to operate. -
Page 7: Preparation
It is a charge-discharge, lithium polymer battery specially designed for GHOST products, with a capacity of 5400mAh, cell voltage of 11.1v and an XT60 connector. The battery must be charged with the original charger provided by EHANG. Battery Charger 1.2 Charging... - Page 8 Preparation 1.3 Put in the Battery Put GHOST on level ground and connect it to battery cable. When the flicker frequency is lowered (5 seconds per flicker), push the battery into the com- partment in the right direction and make sure the battery is tightly stuck. Close the cover and keep a safe distance (5 meters).
-
Page 9: G-Box
Preparation 2 .G-Box 2.1 About G-Box G-Box is a communication device specially designed for GHOST products. Each GHOST is equipped with one G-Box; Without G-Box, you cannot use GHOST APP on your smartphone to control the GHOST; please keep the G-Box in good condition. Charging cable port Data indicator On/off G-BOX... -
Page 10: Ghost
Preparation 3.GHOST 3.1 About the GHOST GHOST (without Gimbal and camera) has a built-in GHOST flight controller and can move forwards, backwards, left, right, up and down, rotate or fly to a certain point or make other movements controlled by a smartphone APP. It can be easily controlled and is highly stable. - Page 11 4.1 About the Propellers Pictures of the propellers and the supporting tools (Notice: grey part indicates the back sides of GHOST and parts) Cushion × 4 Screw- GHOST drone Right propeller × 2 Nut × 4 driver Left propeller × 2 4.2 Install Propellers...
- Page 12 2)Please check whether blades are intact; replace with new ones if there is damage or aging; 3)Keep away from rotating blades and running motor in case of injury; 4)Please use original 3-blade, co-rotating and counter-rotating propellers provided by EHANG to achieve optimal flight experience.
-
Page 13: Prop Guard
6.1 Gimbal Parameters Weight: 178g Precision: ±0.09° Working voltage: 7V to 17V Maximum angle: Roll angle ±55° Pitch angle -180° to +60° Balance angle: Roll angle ±45° Pitch angle -90° to +30° Supporting cameras: EHANG motion camera, Gopro3, Gopro3+ and Gopro4... - Page 14 Preparation 6.2 Installation Step 1 Assemble the camera: Use 1.5 long screws to fasten the camera brace to the camera and 1.5 short screws to connect the camera (such as GoPro) to the lower seat of Gimbal. (Notice: Parts must be fastened with screwdriver).
- Page 15 Preparation Step 3 Connect the upper/lower seat: Connect the upper and lower seat with buffer balls. Finished Step 4 Wiring (very important): Pay attention to the colors of cable ends and make sure each one is connected to the right color or there may be damage to the Gimbal.
-
Page 16: Landing Gears
Preparation 7.L a n d in g Gear Assembly: Assemble the landing gear; pay attention to the direction in which the cross-bar is installed; the finished landing gear is as follows: Base Cross-bar Head Assembly Seen from the bottom Seen from the front side... -
Page 17: Camera
Preparation 8.EH A N G Moti on C a mer a 8.1 Features Filming Ultra-HD screen to play and replay your videos Dismountable battery to extend its service life Filming while being charged Filming while being plugged in 12 Megapixel HD wide-angle lens HDMI HD output Web camera Memory card support maximum of 32G... - Page 18 Preparation 8.3 How to Use the Camera 1)Insert Micro SD card 5)Mode swapping After turning it on, tap the ON/OFF button Notice: Please use qualified Micro SD to film/ take a picture/ replay or convert card; format it on computer into modes.
- Page 19 Preparation 8.4 Camera parameters Items Parameters Operating Windows XP/VistaorAbove/win7/Mac os 59.27*41.13*29.28 system 1.5LTPS Lens 170° A+ high-resolution wide-angle lens Language Simplified Chinese/ Traditional Chinese/ English/ German/ French/ Spanish/ Italian/ Portuguese/ Russian/ Japanese 1080P (1920*1080) 30FPS 720P (1280*720) 60FPS Filming VGA (848*480) 60FPS QVGA (640*480) 60FPS Filming format Compressed H.264...
-
Page 20: Ghost App
You must use GHOST APP to use GHOSTAerial/ Aerial Plus. You can down- load the application in the following manners: 01: Visit www.ghost-drone.com to download EHANG GHOST APP (Pic 1). 02: Download GHOST APP from Google Play/ APP Store (Pic 2). - Page 21 The voice notice warns about “Battery Level”, “Low battery. Please return” and “Error” in case communication is lost or the GHOST crashes due to low battery or operation error. EHANG should not be held accountable for acci- dents that could have been avoided by following the voice notice.
- Page 22 Preparation 9.4 APP-Bluetooth Step3 : When new Bluetooth Step1 : Tap the Initial button on top device is detected, tap to get left corner to turn to setup page. connected. Step2 : Connected Bluetooth devic- Step4 : New Bluetooth device is es will be shown on this page.
- Page 23 Preparation Step6 : Type in the new name Step7 : Bluetooth device is and tap “MODIFY”. renamed. 9.5 Remove Bluetooth Pairing Step1 : Tap “INITIAL” button on Step2 : Tap“ ” button on the top left corner to turn to right to turn to Bluetooth Bluetooth setup page.
- Page 24 Preparation 9.6 Model After APP installation and Bluetooth pairing is completed, turn to the page on the left. GHOST setting page will pop up If you choose correctly, you will see “GHOST parameters set ”; it turns to APP operation page; if you need to reset, tap “ ”button on top left corner and choose GHOST settings(if with a certain model recommended, you must proceed based on the GHOST actually used).
-
Page 26: Ghost App
GHOST APP Function 1 . U n l o ck Unlocked, ready to fly Unlock Propellers spin at low speed Voice notice Tap “TAKEOFF” to fly GHOST GHOST will beep if flight command is not received in three minutes and thirty seconds. - Page 27 GHOST APP Function 4 .Fo l l o w Tap “FOLLOW” to keep GHOST following you wherever you go and recording every amazing moment! GPS on smartphone is required to activate this feature. Available only in HOVERING status. At minimum 3m (up to smartphone GPS accuracy) horizontal distance from the user (smartphone and G-Box), GHOST begins to follow the user automatically.
- Page 28 GHOST APP Functions and How to Use GHOST APP 6.A sce nd /De s c en d/ Rotating GHOST ascends Pull upward Ascend/ descend Pull downward GHOST descends Pull Pull Rotate Rotating Rotate rightward leftward clockwise anti-clockwise Height control is only accessible in hovering status. During flight, the height control bar is hidden on right side of the APP interface.
-
Page 29: Flight
2.2 Check whether propellers are installed correctly. 2.3 Check whether motor starts normally after unlocking. Please contact EHANG dealers or customer service in case of any trouble during installation or use. 3 . F l i g h t S a fety 3.1 Make sure that there is a minimal of 5m distance between you and... -
Page 30: Caution During Flight
5.A ft er- s al e s 5.1 GHOST products are guaranteed by after-sales service (please see details on after-sales card). 5.2 Visit our website: www.ghost-drone.com to learn more about APP updates, newsletters, product development progress and after-sales service. EHANG will be at your service. - Page 31 : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
