MIN/MAX Record/Recall Mode

The Record/Recall function tracks the maximum and minimum readings for recall at any

time.

1. Press the RECORD/RECALL button once. The REC indicator will appear on the

display.

2. Press the RECORD/RECALL button again to view the highest (MAX) reading taken

since the RECORD/RECALL button was first pressed. The MAX indicator and

maximum reading will appear on the display.

3. Press the RECORD/RECALL button again, the MIN indicator and the minimum value

will appear on the display.

4. To return to normal operation, press and hold the RECORD/RECALL button until the

display indicators REC, MAX, and MIN disappear.

The meter has a built-in RS-232 serial port for use with the optional PC Interface Data

Acquisition Software/Hardware kit Model 407001.

Model 407910 - Version 2.0 - March 2005
