Sensor
Wire
Control
Maximum
ceiling 74"
spacing
72-0106 02-26-16
INSTALLATION AND OPERATING INSTRUCTIONS
DIAGRAM 3
Sensor protective cover. Locate bottom of
sensor 5" from ceiling and directly above
of heater.
Heater Input
15' Low Voltage Cable provided with control.
DIAGRAM 5
Back of
sensor
Insert screwdriver tip here to unsnap
sensor cover from sensor.
Note vertical orientation of cover
before removing.
Diagram 4 was intentionally left blank.
Light Input
Light Output Power
DIAGRAM 4
DIAGRAM 5, continued
7013482 314 SKSM 215 B
Page 4
5" from ceiling to
top of sensor and
centered above
the heater.
