Getting to know your machine

Battery level indicator
Dirt container lid
Dirt container
Dirt container release button
Handheld release button
Reach wand
Powered Head/
accessory release clip
Powered Head
Brushbar
Powerhead Specification Battery Specification
Model no. FT3V1B1 Type Lithium-ion rechargeable battery pack
Wattage 48W Battery model no. 32BTBT3V1
Voltage 28.8V Voltage 28.8V
Powerhead to be used ONLY Rating 2.0Ah 57.6Wh
with Vax VX63
Use with E-TEK model ZD24W342060
Charger ONLY
Subject to technical change without notice.
Turn off brushbar on hard floors. Images are illustrative only.
On/Off button
Handle
Battery level gauge
Battery level indicator
Boost mode on/off button
Brushbar on/off button
Charging port

Technical Specification

Model Number VX63
Name Vax Cordless Blade Pet Pro
Battery voltage 28.8V
Run time Up to 45 minutes*
Charge time 4 hours
Weight 3.0 kg
Dust bin capacity 0.3L
Charger Specification
Charger model no. ZD24W342060
Input 100-240V ~ 50/60Hz 0.8A Max
Output 34.2V 600mA
Use with Li-ion Battery 32BTBT3V1 ONLY
Accessories & Consumables
Filter pack Model No. VX63F
To purchase consumables and accessories, please visit
*Brushbar and Boost off
PLEASE READ 'LET'S TALK SAFETY' AT THE BEGINNING BEFORE USE
Filter cap

Before you begin

CAUTION: Always switch off the vacuum cleaner before connecting or disconnecting the handheld/attachments
or removing and emptying the dirt container.
For best cleaning results, filters require cleaning at least every 3 months and should be replaced every 12 months
depending upon use.
Lithium-Ion battery safety features
• Over charge protection
• Short circuit protection
• Deep discharge protection

Assembling your upright slim vacuum cleaner

CAUTION: This vacuum cleaner is not free standing. In between uses or when carrying out any maintenance
always lie flat on the floor in a suitable location so it does not become a trip hazard or can be stepped on.
Line up the connector on
the reach wand with the
Powered Head. Push the
reach wand down onto
the Powered Head until it
clicks into place.
vax.com.au

Getting started

• Over load protection
• High/low temp protection
Push the handheld down The vacuum is not free
onto the reach wand until standing and in between
it clicks into place. uses must always be placed
in the wall bracket, or laid
flat on the floor in a suitable
location, so it does not
become a trip hazard or
can be stepped on.
