"Telecommunication Products to solve Telecommunication Problems"
CK-1P4
Promotion-On-Hold Module
(For Panasonic
KX-TG6700B and KX-TG6702B)
Introduction
CK1P4
Power Cube
Thank you for purchasing the
Sensor Board
Skutch CK-1P4 Promotion-On-
Hold Module. The CK-1P4 is a
true plug and play device. The unit
Black Box
does not require any "Learning" to
operate. When a call is placed ON
HOLD from the base set, or any one
of the cordless phones, the caller
will hear the Promotion-On-Hold
audio. When the line is re-
answered, the audio automatically
stops. It's that simple!
NOTE: You can NOT use the
Audio Cord (For CD Player ONLY!)
Sensor Cable
"Transfer to Answering System"
with this module. This is ONLY
Short Mod Cord
when you transfer a call to the
answering device, AFTER you have already answered and talked to the person! When a
call is answered by the answering device, the Answering System works perfectly.
Installation
Fig. 1
LINE 2
LINE 1 /2
1- Position the CK-1P4 black box under
the base telephone with the jacks facing
towards the back of the phone. (See Fig.
1).
To Audio Source
Connect to Wall Jack
Page 1 of 4
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SKUTCH CK-1P4
Summary of Contents for SKUTCH CK-1P4
- Page 1 Answering System works perfectly. Installation Fig. 1 LINE 2 LINE 1 /2 1- Position the CK-1P4 black box under the base telephone with the jacks facing towards the back of the phone. (See Fig. To Audio Source Connect to Wall Jack...
- Page 2 Sensor Board as shown in Fig. 7- Connect the POWER CUBE from the CK-1 Black Box to 115VAC power. That's it! Testing the System: 1- Pickup line 1 on your telephone. The No."1" LED on the CK-1P4 Sensor Board should Page 2 of 4...
- Page 3 • ONE YEAR LIMITED WARRANTY This SKUTCH PRODUCT is warranted against defects for a period of one (1) year from the date of the original invoice. Within this period, we will repair it without charge for parts and labor. To obtain warranty service the product must be returned, at the customer's expense, to SKUTCH Electronics along with a copy of the original invoice.
- Page 4 ACTA Statement This equipment complies with Part 68 of FCC rules and the requirements adopted by ACTA. On the bottom side of this equipment is a label that contains, among other information, a product identifier in the format US: AAAEQ##TXXXX. If requested, this number must be provided to the telephone company.
