Gronomics VG 32-45UA Assembly Instruction Manual

1
Parts Identifi cation
Stack matching pieces in piles. Using the parts
list, locate and count the individual pieces and
verify that you have received the correct number
of pieces.
If any pieces are missing or replacement parts
are required, contact Gronomics at
1-855-299-6727.
NOTE: Ground preparation is optional, however
we recommend leveling area under frame of
product, or place product directly on a flat level
surace before filling with soil.
Product care and Maintenace
Cedar will turn a weathered grey if left unfinished. Although no
finish is required for cedar when used outdoors, a natural oil
finish applied regularly will help maintain the beauty and
minimize cracking and drying. It is recommended to use
Gronomics Garden Bed Oil (Item # GBO-1Q), a
non-toxic, food safe finish that is very easy to apply. Apply
Oil when air and wind temperatures are between
50-90degrees. Avoid applying in direct sunlight.
ITEM QTY.
1 1
2 1
3 7
4 7
5 1
6 1
7 1
8 2
9 4
10 1
11 1
12 1
13 1
14 5
Packaged & Inspected by:
www.gronomics.com
Western Red
PART # DESCRIPTION
4550SRB Side Panel (Right Hand) 45-1/2" x 8-7/16" x 1-1/4"
4550SLB Side Panel (Left Hand) 45-1/2" x 8-7/16" x 1-1/4"
3054BKB Back Boards 30" x 5.41" x 5/8"
3050AFB Angled Front Shelf Boards 30" x 5" X 5/8"
2925BMB Bottom Board 29-1/4" x 5.41" x 1" (w/ 4 Pre-Drlled Holes)
V1204 Top Back Board (w/ 2 Pre-Drilled Holes) 30" x 5-1/4" x 5/8"
V1205 Angled Front Shelf Board (w/ Logo) 30" x 5" x 5/8"
RSS10-234ZY
Screw, RSS GRK 10 x 2-3/4"
RSS10-112ZY Screw, RSS GRK 10 x 1-1/2"
YFL Fabric Liner 36" x 10-1/4"
GBDIK Garden Bed Drip Irrigation Kit (Contains Items 12 - 14)
N/A Irrigation Tubing 16'
N/A Hose Connector
SCEY6Z Eyelet Screws
Vertical Garden Bed
Assembly Instruction
3
2
1
Parts List
East Bethel, MN USA
Torx® T25 Torx® T15
4
5
7
6
12 12
Date:
32" x 45"
Item #: VG 32-45UA
9
8
10 10
11 11
13 13
14 14
Continued
763-753-7374
