1
Parts Identifi cation Box 1
Stack matching pieces in piles.
Using the parts list, locate and
count the individual pieces and
verify that you have received the
correct number of pieces.
If any pieces are missing or
replacement parts are required,
contact Gronomics at 1-855-299-
6727.
NOTE: Ground preparation is
optional, however we recommend
leveling area under frame of
product, or place product directly
on a flat level surface before
filling with soil.
ITEM
QTY.
1
1
2
1
3
6
4
1
5
1
6
2
7
4
8
2
9
4
10
2
11
4
12
8
13
2
Packaged & Inspected by:
www.gronomics.com
2
1
Parts List Box 1 of 2
PART #
7003-Lt
Three Sided Dovetail Corner Post (Left) 4" x 4" x 36"
7003-Rt
Three Sided Dovetail Corner Post (Right) 4" x 4" x 36" Post w/13"
7009
Dovetail Depth 4" x 4" x 30"
7004-Rt
Side Rail w/Double Cleat (Right) 21" x 5-1/2" x 1"
7004-Lt
Side Rail w/Double Cleat (Left) 21" x 5-1/2" x 1"
2102
Side Rail w/Cleat 21" x 5-1/2" x 1"
2100
Side Rail 21" x 5-1/2" x 1"
1450
Side Rail 14-1/2" x 5-1/2" x 1"
1451
Narrow Center Side Rail 14-1/2" x 2-1/2" x 1"
1538NR
Corner Notched Ripped Bottom Board 15-3/8" x 4-1/2" x 1"
1538
Bottom Board 15-3/8" x 5-1/2" x 1"
4545
Post Cap 4-5/8" x 4-5/8" x 1-1/2"
FL3622
Fabric Liner 36" x 22"
Planter Bench
Assembly Instruction
3
4
5
6
DESCRIPTION
East Bethel, MN USA
7
9
8
11
11
10
10
Date:
Item #: EPB 24-82
Item #: EPB 24-82S
12
12
13
13
Continued
763-753-7374
Advertisement
Related Manuals for Gronomics EPB 24-82
Summary of Contents for Gronomics EPB 24-82
- Page 1 Planter Bench Assembly Instruction Item #: EPB 24-82 Parts Identifi cation Box 1 Item #: EPB 24-82S Stack matching pieces in piles. Using the parts list, locate and count the individual pieces and verify that you have received the correct number of pieces.
- Page 2 Western Red Cedar will turn a weathered grey if left unfinished. Although no finish is required for cedar products when used outdoors, a natural oil finish applied regularly will help maintain the beauty and minimize cracking and drying. It is recommended to use Gronomics Garden Bed Oil , a non-toxic, food safe finish that (Item # GBO-1Q) is very easy to apply.
- Page 3 Locate the 45” x 5-1/2” side rail w/Logo (Item 16). Install the side rail (Logo facing down) into the slots and slide to the bottom of the slots. Continued www.gronomics.com East Bethel, MN USA 763-753-7374...
- Page 4 Install the 21” x 5-1/2” side rail w/double cleat (right) (Item 4) (cleats located at the bottom) into the slots on the posts and slide down to the bottom of the slots. Long Cleat Located (as shown) Continued www.gronomics.com East Bethel, MN USA 763-753-7374...
- Page 5 Install the 14-1/2” x 5-1/2” side rail (Item 8) into the slots on the posts and slide down to the bottom of the slots. Continued www.gronomics.com East Bethel, MN USA 763-753-7374...
- Page 6 Install the 14-1/2” x 5-1/2” side rails (Item 8) into the slots on the posts and slide down. Install the 21” x 5-1/2” side rails (Item 7) into the slots on the posts and slide down. Continued www.gronomics.com East Bethel, MN USA 763-753-7374...
- Page 7 Repeat steps 7 - 12 for planter box on opposite end of planter bench backrest. Locate the two pieces of fabric liner. Place one piece in the bottom of each planter box. Soil Capacity: 4.1 Cubic Feet Continued www.gronomics.com East Bethel, MN USA 763-753-7374...
- Page 8 Align the hole of the 4” x 4” post cap (Item 12) with stud and tighten until the cap makes contact with the post. NOTE: Do not overtighten. Stud Repeat procedure for all posts. www.gronomics.com East Bethel, MN USA 763-753-7374...
