Parts Identifi cation Box 1
Remove contents from Box 1 of 3.
Stack matching pieces in piles. Using the
parts list, locate and count the individual
pieces and verify that you have received
the correct number of pieces.
If any pieces are missing or replacement
parts are required, contact Gronomics at
1-855-299-6727.
NOTE: Ground preparation is optional,
however we recommend leveling area
under frame of product, or place product
directly on a flat level surface before
filling with soil.
Torx® T25
Torx® T15
14
14
15
15
16
16
ITEM
QTY.
1
2
2
4
3
4
4
4
5
8
6
8
7
4
8
4
9
4
10
2
11
4
12
2
13
2
14
12
15
20
16
8
17
12
Packaged & Inspected by:
www.gronomics.com
1
2
Torx® T30
17
17
PART #
FL2236
Fabric Liner, 22" x 36"
3100
Post Cap, 4" x 4" x 1-1/2"
1451
Narrow Center Side Rail, 14-1/2" x 2-1/2" x 1"
1551
Corner Notched Bottom Board, 15-1/2" x 4-1/2" x 1"
1450
Side Rail, 14-1/2" x 5-1/2" x 1"
1550
Bottom Board, 15-1/2" x 5-1/2" x 1"
3103
Narrow Center Side Rail, 31" x 2-1/2" x 1"
3102
Side Rail w/Cleat, 31" x 5-1/2" x 1"
3101
Side Rail, 31" x 5-1/2" x 1"
3101L
Side Rail w/Logo, 31" x 5-1/2" x 1"
3201
Corner Post, 4" x 4" x 32"
7022
Support Plate
7021
Pentagon Cap
CS8-112ZY
8 x 1-1/2" GRK Screw (Trellis)
RSS516-234ZY RSS 5/16 x 2-3/4" GRK Screw (Support Plate)
RSS516-234ZY RSS 5/16 x 2-3/4" GRK Screw (Posts)
R410-4ZY
R4 10 x 4" GRK Screw (Crosspieces into Trusses)
Pergola Planter
Assembly Instruction
3
4
5
13
13
Box 1 of 3
DESCRIPTION
East Bethel, MN USA
18" x 34"
Item #: PP2 18-34
Item #: PP2 18-34S
7
8
6
12
12
Date:
11
11
9
10
10
Continued
763-753-7374
