3 x Product description
Booster heater
In ROTEX heat pump systems, the electric immersion heater is
designated a booster heater.
Type
Operating voltage
Heating output
Temperature range
Cable length
Heating element length
Screw-in thread
Suitable for
Tab. 3 -3 Booster Heater - Overview and technical data

3.3.2 Non return valves

To prevent heat losses through the connection lines when the
heat pump is turned off and during periods without drinking water
flowing (gravitational circulation), circulation brakes (set of two,
16 50 70) should be built into the connections to the ROTEX
High-efficiency hot water storage tank.

3.3.3 Dirt filter

If the ROTEX High-efficiency hot water storage tank is connected
to a heating system with steel pipes, radiators or non-diffusion-
proof floor heating pipes, slurry and swarf could enter the hot
water storage tank and cause blockages, local overheating or
corrosion. This can be prevented by fitting a dirt filter or sludge
trap (see ROTEX price list).

3.3.4 Scalding protection

There is a danger of scalding at hot water temperatures over
60 °C. Fitting scalding protection enables the hot water temper-
ature to be varied continuously and limited from 35 - 60 °C.
– Scalding protection VTA32 (
– Screw connection kit 1" (

3.3.5 Solar storage tank extension kit

The following components are offered for the interconnection of
several ROTEX High-efficiency hot water storage tank to the
solar system:
– Solar storage tank extension kit CON SX (
– Solar storage tank extension kit CCON SXE (
– FlowGuard FLG (
16 41 02)
12
BO3s
230 V / 50 Hz
3 kW
35-65 °C
—
0.9 m
R 1½"
all HYC
16 51 37
15 60 15)
15 60 16)
16 01 20)
16 01 21)
