- Page 1 For certified companies ROTEX Sanicube / HybridCube Installation and maintenance instructions High-efficiency hot water storage tank Types SC 538/0/0 HYC 343/0/0-DB SC 538/16/0 HYC 343/19/0-DB, HYC 343/19/0-P SC 538/16/16 HYC 544/19/0-DB, HYC 544/19/0-P SCS 328/14/0-DB, SCS 328/14/0-P HYC 544/32/0-DB, HYC 544/32/0-P...
-
Page 2: Table Of Contents
Sanicube Solaris (SCS) ....25 6.1.3 Sanicube (SC)......26 FA ROTEX SC / SCS / HYC - 02/2013... -
Page 3: Guarantee And Conformity
Guarantee and conformity Guarantee and conformity 1.1 Warranty conditions The legal guarantee conditions fundamentally apply. Our warranty conditions beyond that can be found online on your sales representative's webpage. FA ROTEX SC / SCS / HYC - 02/2013... -
Page 4: Safety
Notes related to order numbers are identified by the shopping ated installation and operating instructions. cart symbol – When connecting to a ROTEX solar system; the associated installation and operating instructions. Handling instructions The guides are included in the scope of supply for the individual Instructions on actions are shown as a list. -
Page 5: Proper Use
2.5.4 Requirements of the heating and filling water Avoid damages caused by deposits and corrosion: Observe The ROTEX Sanicube / HybridCube may only be used as a hot the current technological regulations to prevent corrosion water storage tank. The ROTEX Sanicube / HybridCube must be products and deposits. -
Page 6: Product Description
Recommended wall distance 200 mm Outer Outer thread thread Internal Internal thread thread Recommended accessories (Convection brake (2 in number), 16 50 70) Tab. 3 -1 Legend designation for images in section 3.1.1 and 3.1.2. FA ROTEX SC / SCS / HYC - 02/2013... -
Page 7: High-Efficiency Hot Water Storage Tank (Unpressurised System - Drain-Back)
3.1.1 High-efficiency hot water storage tank (Unpressurised system - drain-back) For heat pump systems (Type HYC-DB) Fig. 3-1 Connections and dimensions, High-efficiency hot water storage tank with solar support - Type HYC-DB FA ROTEX SC / SCS / HYC - 02/2013... - Page 8 Product description Excluding heat pump systems (Types SC / SCS-DB) Fig. 3-2 Connections and dimensions, High-efficiency hot water storage tank with solar support - Types SC / SCS-DB FA ROTEX SC / SCS / HYC - 02/2013...
-
Page 9: High-Efficiency Hot Water Storage Tank (Pressurised System)
Product description 3.1.2 High-efficiency hot water storage tank (Pressurised system) For heat pump systems (Type HYC-P) Fig. 3-3 Connections and dimensions, High-efficiency hot water storage tank with solar support - Type HYC-P FA ROTEX SC / SCS / HYC - 02/2013... - Page 10 Product description Excluding heat pump systems (Type SCS-P) Fig. 3-4 Connections and dimensions, High-efficiency hot water storage tank with solar support - Type SCS-P FA ROTEX SC / SCS / HYC - 02/2013...
-
Page 11: Brief Description
In addition to the heating possibilities via the corrugated stainless If a ROTEX heat pump system is used as an external heat steel pipe heat exchanger from various different heat sources generator, the primary hot water storage tank can only be one of and energy carriers, the ROTEX High-efficiency hot water the "Hot water storage tanks for heat pump systems"... -
Page 12: Non Return Valves
To prevent heat losses through the connection lines when the heat pump is turned off and during periods without drinking water flowing (gravitational circulation), circulation brakes (set of two, 16 50 70) should be built into the connections to the ROTEX High-efficiency hot water storage tank. 3.3.3 Dirt filter... -
Page 13: Set-Up And Installation
Set-up and installation 4.1 Set-up 4.1.1 Important information 4.1.2 Scope of delivery – ROTEX Sanicube / HybridCube hot water storage tank WARNING! – Bag of accessories (see fig. 4-1) The storage tank plastic wall on the ROTEX Sanicube / HybridCube can melt under the effects of external heat (>80 °C) and, in the extreme case, can catch fire. -
Page 14: Installing The Hot Water Storage Tank
Erecting the hot water storage tank (shown on the point. HybridCube) When setting up the unit in a cabinet, behind panels or in other restricted conditions, sufficient ventilation (e.g., using ventilation gratings) must be ensured. FA ROTEX SC / SCS / HYC - 02/2013... -
Page 15: Installation
CAUTION! tion), you should fit circulation brakes (see chapter If the hot water storage tank is connected to a heating 3.3.2) in the connections to the ROTEX hot water stor- system with steel pipes, radiators or non-diffusion- age tank. proof underfloor heating pipes, sludge and swarf could enter the hot water storage tank and cause 4.2.2 Overview of connections... - Page 16 Recommended accessories (circulation brakes (2 in number), 16 50 70) Tab. 4 -1 Legend for fig. 4-4 / fig. 4-5 Fig. 4-7 External connections hot water storage tank (shown on HYC 544/32/0-P FA ROTEX SC / SCS / HYC - 02/2013...
-
Page 17: Hydraulic Connection
ROTEX heat pump: Storage tank charging return (via 1st. heat source)* ROTEX Mount the storage tank kit "E-PAC" for the Heating support flow* (connect to return flow heat generator!) ROTEX heat pump to the HybridCube hot water storage... -
Page 18: Connecting Together Several Hot Water Storage Tanks
4.2.4 Connecting together several hot water storage tanks CON SX B Storage tank extension kit FlowGuard If the heat output of a single ROTEX hot water storage tank is not FlowSensor adequate you can interconnect several Sanicube / HybridCube Fig. 4-9 Schematic for storage tank extension modules. - Page 19 K1 on the electric immersion heater (fig. 4-10) and connect to the mains connection of the domestic installation ( see chapter 8.3). – EHS/500/5 + EHS/500/6: fig. 4-11 or fig. 4-12 Ensure that the polarity is correct. FA ROTEX SC / SCS / HYC - 02/2013...
-
Page 20: Filling The Hot Water Heat Exchanger
(see fig. 4-4 to fig. 4-7, item 15) and connect the filling hose there using the return flow prevention (1/2"). 2. Fill the storage tank on the ROTEX Sanicube / HybridCube until water comes out of the safety overflow connection (see fig. -
Page 21: Commissioning, Decommissioning
– The heating and hot water system are filled and subjected to the correct pressure. – The ROTEX hot water storage tank is filled to the over- flow point. – Optional accessories have been mounted on and connected Checks before start-up Check all connections for leakage. -
Page 22: Taking Out Of Service
(e.g. by draining). Remove the safety oveflow from the overflow connection (see fig. 4-4 to fig. 4-7, item 14) on the hot water storage If installed: Switch off the power supply to the ROTEX electric tank. immersion heater / booster heater. -
Page 23: Final Shutdown
Dismantle the ROTEX Sanicube / HybridCube in accordance with the instruction manual (chapter 4 "Set-up and instal- lation") in reverse order. ROTEX Sanicube / HybridCube disposed off in a professional manner. Recommendations for disposal ROTEX, thanks to the environmentally friendly design... -
Page 24: Hydraulic Connection
6.1 Connection diagrams 6.1.1 HybridCube (HYC) Fig. 6-1 Standard connection layout with heat pump and drain-back solar (shown in the version with just room heating function) (legend see tab. 6 -1) FA ROTEX SC / SCS / HYC - 02/2013... -
Page 25: Sanicube Solaris (Scs)
Standard connection layout with A1 condensing boiler and pressurised solar (legend see tab. 6 -1) Fig. 6-3 Standard connection layout with A1 condensing boiler an unpressurised solar drain-back (legend see tab. 6 -1) FA ROTEX SC / SCS / HYC - 02/2013... -
Page 26: Sanicube (Sc)
Hot water storage tank HYC 544/32/0-DB Diaphragm expansion vessel Booster heater / electric immersion heater 3-way-mixer with drive motor Burner blocking contact in RPS3 Mixer group with high-efficiency pump Overflow valve FA ROTEX SC / SCS / HYC - 02/2013... - Page 27 Solaris collector temperature sensor Solaris return flow temperature sensor Solaris storage cylinder temp. sensor Solaris inflow temperature sensor Fan (vaporiser) Protection against scalding VTA32 Tab. 6 -1 Short names in hydraulic drawings FA ROTEX SC / SCS / HYC - 02/2013...
-
Page 28: Operation And Maintenance
Target temperature tank completely full. ~65 °C ~78 °C The booster heater should only be adjusted via the configuration menu of the ROTEX heat pump (see associated installation and operating instructions). FA ROTEX SC / SCS / HYC - 02/2013... -
Page 29: Service And Maintenance
– Without connection to a ROTEX heat pump: see section 7.1.2 – With connection to a ROTEX heat pump: see chapter "Operation" in the associated installation and operating instruction. If a solar system is connected and is in operation, switch it off and empty the solar panels. -
Page 30: Technical Data
With post-charging at 35 kW, 80°C flow temperature, 65 °C storage tank temperature, With parallel connection of both storage tank charging heat ex- 45°C hot water temperature; 10°C cold water temperature. changers. Data applies to draw-off rate of 20 l/min. FA ROTEX SC / SCS / HYC - 02/2013... -
Page 31: Sanicube Solaris (Scs)
With post-charging at 35 kW, 80°C flow temperature, 65°C storage tank tem- With parallel connection of both storage tank charging heat exchangers. perature, 45°C hot water temperature; 10°C cold water temperature. FA ROTEX SC / SCS / HYC - 02/2013... -
Page 32: Hybridcube (Hyc)
Tab. 8 -3 Basic data HybridCube - Drain-Back Charging by heat pump and electric booster heater. With heat pump HPSU 008. Charging only by heat pump without electric booster heater. 10) With heat pump HPSU 016. FA ROTEX SC / SCS / HYC - 02/2013... - Page 33 Tab. 8 -4 Basic data HybridCube - pressurised system Charging by heat pump and electric booster heater. With heat pump HPSU 008. Charging only by heat pump without electric booster heater. 10) With heat pump HPSU 016. FA ROTEX SC / SCS / HYC - 02/2013...
-
Page 34: Performance Diagrams
Drinking water heat exchanger Drinking water heat exchanger (HYC 544/19/0-DB, HYC 544/19/0-P, HYC 544/32/0-DB, (SC 538/0/0, SC 538/16/0, SC 538/16/16, SCS 538/16/0-DB, HYC 544/32/0-P) SCS 538/16/0-P, SCS 538/16/16-DB, SCS 538/16/16-P) Drinking water heat exchanger... -
Page 35: Tightening Torque
(hand-tight) Cabling on terminal rail K1 (EHS) 0.5 - 1.5 Nm Tension release (EHS) 6 Nm Cover flap fixing screws (EHS) 4.2 x 19 1.5 Nm Tab. 8 -5 Tightening torque FA ROTEX SC / SCS / HYC - 02/2013... -
Page 36: List Of Keywords
Proper use ....5 Regulation and Pump Station ..28 Relevant documents ... . . 4 FA ROTEX SC / SCS / HYC - 02/2013... -
Page 37: Notes
Notes 10 Notes FA ROTEX SC / SCS / HYC - 02/2013... - Page 38 Notes FA ROTEX SC / SCS / HYC - 02/2013...
- Page 39 Notes FA ROTEX SC / SCS / HYC - 02/2013...
