Product description

2.1

Design and components

2 Product description

2.1.1 Sanicube (SC) / Sanicube Solaris (SCS)

SCS/SC 538/16/16
27
25
24
22
Fig. 2-1
1 Solaris - flow (1 union nut) (SCS only)
2 Cold water supply (1" male)*
3 Hot water (1" male)*
4 Tank charge feed (SC - "heating 1"; SCS - "heating 2") (1" AG)*
5 Tank charge return flow (SC - "heating 1"; SCS - "heating 2")
(1" AG)*
6 Tank charge feed (2nd heat source - "heating 3") (1" AG)*
7 Tank charge return flow (2nd heat source - "heating 3")
(1" AG)*
8 Solar support heating feed (SCS 538/xx/xx only) (1" male)*
(Connect to heating return flow to boiler!)
9 Solar support to heating return flow (SCS 538/xx/xx only)
(1" male)*
(Connect to heating return flow from system!)
10 Storage tank (double-walled jacket made of polypropylene with
PUR hard foam thermal insulation)
11 Filling and drain connection (Tr. 32
x3 male) with valve insert (SCS: Solaris return flow)
12 Connection for equalisation pipe (AGL,
extension set for another heat source (EWS,
13
water heating
8
834
195
93
X
1
4
5
6
7
2
140
3
220
256
2 5 6 8 20 1
3 4 7 9 21 18
13 14 15 23
SCS 538/16/16
Connections and dimensions, Sanicube Hot water storage tank
Corrugated stainless steel pipe heat exchanger for domestic hot
27
95
22
18
26
9
8
20
2 5 20 7 18
3 4 6 21
27
25
16
17
28
12
10
11
19
22
13 14 15 23
SC 538/16/16
14 Corrugated stainless steel pipe heat exchanger for charging
storage tank (SL-WT1)
15 Corrugated stainless steel pipe heat exchanger for charging tank
via 2nd heat source (SL-WT2)
16 Corrugated stainless steel pipe heat exchanger solar support to
heating system (SCS 538/xx/xx only)
17 Heat exchange sleeve for solar support to heating system heat
exchanger (SCS 538/xx/xx only)
18 Connection for electric immersion heater element
(R 11/2" female)
19 Solaris - stratifying pipe flow (SCS only)
20 Filling level indicator
21 Electric immersion heater element (optional)
22 Sensor immersion sleeve for storage tank temperature sensor
23 Unpressurised storage tank water
24 Solar zone (SCS 538/xx/xx only)
25 Hot water zone
26 Type plate
16 01 08) or 27 Safety overflow connection (Tr. 32x3 male)
16 01 10) 28 Handle
X Recommended wall distance 200 mm
* Recommended accessories
(non return flow valves (2 pcs.),
669
SCS 328/14/0
615
176 187
97
X
2 22
5
1 18
6
3
5 4 18
2 3 21
27
27
10
25
28
12
11
22 13 14
SCS 328/14/0
16 50 70)
FA ROTEX SC+HYC - 10/2009
26
