Samson MD1 Direct Box Quick Start Manual page 4

Callouts
1
1. INPUT – 1/4" hi-Z input jack for connecting for instruments or line level
signals.
2. THRU – 1/4" output for passing the input signal through to a stage ampli-
fier or monitor system.
3. GROUND LIFT – When the switch is engaged, the input ground (shield) is
disconnected.
4. BALANCED OUTPUT – Male XLR low-Z connector.
2 3 4
