Surface Temperature Sensor is connected to the instrument and held against
the surface of interest. Temperature values can be displayed in °C or °F (see
section 2.5 for instructions).
T is a useful function when investigating condensation, as it tells the user
DIFF
how many degrees a surface is above or below the prevailing dew point
temperature. When a surface exceeds the dew point by more than 3°C, T
displayed with the message NO CONDENSATION. When a surface exceeds
the dew point by 3°C or less, T
CONDENSATION. When the surface temperature is equal to or lower than the
dew point, a negative T
The progress bar is activated when T
point. The indicator moves from left to right to signify the increasing risk and
degree of condensation. Table 3 below summarizes this functionality.
Temperature of Surface
>14°C above dew point
≤14°C but >3°C above dew point
≤3°C above dew point
≤ dew point
Page 10
is displayed with the message AT RISK, NO
DIFF
is displayed with the message CONDENSATION.
DIFF
Table 3: Condensator Mode Readings
is less than 14°C above the dew
DIFF
MMS Condensator Mode Display
T , NO CONDENSTATION,
DIFF
[inactive progress bar]
T , NO CONDENSTATION,
DIFF
[active progress bar]
T , AT RISK, NO CONDENSTATION,
DIFF
[active progress bar]
T , CONDENSTATION,
DIFF
[active progress bar]
Protimeter MMS Moisture Measurement System
is
DIFF
