Dell SC7020 Getting Started Manual
Hide thumbs
Also See for SC7020:
- Owner's manual (22 pages) ,
- Owner's manual (20 pages) ,
- Getting started manual (17 pages)
Related Manuals for Dell SC7020
Summary of Contents for Dell SC7020
- Page 1 Dell SC7020 Storage Controller Getting Started Guide Regulatory Model: E03T Regulatory Type: E03T001...
-
Page 2: Notes, Cautions, And Warnings
WARNING: A WARNING indicates a potential for property damage, personal injury, or death. Copyright © 2015 Dell Inc. All rights reserved. This product is protected by U.S. and international copyright and intellectual property laws. Dell and the Dell logo are trademarks ™... -
Page 3: Setting Up The Storage System
Setting Up the Storage System Consider the following best practices before setting up your SC7020 storage system. • Dell recommends that you use a dedicated SAN network for data transmission when using a Fibre Channel or iSCSI storage system. •... -
Page 4: Locating Your Service Tag
Alternatively, the information may be on a sticker on the back of the storage system chassis. This information is used by Dell to route support calls to the appropriate personnel. NOTE: The Quick Resource Locator (QRL) code on the information tag is unique to your system. -
Page 5: Installation And Configuration
UPS. In addition, verify that there is space in the rack to install the storage system. Unpacking Storage Center Equipment Unpack the storage system and identify the items in your shipment. Figure 1. SC7020 Storage System Components • Documentation •... - Page 6 The SC7020 storage system ships with a ReadyRails II kit. The rails come in two different styles: tool-less and tooled. Follow the detailed installation instructions located in the rail kit box for your particular style of rails. NOTE: • The storage system and expansion enclosures each require 3U of rack space for installation.
- Page 7 Figure 3. Attach the rails to the rack...
- Page 8 Figure 4. Slide the storage system onto the rails...
- Page 9 Figure 5. Tighten the screws 4. Repeat these steps to position and seat the front end piece of the vertical flange. If the Storage Center system includes expansion enclosures, mount the expansion enclosures in the rack. See the instructions included with the expansion enclosure for detailed steps.
-
Page 10: Nom Information (Mexico Only)
The following information is provided on the device described in this document in compliance with the requirements of the official Mexican standards (NOM): Importer: Dell Inc. de México, S.A. de C.V Paseo de la Reforma 2620-11 ° Piso Col. Lomas Atlas 11950 México, D.F. -
Page 11: Technical Specifications
Technical Specifications The technical specifications of the SC7020 storage systems are displayed in the following tables. Drives SAS hard drives Up to 30 2.5-inch SAS hot-swappable hard drives (12GB SAS) Storage Controllers Storage Up to two hot-swappable storage controllers with one controllers mezzanine card and three IO slots. - Page 12 Back-Panel Ports Connectors (per Storage Controller) Serial connector NOTE: Not for customer use LED Indicators • One two-color LED indicator for system status. Front panel • One single-color LED indicator for power status. • ID button with a single-color LED indicating boot status and pressed states Hard drive carrier •...
- Page 13 Weight without drives 25 kg (55 lb.) Environmental For additional information about environmental measurements for specific storage system configurations, see dell.com/environmental_datasheets. Temperature Operating 10°C (50°F) to 35°C (95°F)with a maximum temperature gradation of 20°C/hour (36°F/hour) 52°C (126°F) maximum 2,000 to 3,048 m (6,562 to 10,000 ft) 47°C (117°F) maximum 3,048 to 4,000 m (10,000 to...
- Page 14 Environmental Storage 71 G +/- 5% with pulse duration of 2 msec +/- 10% (equivalent to 35 in/sec [89 cm/sec]) Altitude Operating 3,048 meters (10,000 feet) <35°C (95°F) Maximum Rating—Maximum temperature is reduced by 1°C/300 meter (1°F/547 feet) above 950 meters (3,117 feet) 40°C (104°F) Maximum Rating—Maximum temperature is reduced by 1°C/175 meter (1°F/319 feet) above 950...
