ELECTRIC INSTANTANEOUS WATER
READ THIS MANUAL CAREFULLY BEFORE ATTEMPTING TO INSTALL OR OPERATE
THIS WATER HEATING UNIT. IF YOU DO NOT FOLLOW THE SAFETY RULES, THE
UNIT WILL NOT OPERATE PROPERLY AND COULD CAUSE DEATH, SERIOUS
BODILY INJURY AND OR PROPERTY DAMAGE.
READ ALSO THE ENCLOSED WARRANTY CARD. WARRANTY OF THIS WATER
HEATING UNIT WILL DEPEND ON PROPER INSTALLATION AND OPERATION. THE
WARRANTY SHALL BE VOID IF THE DESIGN HAS BEEN ALTERED IN ANY WAY
WHATSOEVER. THE MANUFACTURER OF THIS UNIT WILL NOT BE LIABLE FOR
ANY DAMAGES BECAUSE OF FAILURE TO COMPLY WITH THE INSTALLATION AND
OPERATING OUTLINED ON THE FOLLOWING PAGES.
THE INSTALLATION MUST CONFIRM WITH THE INSTRUCTIONS IN THIS MANUAL;
ELECTRIC COMPANY RULES; AND LOCAL CODES, OR IN THE ABSENCE OF LOCAL
CODES, WITH THE LATEST EDITION OF THE NATIONAL ELECTRICAL CODE. A
COPY OF THE NATIONAL ELECTRICAL CODE IS AVAILABLE FROM
UNDERWRITERS LABORATORIES, 333 PFINGSTEN ROAD, NORTHBROOK, IL,
60062
.
IF ASSISTANCE IS REQUIRED OR ANY QUESTIONS ARISE RELATING TO THE
INSTALLATION OR THE PERFORMANCE OF THIS UNIT, CONTACT TECHNICAL
SERVICE DEPARTMENT TOLL FREE AT 1-800-334-3393.
HAVE THE INFORMATION LISTED BELOW BEFORE CALLING:
MODEL NO.
HEATER
INSTALLATION GUIDE AND OWNERS MANUAL
"THERMOSTATIC"
MODELS COVERED:
EFT-5500-4-S-10
EFT-6500-4-S-10
EFT-7500-4-S-10
EFT-9500-4-S-10
EFT-8300-2-S-10
EFT-6000-5-S-10
EFT-8000-5-S-10
EFT-9000-5-S-10
EFT-10000-5-S-10
SERIAL NO.
240V
240V
240V
240V
208V
277V
277V
277V
277V
INSTALL DATE
.
Advertisement
Related Manuals for Bradford White Kwickshot EFT-5500-4-S-10
Summary of Contents for Bradford White Kwickshot EFT-5500-4-S-10
- Page 1 ELECTRIC INSTANTANEOUS WATER HEATER INSTALLATION GUIDE AND OWNERS MANUAL “THERMOSTATIC” MODELS COVERED: EFT-5500-4-S-10 240V EFT-6500-4-S-10 240V EFT-7500-4-S-10 240V EFT-9500-4-S-10 240V EFT-8300-2-S-10 208V EFT-6000-5-S-10 277V EFT-8000-5-S-10 277V EFT-9000-5-S-10 277V EFT-10000-5-S-10 277V READ THIS MANUAL CAREFULLY BEFORE ATTEMPTING TO INSTALL OR OPERATE THIS WATER HEATING UNIT.
-
Page 2: Mounting The Unit
GENERAL This “Thermostatic” water heating unit is specifically designed to take in cold or pre-heated water and heat it to temperatures suitable for domestic usage up to a maximum of 140°F (60°C). To obtain optimum performance and energy savings. The unit should be located as near as possible to the point of use. -
Page 3: Plumbing Connections
Plumbing Connections NOTE: ALL MOUNTING AND PLUMBING MUST BE COMPLETED BEFORE PROCEEDING WITH THE ELECTRICAL HOOK-UP. TEST THE INSTALLATION FOR LEAKS BEFORE CONNECTING THE ELECTRICAL SUPPLY. 1) This unit is supplied with compression fittings, USE THESE; DO NOT USE TAPERED THREAD PIPE FITTINGS AND DO NOT SOLDER PIPE TO THE INLET OR OUTLET(SEE FIGURE 1). -
Page 4: Electrical Connections
ELECTRICAL CONNECTIONS WARNING BEFORE BEGINNING ANY WORK ON THE INSTALLATION BE SURE THAT SWITCH AT MAIN BREAKER PANEL IS “OFF” TO AVOID ANY DANGER OF ELECTRICAL SHOCK. DANGER FAILURE TO GROUND THE SYSTEM MAY RESULT IN DEATH OR SERIOUS INJURY. This “Thermostatic”... - Page 5 TERMINAL BLOCK ELECTRICAL HOOK-UP GROUND TEMPERATURE CONTROL Note: 277V models, “L2” ADJUSTMENT terminal is replaced by SCREW neutral “N”. HOT WATER OUTLET PRE-HEATED/COLD WATER INLET THE TEMPERATURE CONTROLLING POTENTIOMETER IS A PRECISION COMPONENT. ADJUST GENTLY AND DO NOT TURN BEYOND THE MIN. AND MAX.
-
Page 6: Operation
OPERATION WARNING HOUSEHOLDS WITH SMALL CHILDREN OR ELDERLY PERSONS MAY REQUIRE WATEER TEMPERATURES OF 125°F OR LOWER TO PREVENT ACCIDENTAL SCALDING FROM CONTACT WITH THE WATER. 1) Completely open both the inlet and outlet ball valves at the unit. 2) Open all hot water outlet serviced by the unit. If the outlet is a mixer type adjust to the hottest position. - Page 7 SYMPTOM POSSIBLE CAUSE SOLUTION NO HEAT - A) ELECTRICAL SUPPLY OFF TURN ON MAIN CIRCUIT BREAKER INDICATOR LIGHT MINIMUM WATER FLOW TO TURN ON UNIT IS 0.7 GALLON PER MINUTE. INCREASE FLOW TO AT B) NO OR LOW WATER FLOW LEAST THIS LEVEL.
