  • Page 1 OWNER’S MANUAL DS-6500 Dispatch Terminal...
  • Page 2 Preface Thanks for your favor in our product. DS-6500 Dispatch Terminal is tailored to work with Hytera SmartDispatch application, to simplify dispatch operation and enhance operational efficiencies in the mission-critical environment. Its compact body facilitates easy installation and maintenance, while the modular design allows for easy addition of accessories based on your actual needs.
  • Page 3 Copyright Information Hytera is the trademark or registered trademark of Hytera Communications Co., Ltd. (the Company) in PRC and/or other countries or areas. The Company retains the ownership of its trademarks and product names. All other trademarks and/or product names that may be used in this software are properties of their respective owners.

  • Page 4: Table Of Contents

    User Manual Contents Contents Preface ............................... ii Documentation Information ........................1 1. Checking Items in the Package ......................2 2. Safety Information ..........................2 3. Specification ............................5 4. Product Overview ..........................6 5. Connection Diagram ..........................9 6. Turning the Product On/Off ......................... 9 7.

  • Page 5: Documentation Information

    User Manual Documentation Information Documentation Information This section describes the conventions and revision history of this document. Instructional Icons Icon Description Caution Indicates situations that could cause data loss or equipment damage. Notational Conventions Convention Description The text in boldface denotes the name of a hardware button. For example, press the Bold PTT key.

  • Page 6: Checking Items In The Package

     Do not attempt to service the product by yourself. Power Cord  Use only the power cord supplied by Hytera.  Do not wrap the power cord around the power adapter or other objects. Otherwise, the power cord may become frayed or damaged and thus cause safety hazard.
  • Page 7 User Manual Safety Information  Do not share the outlet with other high-power household or commercial appliances; otherwise, unstable voltage may damage your data or connected devices.  Do not overload the outlet. The total system load must not exceed 80% of the branch circuit rating. For more information, please consult an electrician.
  • Page 8 Safety Information User Manual 2. Unplug the power cord from the outlet. 3. Remove the signal cable from the connector. 4. Remove all cables from the equipment. You must first remove the power cord from the power outlet, and then attach other cables to the product.

  • Page 9: Specification

     One 3.5mm Mic-in port  One 3.5mm Line-in port I/O Interface  One 3.5mm Line-out port  One PS/2 port  Two 3.5mm Mic-in or Line-out ports (Dedicated for DS-6500 with multiple dispatch stations) Antenna BNC (female) Connector Power Supply...

  • Page 10: Product Overview

    RoHS Compliant with RoHS standard 4. Product Overview Caution All pictures in this manual are for reference only. DS-6500 (with two built-in dispatch stations) Front Panel Part Name Part Name Power Button (for main unit) Power Buttons (for dispatch station)
  • Page 11 User Manual Product Overview Rear Panel Part Name Part Name Ground Terminal Audio Input Port AC Power Port Audio Output Port DVI Port Microphone Port PS/2 Ports Antenna Connector RS232 Ports USB Ports Audio Output Ports VGA Port (for expansion dispatch station) Microphone Ports HDMI Port (for expansion dispatch station)
  • Page 12 Product Overview User Manual DS-6500 (with one built-in dispatch station) Front Panel Part Name Part Name Power Button (for main unit) Power Button (for dispatch station) Rear Panel Part Name Part Name Ground Terminal RJ45 Ports AC Power Port Audio Input Port...

  • Page 13: Connection Diagram

    Antenna Connector HDM Port 5. Connection Diagram Please refer to the following figure to connect DS-6500 and other devices. 6. Turning the Product On/Off Turning On the Product To turn on the main unit, press the Power Button and its LED indicator glows green.

  • Page 14: Software

    Software User Manual 7. Software Caution For features and operations on the software, please refer to product-specific documentation. 8. Care and Cleaning To guarantee optimal performance as well as a long service life of the product, please follow the tips below.

  • Page 15: Optional Accessories

    User Manual Optional Accessories 9. Optional Accessories The following items are the main optional accessories for the product, and please consult your local dealer for more other accessories. Part Name Product Model Desktop Microphone DM01U1 Antenna Speaker Earpiece Subject to your actual needs. Microphone USB Optical Drive Monitor...
  • Page 16 Hytera Communications Corp., Ltd. 2013 Hytera Corp., Ltd. All Rights Reserved. Address: HYT Tower, Hi-Tech Industrial Park North, Beihuan RD., Nanshan District, Shenzhen, China Postcode: 518057 http://www.hytera.com...
