PDA102 Instructions • DCP003169 Rev 3 • Page 16
PDA102
AUDIO-FREQUENCY
INDUCTION LOOP AMPLIFIER
INSTALLATION INSTRUCTIONS
This equipment must be installed by a suitably skilled and technically
competent person. Please read these instructions carefully before installation.
Important notes ............................................................................................. 2
PDA102 kit contents ...................................................................................... 2
What is an audio frequency induction loop system? .................................. 3
Familiarisation with your PDA102 induction loop amplifier ...................... 4
Planning the system ...................................................................................... 5
Overview of the 'Outreach plate' audio input extension system .............. 10
Installation ..................................................................................................... 11
Connecting and testing the system ............................................................... 12
Troubleshooting ............................................................................................. 14
Technical specification ................................................................................... 15
PDA102 Instructions • DCP003169 Rev 3 • Page 1
Advertisement
Table of Contents
Related Manuals for PDA Range PDA102
Summary of Contents for PDA Range PDA102
-
Page 1: Table Of Contents
PDA102 kit contents ..................2 What is an audio frequency induction loop system? ........3 Familiarisation with your PDA102 induction loop amplifier ...... 4 Planning the system ..................5 Overview of the ‘Outreach plate’ audio input extension system ....10 Installation ..................... -
Page 2: Important Notes
Recommended loop conductor size: 0.5mm @ <16metres loop length (inc. tails) The PDA102 induction loop amplifier is available in the following kit formats. Please ensure Recommended number of turns: 1 that the accessories shown are included in the kit you have purchased. -
Page 3: What Is An Audio Frequency Induction Loop System
Tip: The loop strength meter WILL NOT illuminate if there is a break in the loop cable or if it is misconnected. Loop Microphone Signal cable Signal cable Hearing aid in the Amplifier ‘T’ or ‘MT’ position Television PDA102 Instructions • DCP003169 Rev 3 • Page 14 PDA102 Instructions • DCP003169 Rev 3 • Page 3... -
Page 4: Familiarisation With Your Pda102 Induction Loop Amplifier
If the signal level is not acceptable, adjust the Drive control in small increments until it is. When you are The PDA102 is a true current mode wall or desk mountable induction loop amplifier designed satisfied with the signal in the centre of the loop, move around to cover ticket counters up to 1.2m... -
Page 5: Planning The System
Connect the loop cable (supplied), the microphone and/or the outreach network If you have purchased a non-kit variant of the PDA102, we recommend the use of 0.5mm tri-rated cable such as our own LOOP1/B or LOOP1/W cable, available in 100m reels. Note cable (as relevant) to the amplifier as shown below. -
Page 6: Installation
We recommend you apply one of the ‘induction loop in use’ stickers supplied with the The loop will not interfere with computer keyboards but may PDA102 to the amplifier’s top surface to help identify it as an induction loop system (see cause the screen to judder if placed too close to some monitors. - Page 7 Overview of the Outreach plate audio input extension system A typical PDA102R small room system (‘Outreach’ plated mic. version) The PDA102 is fully compatible with the outreach plate audio input extension system. This system allows the connection of multiple microphone or line level inputs via a range of...
- Page 8 Put the ‘induction possible to the user using supplied, or be left free-standing. is provided for connecting the APL to the PDA102 loop in use’ sticker the self-adhesive pad or and this can be cut to the desired length. The APS where it can be other fittings supplied.
