- Page 1 CS261 / CS261TK DVI Computer Sharing Device RS232 Commands V1.0 User Manual www.aten.com...
-
Page 2: Emc Information
CS261 / CS261TK RS-232 Control Tool EMC Information FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 3: Hardware Connection
CS261 / CS261TK user manual. Setup Install a HyperTerminal application on a computer that is not part of the CS261 / CS261TK setup, which will be connected and used to control the CS261 / CS261TK via RS-232. HyperTerminal applications can be download from the internet, and many operating systems are embedded with HyperTerminal applications. - Page 4 CS261 / CS261TK RS-232 Control Tool Console Login - HyperTerminal Once a physical connection from the computer to the CS261 / CS261TK has been made, you can establish a HyperTerminal session using the instructions below. 1. Open the HyperTerminal application, and configure the port settings for...
- Page 5 CS261 / CS261TK RS-232 Control Tool Bits per Second: 19200, Data Bits: 8, Parity: None, Stop bits: 1, Flow Control: None. 2. When configured correctly a login prompt like the one below appears:...
- Page 6 4), you can use the instructions below to send RS-232 commands to control the CS261 / CS261TK from a remote system. When the RS-232 link is opened, the CS261 / CS261TK will no longer accept commands from front panel buttons or most of hotkey functions (excluding hotkey switching mode, console status and turn off/on the other monitor and audio).
-
Page 7: Switch Operation
CS261 / CS261TK RS-232 Control Tool Switch Operation The switch port command allows you to switch between computers connected to the CS261 / CS261TK’s ports. Use the Formula - to set Parameters - to create a Command. Formula: Command + Input Command + [Enter]... - Page 8 CS261 / CS261TK RS-232 Control Tool Keyboard Language Layout The Keyboard Language Layout command allows you to change the keyboard language layout. Use the Formula - to set Parameters - to create a Command. Formula: Command + Control + [Enter]...
- Page 9 CS261 / CS261TK RS-232 Control Tool Set Operating System The Set Operating System command allows you to set the operating system for a port. Use the Formula - to set Parameters - to create a Command. Formula: Command + Control + [Enter]...
- Page 10 CS261 / CS261TK RS-232 Control Tool Timeout The Timeout command allows you to set the timeout period. Use the Formula - to set Parameters - to create a Command. Formulas: Command + Control + [Enter] Parameters: Command Description timeout Timeout Period...
- Page 11 Control Description remix Implement the EDID of each connected display according to its connection when the CS261 / CS261TK is first powered on, or immediately after selecting the Remix option. port1 Implement the EDID of the connected display to console1, and pass it to the source.
- Page 12 CS261 / CS261TK RS-232 Control Tool Note: 1. Each command string can be separated with a space. 2. The default EDID mode setting is remix. 3. The ASCII code for Enter is 0x0D0A.
-
Page 13: Screen Saver
CS261 / CS261TK RS-232 Control Tool Screen Saver The Screen Saver command allows you to set the timeout period before the screen saver is activated. Use the Formula - to set Parameters - to create a Command. Formulas: Command + Control + [Enter]... -
Page 14: Activate Beeper
CS261 / CS261TK RS-232 Control Tool Activate Beeper The Activate Beeper command allows you to enable/disable the beeper function. Use the Formula - to set Parameters - to create a Command. Formulas: Command + Control + [Enter] Parameters: Command Description... -
Page 15: Hotkey Settings
CS261 / CS261TK RS-232 Control Tool Hotkey Settings The Hotkey Settings command allows you to enable/disable and change the hotkey used to invoke the HSM (Hotkey Settings Mode). Use the Formula - to set Parameters - to create a Command. -
Page 16: Hotkey Switching
CS261 / CS261TK RS-232 Control Tool Hotkey Switching The Hotkey Switching command allows you to change the hotkey switching mode. Use the Formula - to set Parameters - to create a Command. Formulas: Command + Control + [Enter] Parameters: Command... -
Page 17: Usb Reset
CS261 / CS261TK RS-232 Control Tool USB Reset The USB Reset command allows you to reset the USB connection. Use the Formula - to set Parameters - to create a Command. Formulas: Command + Control + [Enter] Parameters: Command Description... -
Page 18: Restore Default Settings
CS261 / CS261TK RS-232 Control Tool Restore Default Settings The Restore Default Settings command allows you to reset all of the CS261 / CS261TK’s settings back to the default. Use the Formula - to set Parameters - to create a Command. -
Page 19: Firmware Upgrade
CS261 / CS261TK RS-232 Control Tool Firmware Upgrade The Firmware Upgrade command allows you to enable the firmware upgrade mode. Use the Formula - to set Parameters - to create a Command. Formulas: Command + [Enter] Parameters: Command Description upgrade... -
Page 20: Kvm Status
CS261 / CS261TK RS-232 Control Tool KVM Status The KVM Status command allows you to display read-only information about the CS261 / CS261TK’s current KVM status. Use the Formula - to set Parameters - to create a Command. Formulas: Command + [Enter]... - Page 21 CS261 / CS261TK RS-232 Control Tool Info The Info command allows you to display the CS261 / CS261TK’s current firmware version and ATEN copyright information. Use the Formula - to set Parameters - to create a Command. Formulas: Command + [Enter]...
- Page 22 CS261 / CS261TK RS-232 Control Tool This Page Intentionally Left Blank...
