MC-100V & BC-100V
Operation / Installation Manual
A guide on how to use and install Rinnai deluxe water controllers
This guide is for the use and installation of
Rinnai Deluxe water controller models
MC-100V and BC-100V.
These instructions must be used in conjunction
with the Rinnai Water Heater Operation /
Installation Manual supplied with Rinnai water
heaters.
These water controllers are compatible only
with the Rinnai water heater and other water
controller models shown.
Refer to the table located on page 1 of this
manual to confirm the maximum number and
combination of controllers that can be fitted to
your Rinnai water heater model.
This appliance shall be installed in accordance with:
• Manufacturer's Installation Instructions
• Current AS/NZS 3000, AS/NZS 3500 & NZS 5261
• Local Regulations and Municipal Building Codes
This appliance must be installed, serviced and removed by an Authorised Person.
Compatible Rinnai water heater models:
Infinity XR32
HD-200
Infinity XR26
HD-200i
Infinity XR24
HD-250
Infinity XR20
HD-250i
Infinity XR18
Infinity XR16
Infinity XR26i
Infinity XRPlus 26
Infinity XRPlus 20
Efficiency 24
Compatible Rinnai water controller:
Universal wired controller
Wireless controller
MC-91
MC502S
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Rinnai MC-100V
Summary of Contents for Rinnai MC-100V
- Page 1 MC-100V & BC-100V Operation / Installation Manual A guide on how to use and install Rinnai deluxe water controllers This guide is for the use and installation of Compatible Rinnai water heater models: Rinnai Deluxe water controller models Infinity XR32 HD-200 MC-100V and BC-100V.
- Page 2 Controllers and water heaters must be installed correctly by an authorised person. The installation of gas, water, and electricity must conform to local regulations. The installation must also comply with the instructions supplied by Rinnai. Please keep this instruction booklet in a safe place for future reference.
-
Page 3: Table Of Contents
DELUXE WATER CONTROLLERS ................2 ABOUT THE DELUXE KITCHEN WATER CONTROLLER (MC-100V) ........2 HOW TO USE THE DELUXE KITCHEN WATER CONTROLLER (MC-100V) ......2 ABOUT THE DELUXE BATHROOM WATER CONTROLLER (BC-100V) ........4 HOW TO USE THE DELUXE BATHROOM WATER CONTROLLER (BC-100V)......4 OPERATING THE SHOWER SAVER / BATH FILL FUNCTION.......... -
Page 4: General Water Controller Information
Kitchen 50°C ~ 55°C* Shower 37°C ~ 43°C, Bath fill 39°C ~ 45°C * Temperature may not be available on all installations. Rinnai water heaters can be programmed to deliver higher temperatures via the kitchen controller. Contact Rinnai for more details. -
Page 5: Deluxe Water Controllers
If more than one controller is fitted press the ‘Transfer’ button to transfer priority to the desired controller. The MC-100V controller is not water resistant, avoid direct exposure to water or steam as these conditions may cause damage. NOTE Setting The Clock The clock is a 12 hour AM/PM style display. - Page 6 43°C. In addition transfer of 'priority' between NOTE controllers is not possible. These are safety features. CHECK WATER TEMPERATURE BEFORE USE. A parent or carer should always check the temperature before a child is placed CAUTION in contact with hot water. Rinnai New Zealand Operation Manual:01-07...
-
Page 7: About The Deluxe Bathroom Water Controller (Bc-100V)
Refer to page 1 to confirm the maximum number and combination of water controllers that can be fitted to your Water Heater model. NOTE Avoid getting water directly in the speaker as this may cause damage. Rinnai New Zealand Operation Manual:01-07... - Page 8 43°C. In addition transfer of 'priority' between NOTE controllers is not possible. These are safety features. CHECK WATER TEMPERATURE BEFORE USE. A parent or carer should always check the temperature before a child is placed CAUTION in contact with hot water. Rinnai New Zealand Operation Manual:01-07...
-
Page 9: Operating The Shower Saver / Bath Fill Function
The 'Shower Saver / Bath fill' button will illuminate and a voice prompt and tone will sound. During 'Shower Saver / Bath Fill' operations the 'Bath' indicator will also be displayed in the deluxe kitchen water controller digital monitor (when fitted). Rinnai New Zealand Operation Manual:01-07... -
Page 10: Using Multiple Controllers
Universal and Deluxe Controllers can be combined and will function as described in other sections of the Water Heater Operation / Installation Manual. Refer to page 1 to confirm the maximum number and combination of water controllers that can be fitted to your water heater model. Rinnai New Zealand Operation Manual:01-07... -
Page 11: Water Controller Installation
Heat, steam, smoke and hot oil may cause damage. NOTE • Do not install water controllers in direct sunlight. • The MC-100V water contoller MUST NOT be installed in a bathroom. • Do not install water controllers outdoors unless protection from dust ingress and sunlight are provided. -
Page 12: Fitting The 'Deluxe Bathroom' Water Controller (Bc-100V)
Backing Seal Remove to expose self-adhesive Fig. 3 Fig. 4 Fig. 5 Remove the protective plastic film from the controller’s digital monitor. Replace the face plate. Rinnai New Zealand Installation Manual:01-07... - Page 13 Extension cables are available from Rinnai. Alternatively, two core sheathed (double insulated) flex with minimum cross sectional area of 0.5mm² may be used. Cable lengths must not exceed 20 metres.
- Page 14 NOTES Rinnai New Zealand Installation Manual:01-07...
- Page 15 NOTES Rinnai New Zealand Installation Manual:01-7...
-
Page 16: Contact Information
RA TSD Issue 27/12/07...
