4-684-553-12(1)
Television
Reference Guide
KD-55X8200E / 55X8000E / 49X8200E / 49X8000E / 43X8200E / 43X8000E
FW-55X8001E / 49X8001E

Advertisement

Table of Contents

   Summary of Contents for Sony KD-55X8200E

  • Page 1 4-684-553-12(1) Television Reference Guide KD-55X8200E / 55X8000E / 49X8200E / 49X8000E / 43X8200E / 43X8000E FW-55X8001E / 49X8001E...
  • Page 2: Table Of Contents

    Introduction Table of Contents Thank you for choosing this Sony product. Before operating the TV, please read this manual thoroughly and retain it for future reference. Note • Before operating the TV, please read the “Safety information” (page 3). • Instructions about “Installing the TV to the Wall” are included within this TV’s instruction manual.
  • Page 3: Safety Information

    Screw (not supplied) • Only qualified service personnel should carry out wall-mount installations. • For safety reasons, it is strongly recommended that you use 1.5 N·m/1,5 N·m Sony accessories, including: Cord (not {15 kgf·cm}  Wall-Mount Bracket SU-WL450 supplied) Screw (not...
  • Page 4 • Use when your hands are wet, with the cabinet removed, or with the plug that fits into the AC power outlet (mains socket).  Use only Sony supplied AC power cords (mains lead), not those with attachments not recommended by the manufacturer.
  • Page 5: Precautions

    Turn off the TV set and unplug the AC power cord (mains lead) stand. immediately if any of the following problems occur. Ask your dealer or Sony service centre to have it checked by Optional Equipment qualified service personnel. Keep optional components or any equipment emitting When: electromagnetic radiation away from the TV set.
  • Page 6 You may contact our company’s toll free number in India for assistance. Toll Free: 1800-103-7799 Visit: www.sony.co.in for product recycling Reduction in the Use of Hazardous Substances in Electrical & Electronic Equipment (Applicable in Republic of India)
  • Page 7: Parts And Controls

    Parts and Controls Controls and Indicators   (Power) /+/- When the TV is off,  Press to power on. When the TV is on,  Press and hold to power off.  Press repeatedly to change the function, then press + or – button to: •...
  • Page 8: Using Remote Control

    Using Remote Control Remote Control Parts Description The remote control shape, location, availability and function of remote control button may vary depending on your region/country/TV model.  / (Input select/Text hold) (Wide mode) In TV mode: Display and select the input Change the screen format.
  • Page 9  Google Play  AUDIO Access the “Google Play” online service. Change the language for the programme currently being viewed. NETFLIX (Only on limited region/ ///.//>/ country/TV model) Operate media contents on TV and Access the “NETFLIX” online service. connected BRAVIA Sync-compatible device. Colour buttons (Subtitle setting) Execute corresponding function at that time.
  • Page 10: Connection Diagram

    Connection Diagram For more information on connections, refer to the Help Guide by pressing HELP on the remote control. Home Audio Headphone/ System with Home Audio Optical System/ HDMI Audio Input Subwoofer Device Digital still camera/ Camcorder/USB storage media HDMI Device Home Audio System with ARC/ HDMI Device...
  • Page 11: Audio Out

     AUDIO OUT  / VIDEO IN 1 • Supports 3-pole stereo mini jack only. • For a composite connection, use an • To listen to the TV's sound through the Analogue Extension Cable (not supplied). connected equipment, press HOME. •...
  • Page 12: Installing The Tv To The Wall

    Sufficient expertise is required for installing this product, especially to determine the strength of the wall for withstanding the TV’s weight. Be sure to entrust the attachment of this product to the wall to Sony dealers or licensed contractors and pay adequate attention to safety during the installation. Sony is not liable for any damage or injury caused by mishandling or improper installation.
  • Page 13 Make sure that the wall has enough space for the TV and is capable of supporting a weight of at least four times that of the TV. Refer to the following table on installing the TV to the wall. See page 17-18 (Specifications) for the TV’s weight.
  • Page 14 Attach the Attachment parts for Wall-Mount Bracket. Check the Attachment parts by referring to “1” of the Wall-Mount Bracket Installation Guide. Note • If using an electric screwdriver, set the torque at approximately 1.5 N·m {15 kgf·cm}. • Be sure to store the unused parts in a safe place for future use. Retain this manual for future reference. Standard mounting ...
  • Page 15   Screw (+PSW 6 x 20) Screw (+PSW 6 x 20)  Pulley  Spacer (20 mm) Soft cloth  Belt Connect necessary cables to the TV. Note • You cannot access to any terminal after installing the TV to the wall. Install the TV to the Base.
  • Page 16: Troubleshooting

    TV. If the problem persists, disconnect the AC power Refer to the Help menu by pressing HELP on cord (mains lead), and contact your dealer or Sony the remote control. service centre with the number of times the illumination LED flashes.
  • Page 17: Specifications

    Audio: 5.1 channel linear PCM: 32, 44.1, 48, 88.2, 96, 176.4 and 192 kHz, 16, 20 and 24 bits, Dolby Specifications Digital, Dolby Digital Plus and DTS ARC (Audio Return Channel) (HDMI IN 3 only) System (Two channel linear PCM: 48 kHz, 16 bits, Dolby Panel system Digital, Dolby Digital Plus, DTS) LCD (Liquid Crystal Display) Panel, LED Backlight...
  • Page 18: Trademark Information

    Screen size (measured diagonally) (Approx.) without Table-Top Stand KD-55X8200E / KD-55X8000E / FW-55X8001E: KD-55X8200E / KD-55X8000E / FW-55X8001E: 55 inches / 138.8 cm 17.6 kg KD-49X8200E / KD-49X8000E / FW-49X8001E: KD-49X8200E / KD-49X8000E / FW-49X8001E: 49 inches / 123.2 cm 12.2 kg...
  • Page 19 • The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by Sony Corporation is under license. Other trademarks and trade names are those of their respective owners. • TUXERA is a registered trademark of Tuxera Inc.
  • Page 20 KD-43X8000E only Help Guide http://rd1.sony.net/help/tv/ega2/h_ga/ Except KD-43X8000E http://rd1.sony.net/help/tv/ega3/h_ga/ Customer Support and Contact: © 2017 Sony Corporation Printed in Malaysia...
