Thermador HMWN30FS Manual

HMWN30FS
WALL HOOD (30-INCH WIDTH)
MASTERPIECE ®
FEATURES & BENEFITS
- Recirculation possible with kit RECIRC30FS (max 600 CFM)
- Three fan speeds
- Built-in 'Clean Filter' reminder light illuminates after 40 hours
of operation
- Delayed shut-off tackles lingering odors for up to 10 minutes
- Dishwasher-safe low-profile baffle filters

ACCESSORIES (OPTIONAL)

Roofplates
RFPLT600P - For use with 600 CFM Remote Blower VTR630P
RFPLT1000P - For use with 1000 CFM Remote Blower
VTR1030P and 1300 CFM Blower VTR1330P
Recirculation Kit
RECIRC30FS - For HPWB30FS, HMWB30FS and HMWN30FS
30" Hoods Only. Adds 4" to height of appliance
Replacement Charcoal Filter - CHFILT3036
For Use With Recirculation Kit RECIRC_FS
30" W, 6" H Stainless Steel Duct Cover
30" W, 12" H Stainless Steel Duct Cover

GENERAL PROPERTIES

Operating Mode
Maximum CFM
Number of Speed Settings
Motor Location
Number Of Lights
Bulb Type
Total Power Of The Lamps (W)
Damper Included
Grease Filter Material
Grease Filter Type

TECHNICAL DETAILS

Watts (W)
Current (A)
Volts (V)
Frequency (Hz)
Plug Type
DIMENSIONS & WEIGHT
Overall Appliance Dimensions (Width Of
Canopy Included) (HxWxD) (in)
Required Distance Above Cooktop / Range
Cooking Surface
Diameter of Air Duct (in) Top
Diameter of Air Duct (in) Back
Net Weight (lbs)

ACCESSORIES (REQUIRED)

DC30US
Blower (Sold Separately)
DCT30US

BLOWER OPTIONS

Remote Blower
(Mounted to Roof or External Wall)
Inline Blower
(Mounted Between Kitchen and External Wall)
Integrated Blower (Mounted in Hood)

WARRANTY

Limited Warranty Parts And Labor
Page 1 of 5
Convertible: Ducted /
Recirculating
N/A
3-Stage
Blower (Sold
Separately)
Lights Sold
Separately - 2
50 W - G10 Base
100 W
Yes
Washable Synthetic
Multilayer Cassette
100 W
15 A
120 V
60 HZ
Fixed Connection
11" x 30" x 23 1 / "
8
30" / 30"
10"
N/A
35 lbs
VTR630P - 600 CFM
VTR1030P - 1000 CFM
VTR1330P - 1300 CFM
VTI610P - 600 CFM
VTI1010P - 1000 CFM
VTN600F - 600 CFM
2 Year
09 / 16
