TPM1.0U LA 1. Technical Specifications,Connections,and Chassis Overview 1.Technical Specifications,Connections,and Chassis Overview Index of this chapter: AV IN3: Video3 (CVBS, RCA jack) and S-Video share with 1.1 Technical Specifications same audio R/L (RCA jack ). 1.2 Connections AV IN1: YPbPr component video1 (RCA jack) with audio R/L (RCA jack). 1.3 Chassis Overview AV IN2: YPbPr component video2 (RCA jack) with audio R/L (RCA jack).
Page 3
TPM1.0U LA 1. Technical Specifications, Connections and Chassis Overview 1.2.3 HDMI Pin assignment (Nafta only) 1.2.4 VGA Pin assignment Type A Connector No. 1 No. 19 No. 2 No. 18 PIN No. SIGNAL PIN No. SIGNAL TMDS Data2+ TMDS Data2 shield Green TDMS Data2- Blue...
TPM1.0U LA 3. Directions for Use 3. Directions for Use You can download this information from the following websites: http://www.philips.com/support http://www.p4c.philips.com Magnavox/Philips Digital UI-TV/AV1/AV2/AV3/Side/HDMI OSD Layer 1 Picture Smart Picture Personal Rich Natural Soft Power Saver Contrast slider Brightness slider...
Page 7
TPM1.0U LA 3. Directions for Use Digital caption options Reset to default Reset to default Size Default Small Standard Large Style Default Monospaced serif Serif Monospaced sans serif Sans serif Casual Cursive Small caps Text Color Default Black White Green Blue Yellow Magenta...
Page 8
HDMI Digital Clock Enter Time(Hrs,Mins) AM/PM Weak channel Installation (Current software Current Software Info Version) Reset AV settings Start now EXIT EXIT Magnavox/Philips Digital UI-PC Picture Contrast slider Brightness slider Color temp Normal Warm Cool Picture format Full screen Sound...
TPM1.0U LA 4. Mechanical Instructions 4. Mechanical Instructions Index of this chapter: 4.1 Assy/Panel Removal 4.2 Set Re-assembly 4.1 Assy/Panel Removal Note:Please put your mechine on a soft material to avoid to scrape panel when you disassemble it. Front View Fig 3 Step 4.
TPM1.0U LA 4. Mechanical Instructions Step 7. Remove Metal frame Unscrew sixteen screws as fig 8 In warranty, it is not allowed to disassembly the LCD panel, even the backlight unit defect. Out of warranty, the replacment of backlight unit is a correct way when the defect is cused by backlight (CCFL,Lamp).
TPM1.0U LA 5. Service Modes, Error Codes and Fault Finding 5. Service Modes, Error Codes and Fault Finding index of this chapter: 5.1 CSM 5.2 Factory Mode 5. 3 Repair Flow Chart 5.1 CSM It can display CSM windows message when press 1-2 3-6 5-4 on the button (RC) remote control in normal operation mode. The following information is displayed on screen: CSM Item Contents...
Page 12
TPM1.0U LA 5. Service Modes, Error Codes and Fault Finding 5.2 Factory Mode It can enter Factory Mode 1. Press" Menu" in normal operation mode to enter OSD. 2. Press "062596+Menu" on the button (RC) remote control in OSD. 3. Press "Menu" again. The screen will appear "FAC" in top right corner. OSD behavior: Before press number key change OSD item Now remove previous function, press number key then press OK will change value...
TPM1.0U LA 5. Service Modes, Error Codes and Fault Finding 39 VIDEO_PWM_NORMAL 0~255 Pass 40 VIDEO_PWM_MEDIUM 0~255 Pass 41 VIDEO_PWM_MAXIMUN 0~255 Pass 42 VGA_PWM_MIN to limit PC brightness range 0~255 Dark Pass 43 VGA_PWM_MAX 0~255 Bright Pass //YPbPr H/V Position (value different by each timing) 44 YPBPR_POS_H Pass...
Page 14
TPM1.0U LA 5. Service Modes, Error Codes and Fault Finding 5.3 Repair Flow Chart 1.No work/LED is off Check if power switch is Replace Power switch normal Check IR board CN001 pin1=0V,pin2=3.7V, Check IR board pin3=3V,pin4=2.85V ,pin5=5V,pin6 =3.3V Check scaler board U102 pin1=14V,pin4=1.22V, pin7=16V,pin8=5V, 2.No raster/picture too...
Page 15
TPM1.0U LA 5. Service Modes, Error Codes and Fault Finding 3.No picture/LED is green Check scaler board U102 Check power pin1=14V,pin4=1.22V, pin7=16V,pin8 Check circuit around Check if each regulator and working voltage eliminate short and U152,pin2=3.3V open situation pin3=5V Check if clock Replace X350 source X350 Check if...
Page 16
TPM1.0U LA 5. Service Modes, Error Codes and Fault Finding 4.No TV sound Check if tuner TU201 pin11 Replace TU201 output IF signal Check U301 5.No earthphone sound Check Eliminate short and open U760 pin15=3.3V situation Check U760 pin20=HPOUTL Replace U760 pin6=HPOUTR Replace Side AV Board...
Page 17
TPM1.0U LA 5. Service Modes, Error Codes and Fault Finding 6.No remote function Tty another Replace one good remote control remote control Check IR receiver 7.LED and function key poor Check circuit around control board and cable between control board and scaler board 8.No HDMI picture Invalid Change U701 writen...
7. Circuit Diagrams and PWB Layouts TPM1.0U LA Scaler Board Schematic Diagram-PIN STATUS DEFINITION PWR PINS STATUS S-18 OPWRSB OPCTRL0 OPCTRL1 OPCTRL2 OPCTRL3 OPCTRL4 OPCTRL5 OPCTRL6 OPCTRL7 Net name OPWRSB LED_G PWR_ON/OFF MUTE PWR_S2 STAND_BY DVD_LED PWR_S6 LED_A DVD LED +5V_SW/+2V6 LED green Panel_Vcc...
Page 39
7.Circuit Diagrams and PWB Layouts TPM1.0U LA Scaler Board Layout...
Page 40
7. Circuit Diagrams and PWB Layouts TPM1.0U LA Scaler Board Layout-(TOP LEFT)
Page 41
7.Circuit Diagrams and PWB Layouts TPM1.0U LA Scaler Board Layout(TOP RIGHT)
Page 42
7. Circuit Diagrams and PWB Layouts TPM1.0U LA Scaler Board Layout-(BUTTOM LEFT)
Page 43
7.Circuit Diagrams and PWB Layouts TPM1.0U LA Scaler Board Layout(BUTTOM RIGHT)
Page 44
7. Circuit Diagrams and PWB Layouts TPM1.0U LA Scaler Board Layout-2...
Page 45
7.Circuit Diagrams and PWB Layouts TPM1.0U LA Scaler Board Layout-2(TOP LEFT)
Page 46
7. Circuit Diagrams and PWB Layouts TPM1.0U LA Scaler Board Layout-2(TOP RIGHT)
Page 47
7.Circuit Diagrams and PWB Layouts TPM1.0U LA Scaler Board Layout-2(BUTTOM LEFT)
Page 48
7. Circuit Diagrams and PWB Layouts TPM1.0U LA Scaler Board Layout-2(BUTTOM RIGHT)
7. Circuit Diagrams and PWB Layouts TPM1.0U LA IR Board Schematic Diagram(26",32") LED STATUS Standby Power on Pc power saveing FUCTION (Blank) (Green) (Red) LED_G Net name LED_A LED_A LED_G LED_A LED_G +5V_STB state High High High CN001 C1 C001 C3 C002 C2 R006 R007...
7.Circuit Diagrams and PWB Layouts TPM1.0U LA IR Board Schematic Diagram(37",42") Standby Pc power saveing Power on FUCTION (Blank) (Green) (Red) POWER Net name LED_A LED_G LED_A LED_G LED_G LED_A SW002 +5V_STB state High High High CN001 C2 C001 C3 C002 C2 C003 C3 R006...
Page 73
7.Circuit Diagrams and PWB Layouts TPM1.0U LA DVD LED Board Layout(26MD357,32MD357) C080 B2 CN081 A1 C081 A1 LED080 B3 C082 A1 SW080 B2 Q080 B3 R080 A2 R081 B2 R082 B2 ZD080 B2 ZD081 B2...
Page 74
TPM1.0U LA 8. Alignments 8. Alignments Index of this chapter: 8.1 Electrical Instructions 8.2 ISP Instructions 8.3 Serial Number Definition 8.4 WriteMTK_CSM_No_HDCP and WriteMTKHDCPKey Instructions Notes: You could adjust the LCD/TV following this chapter when the LCD/TV has the below defect. 1.
Page 75
TPM1.0U LA 8. Alignments to adjust the clock until no stripe and adjust the phase until clear picture. ("Auto"will be done every time switching to PC mode and mode change) Check all preset 6 modes. 8.1.2.2 WHITE-D adjustment (B) General set-up : Equipment Requirements: Minolta CA-110 or Equivalent Color analyzer Chroma 2250 or equivalent PC signal generator Input requirements:...
Page 76
TPM1.0U LA 8. Alignments 8.1.3. YPbPr mode display adjustment 8.1.3.1 White Balance adjustment (B) General set-up : Equipment Requirement: Minolta CA-110 or Equivalent Color analyzer Quantum Data Pattern Generator 801GD or 802G or Fluke 54200 Input requirements: Input Signal Type : YPbPr signal 1.1080i mode, SMPTE color pattern by 801GD or 802G.or 576i (PAL system), color bar with black/white pattern by Fluke 54200.
Page 77
8. Alignments TPM1.0U LA 8.1.3.2 Check grayscale Apply gray pattern. Check the color poor & noise condition of gray pattern 8.1.4. HDMI mode display adjustment 8.1.4.1 White Balance adjustment (B) General set-up : Equipment Requirement: Minolta CA-110 or Equivalent Color analyzer Quantum Data Pattern Generator 802BT or 881 Input requirements: Input Signal Type...
Page 78
TPM1.0U LA 8. Alignments Alignment: 1. Set color temperature to "NORMAL". 2. Copy CLR_TEMP_R, CLR_TEMP_G and CLR_TEMP_B values from "NORMAL" color temperature in Analog TV mode. Check whether (x,y) color coordinates meet "NORMAL" color specification below. If color coordinates are out of specification, fine-tune CLR_TEMP_R, CLR_TEMP_G and CLR_TEMP_B values.
8.2 Software Upgrading 8.2.1 ComPair Introduction ComPair (Computer Aided Repair) is a Service tool for Philips Consumer Electronics products. and offers the following: 1. ComPair features TV software upgrade possibilities. 2. ComPair helps you to quickly get an understanding on how to repair the chassis in a short and effective way (this feature is not supported in this chassis).
TPM1.0U LA 8. Alignments 8.3 Serial Number Definition BOM Code Panel Supplier Code LPL(LG) BOM Code: PANEL SUPPLIER CODE PANEL SUPPLIER CODE LPL(LG) B Z 2 A 0 6 5 1 0 0 0 0 0 1 Serial number (6 digits) Production year/week code Service version change code BOM (bill of Material) code...
TPM1.0U LA 8. Alignments 8.4 WriteMTK_CSM_No_HDCP and WriteMTKHDCPKey Instructions Instructions(write Project name and S/N) WriteMTK_CSM_No_HDCP Use USB port connecting PC & MT537x Board via ISP board. To PC USB Port Use Desktop PC or Notebook USB Port F3 ISP Board (USB to RS232) RS232 Cable USB Cable...
Page 82
TPM1.0U LA 8. Alignments 32MF337B/27 If there is no error, program will display OK: Program will save information to file MTK_CSM_200612.log ("200612" according to year and month). Content of file lists below: Set Type Production Code Execution time Date 32MF337B/27 15MF237S/37 BZ000651123456 2006-12-20...
Page 83
TPM1.0U LA 8. Alignments Command Setting page: In "Command Setting" page, "RS232 Config" can select COM port and baud rate. For MTK project, please select 115200 baud rare. After you select the COM port, you can press button to test whether it is available or not. In right hand checkbox, , if TV set is support E0, E1 command: Write-EEPROM command format is 58 E0 number high_addr low_addr data1 data2.
Page 84
TPM1.0U LA 8. Alignments Scan Model Number group: Store Model No. string to the address 7C0 (test OK 2006-11-24) in EEPROM (hex number, total 16 bytes). This information can be seen "Set Type" in CSM mode. You can press "1 2 3 6 5 4" to check it. The "Model No.
Page 85
TPM1.0U LA 8. Alignments WriteMTKHDCPKey Instructions(write Project name, S/N and HDCP KEY) To PC USB Port Use USB port connecting PC & MT537x Board via ISP board. Use Desktop PC or Notebook USB Port F3 ISP Board (USB to RS232) RS232 Cable MT537x USB Cable...
Page 86
TPM1.0U LA 8. Alignments If we set "Check HDCP key saved in EEPROM" (please see Config-> EEPROM page setting), and program find TV set have stored HDCP key, then program will display message and end sequences: If there is no error, program will display OK: Program will save information to file MTK_HDCP_200611.log ("200611"...
Page 87
TPM1.0U LA 8. Alignments Command Setting page: In "Command Setting" page, "RS232 Config" can select COM port and baud rate. For MTK project, please select 115200 baud rare. After you select the COM port, you can press button to test whether it is available or not. In right hand checkbox, , if TV set is support E0, E1 command: Write-EEPROM command format is 58 E0 number high_addr low_addr data1 data.
Page 88
TPM1.0U LA 8. Alignments Scan Model Number group: Store Model No. string to the address 7C0 (test OK 2006-11-24) in EEPROM (hex number, total 16 bytes). This information can be seen "Set Type" in CSM mode. You can press "1 2 3 6 5 4" to check it. The "Model No.
Page 89
TPM1.0U LA 8. Alignments You can press button to set main or backup directory that stores HDCP key files. After you press button: You can select driver and the select directory to check whether the directory contains HDCP key files. Key file name must be "enc_*.bin" format and file size is 320 bytes.
TPM1.0U LA 9. Circuit Descriptions, Abbreviations List and IC Data Sheets 9. Circuit Descriptions, Abbreviations List and IC Data Sheets Index of this chapter 9.1 Circuit Descriptions 9.2 Abbreviations List 9.3 IC Data Sheets 9.1 Circuit Descriptions This is a new TV chasis, specifically developed for NTSC/ATSC/QAM reception.The key components are : MT537x:DTV backend decoder and TV controller(MT5371 for WXGA&MT5373 for full HD).
TPM1.0U LA 9. Circuit Descriptions, Abbreviations List and IC Data Sheets 9.2 Abbreviations List Customer Service Mode ATSC Advanced Television Systems Committee, the digital TV standard in the USA Digital Versatile Disc EEPROM Electrically Erasable and Programmable Read Only Memory 3DNR Temporal (3D) Noise Reduction Automatic Gain Control: algorithm that controls the video input of the feature box...
Page 92
Scan mode where two fields are used to form one frame. Each field contains half the number of Interlaced the total amount of lines. The fields are written in "pairs", causing line flicker. Infra Red Interrupt Request LATAM Latin America Liquid Crystal Display Light Emitting Diode LG.Philips LCD (supplier) MUTE MUTE Line...
Page 93
TPM1.0U LA 9. Circuit Descriptions, Abbreviations List and IC Data Sheets Thin Film Transistor SRAM Static RAM STBY STandBY Sync On Green SVGA 800x600 (4:3) SVHS Super Video Home System Software SWAN Spatial temporal Weighted Averaging Noise reduction SXGA 1280x1024 TMDS Transmission Minimized Differential Signalling UXGA...
TPM1.0U LA 9. Circuit Descriptions, Abbreviations List and IC Data Sheets 9.3 IC Data Sheets This section shows the internal block diagrams and pin configurations of ICs that are drawn as "black boxes" in the electrical diagrams (with the exception of "memory" and "logic" ICs). 9.3.1 IC Data Sheets-LP2996(U503) Typical Application Circuit Pin Configuration...
Page 95
TPM1.0U LA 9. Circuit Descriptions, Abbreviations List and IC Data Sheets 9.3.2 IC Data Sheets-TPA3005D2(U801) FUNCTIONAL BLOCK DIAGRAM Pin Configuration...
Page 96
TPM1.0U LA 9. Circuit Descriptions, Abbreviations List and IC Data Sheets 9.3.3 IC Data Sheets-TPS5420(U102) Function Diagram Pin Configuration Pin Configuration 9.3.4 IC Data Sheets-MT5112BD(U250)
Page 97
TPM1.0U LA 9. Circuit Descriptions, Abbreviations List and IC Data Sheets Pin Configuration 9.3.5 IC Data Sheets-MT5371AJ(U301)
Page 98
9. Circuit Descriptions, Abbreviations List and IC Data Sheets TPM1.0U LA PIN ASSIGNMENT (MT5372, MT5371)
Page 99
TPM1.0U LA 9. Circuit Descriptions, Abbreviations List and IC Data Sheets 10/31...
Page 100
TPM1.0U LA 9. Circuit Descriptions, Abbreviations List and IC Data Sheets 9.3.6 IC Data Sheets-HY5DU561622ETP-5(U501) Function Diagram Write Data Register LDQS, UDQS 2-bit Prefetch Unit LDM, UDM Bank 4Mx16 / Bank0 Control /CLK 4Mx16 / Bank1 Command Decoder 4Mx16 / Bank2 /RAS /CAS DQ[0:15]...
Page 101
TPM1.0U LA 9. Circuit Descriptions, Abbreviations List and IC Data Sheets 9.3.7 IC Data Sheets-S29AL032D(U350) Function Diagram DQ0 DQ15 (A-1), (DQ0-DQ7 Model 00) RY/BY# Sector Switches Erase Voltage Input/Output RESET# Generator Buffers State Control BYTE# Command Register PGM Voltage Generator Data Chip Enable Latch...
Page 102
TPM1.0U LA 9. Circuit Descriptions, Abbreviations List and IC Data Sheets Pin Configuration RESET# 40-pin Standard TSOP RY/BY#...
Page 103
TPM1.0U LA 9. Circuit Descriptions, Abbreviations List and IC Data Sheets BYTE# DQ15/A-1 DQ14 DQ13 48-pin Standard TSOP DQ12 RESET# DQ11 WP#/ACC RY/BY# DQ10...
10.Recommended/Spare Parts List Index of this chapter 10.1 Recommended Parts List 10.2 Spare Parts List 10.1 Recommended Parts List Type:32MF337B/27(LPL) Item Philips 12NC Description TPV 18NC 9965 000 43787 DFU ASSY 705TZE01003 9965 000 43788 METAL FRAME-R ASSY 705TZE15003 9965 000 43789 METAL FRAME-L ASSY...
