Instructions for installation and use
IKI electric heaters
with Finlandia control unit

Pillar IKI 4,5 kW
Pillar IKI 6 kW
Pillar IKI 7,5 kW
Pillar IKI 9 kW
Pillar IKI 10 kW



10/2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pillar IKI 4,5 kW and is the answer not in the manual?

Questions and answers

Summary of Contents for IKI Pillar IKI 4,5 kW

  • Page 1 Instructions for installation and use IKI electric heaters    with Finlandia control unit    Pillar IKI 4,5 kW  Pillar IKI 6 kW  Pillar IKI 7,5 kW  Pillar IKI 9 kW  Pillar IKI 10 kW        10/2016 ...
  • Page 2  Read through this installation manual before you begin the installation of the heater.  The warranty does not cover defects caused by faulty installation or misuse of the heater. CONTACTS IKI-Kiuas Oy Technical support Vallila pick up & Production / Pieksämäki Hakaniemenkatu 11...
  • Page 3: Table Of Contents

    Safety distances Requirements for water quality Circuit diagram Supporting the heater against a wall Warranty Quality guarantee / Freight guarantee The terms of warranty for IKI-Kiuas Ltd regarding Finlandia control unit______________16 Mechanical ventilation 17-18 Warnings Instructions for use Trouble-shooting Instructions for installation and use | IKI electric heaters with Finlandia control unit Page   3 ...
  • Page 4: Operating The Control Unit

    The light is off when the heater is off. Goal temperature indicator. When this light is illuminated you can adjust the goal temperature. Menu setting indicator. When this light is illuminated you can adjust the settings in the menu: timer, operating time, temperature. 3-digit display. Instructions for installation and use | IKI electric heaters with Finlandia control unit Page   4 ...
  • Page 5 ( ˄/+ ) or ( ˅/‐ ) buttons to reduce or increase the operating time. The adjustment range is 15 minutes. This setting will not be stored in the device's memory. The setting can be readjusted by pressing the menu button twice.   Instructions for installation and use | IKI electric heaters with Finlandia control unit Page   5 ...
  • Page 6 Tip: If the timer has been set but the heater is not switched on yet, it is possible to bypass the timer by keeping the on/off button pressed down for a few seconds. The heater will begin heating immediately. The timer setting will be stored in the device's memory. Instructions for installation and use | IKI electric heaters with Finlandia control unit Page   6 ...
  • Page 7: Installation

    6. Temperature drop (connector J5) (If this option is available, the connector can be linked to the relay or the contactor coil that drives the heating in the building) a. P - External - Brown b. N - 230VAC OUT – Blue     Instructions for installation and use | IKI electric heaters with Finlandia control unit Page   7 ...
  • Page 8: Installation Of The Thermostat Sensor

    Affixing the sensor to the ceiling: • distance from heater frame 100–400 mm The temperature sensor should be installed no less than 1000 mm from an undirected air vent income, or less than 500 mm from a directed air vent. Instructions for installation and use | IKI electric heaters with Finlandia control unit Page   8 ...
  • Page 9: Installation Of The Thermostat And Control Panel

    Installation of the thermostat and control panel A. distance from heater frame 100–400 mm. B. Thermostat sensor distance from the ceiling 100 C. Control panel distance from the heater min. 500 D. Installation height from the floor max. 1000 mm Instructions for installation and use | IKI electric heaters with Finlandia control unit Page   9 ...
  • Page 10: Installation Of The Control Panel

     Note that the mounting box is not delivered with the heater. You can use boxes such as ABB wall plate mounting box AUS-15. 2p. Mounting boxes are sold in all well-equipped hardware stores. Instructions for installation and use | IKI electric heaters with Finlandia control unit Page   10 ...
  • Page 11: Piling Of The Stones

    10 cm 10 cm 80 cm Pillar IKI 9 kW 10 cm 10 cm 10 cm 80 cm Pillar IKI 10 kW 10 cm 10 cm 10 cm 80 cm * Corner IKI can be installed in the corner Instructions for installation and use | IKI electric heaters with Finlandia control unit Page   11 ...
  • Page 12: Requirements For Water Quality

    Color, taste, precipitates <0,2 mg/l Iron concentration Color, smell, taste, precipitates Hardness: most important substances are Precipitates Mn: <0,05 mg/l manganese (Mn) and lime, i.e. calsium (Ca) Ca: <100 mg/l Risk to health Chlorinated water Forbidden Seawater Fast corrosion Forbidden Instructions for installation and use | IKI electric heaters with Finlandia control unit Page   12 ...
  • Page 13: Circuit Diagram

    Circuit diagram Instructions for installation and use | IKI electric heaters with Finlandia control unit Page   13 ...
  • Page 14: Supporting The Heater Against A Wall

    Supporting the heater against a wall Option 1, corner installation: Supporting beam  HEATER  Supporting beam  Option 2, wall-installation: Supporting beam  HEATER  Supporting beam  Instructions for installation and use | IKI electric heaters with Finlandia control unit Page   14 ...
  • Page 15: Warranty

    Warranty IKI-Kiuas Ltd (the manufacturer) assures a warranty to its products as stipulated here, guaranteeing the quality and functionality of the products during the warranty period. The warranty applies to heaters sold and used in Finland. The warranty requires that the buyer follow the instructions regarding the placement of the heater, its installation, use and maintenance as well as those regarding the qualities of the stones used in the heater.
  • Page 16: Quality Guarantee / Freight Guarantee

    The warranty applies only to transactions between Starsauna Ltd and IKI-Kiuas Ltd, and shall not be directly applied to consumers. IKI-Kiuas Ltd must draw up separate terms of warranty regarding the sales of its sauna heaters.
  • Page 17: Mechanical Ventilation

    - Primarily, warranty and repair matters will be handled between Starsauna Ltd and IKI-Kiuas Ltd. Starsauna Ltd is not obliged to instruct third-parties in repair or troubleshooting issues. The buyer is responsible for arranging technical support itself for the products it sells.
  • Page 18: Warnings

    Sea-air and a humid climate may corrode the metal surfaces of the heater. Do not hang clothes to dry in the sauna, as this may cause a risk of fire. Excessive moisture content may also cause damage to the electrical equipment. Instructions for installation and use | IKI electric heaters with Finlandia control unit Page   18 ...
  • Page 19: Instructions For Use

    The heating time is about 45–75 minutes depending on the size of the room and its ventilation. Recommended temperature for IKI stone pillars is 50–70 degrees. Pouring water on the heater increases temperature and humidity. You can control the heat and humidity by pouring the water to different parts of the heater.
  • Page 20   Copyright IKI‐Kiuas Oy | Pidätämme oikeudet muutoksiin  Instructions for installation and use | IKI electric heaters with Finlandia control unit Page   20 ...
