LS SV-xxx-iP5A-2 Manual

Variable frequency drives starvert ip5a series
Hide thumbs
Table of Contents

Advertisement

Quick Links

Thank you for purchasing LS Variable Frequency Drives!
To prevent injury and property damage, follow these instructions during the
installation and operation of the inverter.
Incorrect operation due to ignoring these instructions may cause harm or damage.
The following symbols are used throughout the manual to highlight important
information.
DANGER
WARNING
CAUTION
■ The meaning of each symbol in this manual and on your equipment is as
follows.
This is the safety alert symbol.
Read and follow instructions carefully to avoid a dangerous situation.
This symbol alerts the user to the presence of "dangerous voltage" inside the
product that might cause bodily harm or electric shock.
■ This manual should be placed in a location where it can be accessed by users.
■ This manual should be given to the person who actually uses the inverter and is
responsible for its maintenance.

SAFETY INSTRUCTIONS

This symbol indicates death or serious injury can
occur if you do not follow instructions.
This symbol indicates the possibility of
death or serious injury.
This symbol indicates the possibility of
damage to the inverter or other components.
Safety Instructions
i
