nVIDIa 3D VIsIon UseR GUIDe

3D Vision Pro Hub

The 3D Vision Pro Hub connects to your system with the included Usb
cable. The emitter has a back-lit button on the front that can be used
to control the pairing with the glasses. The indicator brightens when
stereoscopic 3D is on.
There is a thumbwheel on the back of the emitter that can be used to
increase/decrease depth in some Direct3D based applications.
Note: Usb extenders and Vesa sync extenders have been
tested and qualified for use with the 3D Vision Pro Hub. Con-
tact nVIDIa or your reseller for the list of qualified adaptors.
Hub Control button and light
dim green: stand by
bright green: operational
....flashing light blue/green: pairing
Thumbwheel to adjust stereoscopic
depth in-games
Vesa stereo sync connection
Power/sync status indicator light
green: power on
blue: Vesa stereo sync active
Usb connection to your computer
