- Page 1 PORTACOOL CYCLONE OWNER ’ S MANUAL PAC2KCYC01, PACCYC02, PACCYC03, PACCYC04, PACCYC06...
-
Page 2: Quick Setup
PACCYC02, PACCYC03, wet before starting the fan. The water adjustment PACCYC04 valve on each Portacool portable evaporative cooler is set at max flow. However, ensure the knob is turned Models: PACCYC06 completely to the right before use. Turn to the left to increase water flow. -
Page 3: Operation Warnings
Refer to the warranty, troubleshooting • Test the GFCI/GLCI receptacle or breaker monthly to ensure it or FAQ sections of this Owner’s Manual, call Portacool, LLC is functioning properly. Technical Support at 1-888-266-5243, or email •... - Page 4 OVERVIEW CYCLONE 3000 CYCLONE 2000 CYCLONE 1000 Adjustable Adjustable louvers louvers Adjustable KUUL KUUL louvers evaporative evaporative media media Power cord KUUL evaporative Water level Water level media Water level sight tube sight window sight tube Drain located Drain located Drain located in back underneath...
- Page 5 OVERVIEW CYCLONE 2200 CYCLONE 3200 Adjustable Adjustable louvers louvers KUUL KUUL evaporative evaporative media media Water level Water level sight tube sight tube Drain located Drain located underneath in back Control panel Control panel Power cord Power cord Water adjustment Water adjustment valve valve...
-
Page 6: Starting The Pump And Adjusting The Water Flow
When turning the evaporative cooler off at the end of the day or week, the pump should be turned off about 15 minutes before the fan to allow the KUUL evaporative media to dry. ORDER PARTS STARTING THE PORTACOOL EVAPORATIVE COOLER ONLINE portacoolparts.com Start the fan by turning the fan switch to either the high or low position. -
Page 7: Daily Maintenance
WEEKLY MAINTENANCE Your Portacool portable evaporative cooler should be shut down and the tank should be drained once a week. Closing the water adjustment valve and removing the drain plug will accomplish this. Once the tank is drained and the power disconnected, the KUUL evaporative media may be removed to allow cleaning of the tank, where dust may collect over time. -
Page 8: Troubleshoot
TROUBLESHOOT Turn off all power to your evaporative cooler before attempting to troubleshoot any of the following symptoms. For problems not listed, please contact customer service. REMEDY SYMPTOM POSSIBLE CAUSES 1. Check power Evaporative cooler fails to 1. No electricity to the evaporative cooler A. - Page 9 TROUBLESHOOT REMEDY POSSIBLE CAUSES SYMPTOM 1. Drain, flush and clean tank 1. Stale or stagnant water in tank Musty or unpleasant odor 2. Replace KUUL evaporative media 2. KUUL evaporative media is mildewed or clogged 1. Make sure KUUL evaporative media 1.
-
Page 10: Warranty
Portacool replacement parts; iii) the product has been modified in any way (other than repairs made by qualified individuals with Portacool replacement parts); iv) the product has not been appropriately registered by its original purchaser;... - Page 11 Q. What is the best environment to product the most cool air from my Portacool portable evaporative cooler? A. None. Your Portacool portable evaporative cooler is ready to use right out of the box. A. For optimum performance, the temperature should be 85˚ F or higher and the relative humidity should be below 75%.
- Page 12 Serial numbers are all-digits. Q. What if my question is not answered here? A. Our U.S.-based Tech Support staff is available 8 a.m. to 5 p.m. Central Time, Monday though Friday at 1-888-COOL-AID or you can e-mail them at support@portacool.com.
- Page 13 HOW TO REPLACE YOUR KUUL EVAPORATIVE MEDIA Step 1 Be sure to unplug your Portacool portable evaporative cooler before doing any maintenance. Lock the casters to keep your evaporative cooler from moving while you are working. Remove the flap and KUUL evaporative media from the ®...
-
Page 14: Key Parts
KEY PARTS 1000 2000 2200 3000 3200 MOTOR-017-01 MOTOR-016-01 MOTOR-016-01 MOTOR-013-07B MOTOR-013-07B MOTOR PUMP-CYC-3 PUMP-CYC-3 PUMP-CYC-3 PUMP-CYC-3 PUMP-CYC-3 PUMP PADMF4022/G PAD6019/22 PAD6019/22 PAD6022.5/26 PAD6022.5/26 MEDIA LOCKING CASTER-3-L CASTER-3-L CASTER-3-L CASTER-3-L CASTER-3-L CASTERS (FRONT) NON-LOCKING CASTER-3-NL CASTER-3-NL CASTER-3-NL CASTER-3-NL CASTER-3-NL CASTERS (REAR) FRNTPNL-C1-7112 LOUVERS-CYC-11... - Page 15 REGISTER Please complete this form and mail in a stamped envelope to: Portacool, 711 FM 2468, Center, TX 75935 or register online at: PRIMARY USE: www.portacool.com/support Auto/Aviation Farm/Pet Industrial Hospitality Home Other DATE OF PURCHASE PRIMARY REASON FOR PURCHASE: Safety...
- Page 16 NOTES...
- Page 17 NOTES...
- Page 18 NOTES...
-
Page 19: Customer Service Contact
Pour télécharger une copie numérique, se il vous plaît visitez www.portacool.com. VISIT PORTACOOL.COM والدليل هو متاح في اللغات الأخرى. لتحميل OR CALL 1-936-598-5651 www.portacool.com نسخة رقمية، يرجى ز يارة FOR MORE INFORMATION Portacool, LLC • Manufacturer of Portacool™ portable evaporative coolers and KUUL evaporative media ®...
