MC909X
User Guide

Advertisement

Table of Contents
loading

Related Manuals for Symbol MC909X

Summary of Contents for Symbol MC909X

  • Page 1 MC909X User Guide...

  • Page 2: Using Mc9094 Phone

    Using MC9094 Phone Chapter Contents...

  • Page 3: Accessing The Phone Keypad

    MC909X User Guide Introduction Accessing the Phone Keypad The keypad can be accessed regardless of the program in use on the mobile computer. Applications on the mobile computer can be in use during a call. Antenna/Signal Figure 4-1. MC9094 Phone Keypads Keypads can vary depending on services and the state of the phone.

  • Page 4: Muting A Call

    Using MC9094 Phone 4-3 To answer an incoming call tap Answer on the Phone - Incoming... dialog or press the green dot key on the mobile computer keypad. Figure 4-2. Incoming Call To ignore the incoming the call tap Ignore. This may send the caller to voice mail, depending on the service provider. To end the call tap End or press the red dot key on the mobile computer keypad.

  • Page 5: Using Speed Dial

    MC909X User Guide To access a note created during a call: 1. Tap Start - Phone or press the green dot key on the mobile computer’s keypad. 2. From the Phone keypad, tap Call History. 3. Tap and hold the number or the Note icon for the phone call entry containing the note.
  • Page 6 Using MC9094 Phone 4-5 1. Ensure the contact and phone number are in the Contacts list. 2. Tap Start - Phone or press the green dot key on the mobile computer’s keypad. 3. Tap Speed Dial - Menu -New. Figure 4-6. Contacts 4.
  • Page 7 MC909X User Guide 6. Tap ok to add the contact to the speed dial list. Figure 4-8. Speed Dial Contact List 7. Tap ok to exit the Speed Dial Contact List. To add a speed dial entry from the Contacts window: 1.
  • Page 8 Using MC9094 Phone 4-7 3. Tap Add to Speed Dial. Figure 4-11. Speed Dial Contact Location 4. Tap the Up/Down arrows to select an available location to assign as the new speed dial entry. The first speed dial location is reserved for voice mail. 5.
  • Page 9 MC909X User Guide 3. Tap and hold the contact name. Figure 4-13. Speed Dial Delete Menu 4. Tap Edit..5. Change the name, phone number or location information. 6. Tap ok. Editing names and phone numbers in Speed Dial does not alter contact information in Contacts (Start - Contacts).

  • Page 10: Making A Speed Dial Call

    Using MC9094 Phone 4-9 Deleting names and phone numbers in Speed Dial does not delete the contact information in Contacts (Start - Contacts). Making a Speed Dial Call Use Speed Dial to call someone saved in the speed dial directory. To make a speed dial call: 1.

  • Page 11: Managing Call History

    4-10 MC909X User Guide 1. Tap Start - Phone or press the green dot key on the mobile computer’s keypad. 2. From the Phone keypad, tap Call History. Phone icon Figure 4-16. Call History 3. Tap the phone icon next to the number to begin dialing and return to the phone keypad.
  • Page 12 Using MC9094 Phone 4-11 2. From the Phone keypad, tap Call History. 3. Tap Menu. Figure 4-18. Call History - Tools Menu 4. Select Call Timers... from the menu. Figure 4-19. Call History - Call Timers 5. Tap Reset. (The All Calls: counter cannot be reset.) 6.
  • Page 13 4-12 MC909X User Guide 4. Select Call Timers... from the menu. Figure 4-20. Call History - Call Timers 5. Under Delete call history items older than: tap the drop-down list and select a time period on which to base deletion of stored items.
  • Page 14 Using MC9094 Phone 4-13 Viewing Call Status 1. Tap Start - Phone or press the green dot key on the mobile computer’s keypad to display the Phone keypad. 2. From the Phone keypad, tap Call History. 3. Tap an entry in the list to see the date, time, and duration of a call. Figure 4-23.

  • Page 15: Using Contacts

    4-14 MC909X User Guide 5. Depending on the item selected, the appropriate window displays. For example, if Send SMS is selected, the Inbox window displays. 6. Tap ok to exit the Call History window. Using Contacts Use Contacts to make a call without having to look up or manually enter the phone number.

  • Page 16: Text Messaging

    Using MC9094 Phone 4-15 2. Enter the first phone number and press Talk. When the call is connected, Hold appears on the keypad. Figure 4-26. Call Conferencing - Hold 3. Tap Hold to place the first number on hold. 4. Enter the second number and tap Talk. When the call is connected, menu Conference appears on the keypad. Figure 4-27.

  • Page 17: Sending A Message

    4-16 MC909X User Guide Sending a Message To send a message: 1. Tap Start - Phone or press the green dot key on the mobile computer’s keypad to display the Phone keypad. 2. Tap Contacts. 3. Tap and hold on a contact and select Send Text Message. The Text Messages window appears.

  • Page 18: Editing Messages

    Using MC9094 Phone 4-17 5. Tap Send to send the message. Editing Messages Use the SMS Edit menu to edit, save, cancel and spell check messages. 1. Tap Start - Phone or press the green dot key on the mobile computer’s keypad to display the Phone keypad. 2.
  • Page 19 4-18 MC909X User Guide Table 4-2. SMS Edit Menu Options (Continued) Menu Option Description Options... Tap to display the Message Options window. Figure 4-31. Message Options Select the Request SMS text message delivery notification check box and tap ok to be notified when a text message is...
  • Page 20 Symbol Technologies, Inc. One Symbol Plaza Holtsville, New York 11742-1300 http://www.symbol.com 72E-72215-01 Rev. 1 May 2005...
