INTRODUCTION

Thank you for purchasing a Honda lawn mower.
This manual covers the operation and maintenance of the Honda
HRX537HXEA and HRX537HMEA lawn mowers.
We want to help you get the best results from your new mower and to
operate it safely. This manual contains the information on how to do
that; please read it carefully.
This manual should be considered a permanent part of the lawn
mower and should remain with it if it is resold.
If you have a problem or questions concerning the mower, contact
your supplying dealer.
We recommend that you read the warranty policy to fully understand
your rights and responsibilities. The warranty policy is a separate
document provided by your dealer.
Honda Power Equipment Mfg., Inc. reserves the right to make
changes at any time without notice and without incurring any
obligation.
No part of this publication may be reproduced without written
permission.

SAFETY MESSAGES

Pay special attention to statements preceded by the following words:
 DANGER
 WARNING
 CAUTION
Each message tells you what the hazard is, what can happen, and
what you can do to avoid or reduce injury.
Damage Prevention Messages
You will also see other important messages that are preceded by the
following word:
Your lawn mower or other property can be
NOTICE
damaged if you don't follow instructions.
The purpose of these messages is to help prevent damage to your
lawn mower, other property, or the environment.
© 2004-2007 American Honda Motor Co., Inc.-All Rights Reserved
39VH7H40
00X39-VH7-H400
You WILL be KILLED or SERIOUSLY
HURT if you don't follow instructions.
You CAN be KILLED or SERIOUSLY
HURT if you don't follow instructions.
You CAN be HURT if you don't follow
instructions.
POM53750-E
C1
IPC
xxxx.2007.08
PRINTED IN U.S.A.
OWNER'S MANUAL
MANUEL DE L'UTILISATEUR
MANUAL DEL PROPIETARIO
HRX537HXEA/HMEA
CONTENTS
INTRODUCTION . . . . . . . . . . . . 1
SAFETY MESSAGES . . . . . . . . 1
PLATE . . . . . . . . . . . . . . . . . . . 3
IDENTIFICATION . . . . . . . . . . . 3
SET-UP . . . . . . . . . . . . . . . . . . . 4
CONTROLS . . . . . . . . . . . . . . . . 4
OPERATION . . . . . . . . . . . . . . . 9
FOR MOWING. . . . . . . . . . . . 10
MOWING TIPS . . . . . . . . . . . 11
ENGLISH
MAINTENANCE . . . . . . . . . . . . 14
MAINTENANCE . . . . . . . . . . 14
ADJUSTMENTS . . . . . . . . . . 17
ADJUSTMENT . . . . . . . . . . . .16
INSTALLATION . . . . . . . . . . . 17
REPLACEMENT . . . . . . . . . . 18
SERVICE . . . . . . . . . . . . . . . . 18
TROUBLESHOOTING . . . . . . . 19
SPECIFICATIONS . . . . . . . . . . 20
Honda DISTRIBUTOR
ADDRESSES . . . . . . . . . Last page
1

Advertisement

Table of Contents
loading

Related Manuals for Honda HRX537HXEA

Summary of Contents for Honda HRX537HXEA

  • Page 1: Table Of Contents

    INTRODUCTION Thank you for purchasing a Honda lawn mower. This manual covers the operation and maintenance of the Honda OWNER’S MANUAL HRX537HXEA and HRX537HMEA lawn mowers. MANUEL DE L’UTILISATEUR We want to help you get the best results from your new mower and to operate it safely.

  • Page 2: Safety Instructions

    To ensure safe operation – mowed. • Never operate the lawn mower with defective guards or • Honda lawn mowers are designed shields, or without safety devices (for example, deflectors to give safe and dependable service if and/or grass catchers in place).

  • Page 3: Safety Label Location

    8. Model Directive 9. Manufacturer’s name and 3. Nominal power in kilowatts address [15] HONDA POWER EQUIPMENT MFG., INC. P.O. BOX 37, HONDA DRIVE, NC HWY. 119 [16] SWEPSONVILLE, N.C. 27359 U.S.A. [17] Handlebar 11 Blade control lever Shift lever...

  • Page 4: Set-Up

    SET-UP ENGINE OIL The mower is shipped WITHOUT OIL in the engine. UNPACKING Add enough SAE 10W-30 Remove all the cardboard from around the handlebar. API service category SJ or HANDLEBAR SETUP later oil to bring the oil level 1. Loosen the two between the upper limit [2] knobs [1] on the and lower limit [3] marks on...
  • Page 5 Throttle Lever Shift Lever The throttle lever The shift lever [1] selects and controls the mower’s drive [1] controls the speed. following functions: With the shift lever [1] all the way back [A] and the drive clutch lever engaged, the mower will move slowly or not at all.

  • Page 6: Pre-Operation Checks

    Methanol greater than shown above are not covered by warranty. When a blade needs sharpening or replacement, take the lawn mower to an authorized Honda dealer. Or, if you have a torque wrench, you can remove and install the blades yourself.
  • Page 7 4. Tighten the handlebar locking knobs securely.  WARNING Gasoline is highly flammable and explosive. You can be burned or seriously injured when handling fuel. • Stop the engine and keep heat, sparks, and flame away. • Handle fuel only outdoors. •...
  • Page 8 During normal use the rear shield is subject to deterioration and wear. Remove the grass bag and raise the discharge guard to check the rear shield for cracks or tears. If the rear shield is excessively worn, have it replaced by your authorized Honda servicing dealer. DISCHARGE GUARD [2] (50% open)

  • Page 9: Operation

    Maximum rear discharge 3. HXEA type:. will occur when the Clip Pull the starter grip [1] Director knob is all the way lightly until you feel to the left (BAG) position. resistance, then pull As the Clip Director knob is briskly.

  • Page 10: Operating The Controls For Mowing

    Do not use the throttle lever to the engine to overheat and result in serious engine damage. For use adjust your forward speed. at low altitudes, have your authorized Honda dealer return the The throttle lever must remain carburetor to original factory specifications.

  • Page 11: Safe Mowing Practices

    3. When the mower is not in use, turn the fuel valve to the OFF  WARNING position. A worn, cracked, or damaged blade can break, and pieces of the damaged blade can become dangerous projectiles. Thrown objects can cause serious injury. Inspect the blade regularly, and do not operate the mower with a worn or damaged blade.

  • Page 12: Transporting/Storage

    Clear a clogged deck with a stick, not your hands. Mowing Patterns Your Honda mower will work most efficiently if you use the following mowing patterns as much as possible. Mower deck and equipment Handlebar Folding design, and the direction in which the blades rotate, cause these mowing patterns to give the best results.
  • Page 13 Charging the Battery (HMEA type) NOTICE To assure maximum reliability, the battery should be recharged (boost To prevent losing control of or damaging the mower, do not use the charged) both before and after prolonged storage. A plug-in charger is drive system when going up or down a loading ramp.

  • Page 14: Maintenance

    Keep cigarettes, sparks, and flames away from all fuel-related parts. THE IMPORTANCE OF MAINTENANCE Remember that your Honda dealer knows your mower best and is Good maintenance is essential for safe, economical, and trouble-free fully equipped to maintain and repair it.

  • Page 15: Maintenance Schedule

    1. Service more frequently when used in dusty areas. the low level mark [3], add oil to reach the high 2. These items should be serviced by an authorized Honda servicing limit mark [2] on the dealer, unless you have the proper tools and are mechanically dipstick.
  • Page 16 1. Press down on the 3. Inspect the spark plug. Replace it air cleaner cover [1] if the electrodes are worn or if the 0.7 ~ 0.8 mm tabs, and then insulator is cracked or chipped. remove the cover. Clean the spark plug with a wire brush if you are going to reuse it.

  • Page 17: Control Cable Adjustments

    If the mower does not staff at an authorized Honda dealer. operate as outlined above, go to step 5. BLADE REPLACEMENT: Use Honda Genuine replacement blades or If the mower does operate as outlined above, adjustment is their equivalent. not required.

  • Page 18: Grass Bag Cleaning And Replacement

    This will Replacement help to prevent fuel leakage and hard starting due to carburetor flooding. Replace a worn or damaged bag with a Honda replacement bag or its equivalent. Removal 1. Unclip the plastic edges [1] of the bag [2] from the frame [3].

  • Page 19: Troubleshooting

    If a frequent fuse failure occurs, it usually indicates a short circuit or an overload in the electrical system. Take the mower to an authorized Honda servicing dealer for repair. 3. Connect the battery connector [3] to the charger [6] supplied with the mower.

  • Page 20: Specifications

    SPECIFICATIONS Fuel filter clogged, carburetor Take the mower to an authorized malfunction, ignition malfunction, Honda servicing dealer or refer to the valves stuck, etc. shop manual for repair. MODEL HRX537C1 LOSS OF POWER TYPE HXEA HMEA DESCRIPTION CODE MAGA Possible Cause...
  • Page 21 Website : www.honda.fr http://www.honda.nl http://www.as-domzale-motoc.si BELGIUM GERMANY NORWAY SPAIN Honda Motor Europe (North) Honda Motor Europe (North) GmbH Berema AS Greens Power Products, S.L. Doornveld 180-184 Sprendlinger Landstraße 166 P.O. Box 454 Avda. Ramon Ciurans, 2 1731 Zellik 63069 Offenbach am Main...
  • Page 22 Printed on Recycled Paper...
