- Page 1 AC Voltage detector User Guide Guide de l’utilisateur Bedienungsanleitung Guía del usuario...
-
Page 2: Gsafety Warnings
SAFETY WARNINGS The VF3 Voltage detector may help in the indication of live AC circuits only, and must not be used as verification of a de-energised circuit. This is not a safety test lamp. If damaged, do not use. This instruction guide and markings on the detector provide information for avoiding hazards and unsafe practices related to the use of this tool. -
Page 3: Weee Directive
The crossed out wheeled bin symbol on the instrument and on the batteries is a reminder not to dispose of them with general waste at the end of their life. Megger is registered in the UK as a Producer of Electrical and Electronic equipment. The registration no is; WEE/DJ2235XR. -
Page 4: Battery Disposal
Users of Megger products in the UK may dispose of them at the end of their useful life by contacting B2B Compliance at www.b2bcompliance.org.uk or by telephone on 01691 676124. Users of Megger products in other parts of the EU should contact their local Megger company or distributor. - Page 5 DESCRIPTION The Megger VF3 voltage detector is intended to check for the presence of AC voltage, signaled by a bright red LED situated within the white nylon tip and an audible buzzer. The VF3 has the added advantage of a bright-white LED flashlight for use in poor light.
-
Page 6: Good Practice
If the unit still fails to operate satisfactorily, return for repair. If the unit does not function as expected , replace the batteries. NOTE: The VF3 cannot detect voltage on armoured or sheathed cable, or on cable in conduit, behind panels or in metallic enclosures. -
Page 7: Battery Replacement
BATTERY REPLACEMENT „ Remove the unit from proximity of any live circuits „ Turn off flashlight „ Remove battery cap (1) by lifting clip (2) slightly and pulling cap (1) off body (3) „ Replace batteries, carefully observing correct type and polarity „... -
Page 8: Specifications
SPECIFICATIONS INDICATORS: OPTICAL VIA LED AND ACOUSTICAL VIA BUZZER Voltage range: 90 - 600 V AC 50/60 Hz Operating temp: -10°C - 50°C Humidity: Max. 90% Safety: EN61010-1:2010 EMC: EN61326 Safety Rating: CAT IV 600 V Battery: 2 x AAA / LR03 Size: 178 mm x 26 mm Weight:... - Page 9 LED. APPLICATION The VF3 can be used for identifying the presence of ac voltage at socket outlets, switches, circuit breakers, fuses, luminaries, wires and cables. It can identify breaks in conductors by tracing along the cable from the source to the point where the indicator no longer illuminates;...
- Page 10 Safety CAT IV 600 V Compliance EN 61010-1:2010 ORDERING INFORMATION Description Order Code Box of 12 VF3 voltage detectors 2004-780 UNITED STATES OTHER TECHNICAL SALES OFFICES CERTIFICATION ISO Archcliffe Road Dover 4271 Bronze Way Valley Forge USA, College Station USA, Registered to ISO 9001:2000 Cert.
