Infinition Labradar User Manual page 5

4.2 Configuration Menu definitions
When the Display/Parameters
Menu selection
Velocity Units
Distances units.
Weight units
Select vel. range
Set proj. offset
Set distances
Proj. Weight
Arm time
Screensaver:
Infinition Inc. Rev. 02
button is pressed, a menu appears. The following options are available:
Description
Change the units used when displaying velocity measurements, the user can
choose from the following units:
 Feet per second (fps);
 Yards per second (yps);
 Miles per hour (mph);
 Meters per second (m/s);
 Kilometers per hour (Km/h).
Change the units used when displaying distance measurements, the user can
choose from the following units:
 feet (ft);
 yards (yd);
 meters (m).
Change the units used to enter the weight of the projectile, the user can
choose from the following units:
 gram (g);
 grain (gr).
Select the velocity range for measurements by the LabRadar. Each velocity
range is specified to weapons type as a reference:
 Rifle (300m/s to 1050m/s);
 Handgun (75m/s to 525m/s);
 Archery (20m/s to 225m/s).
Input the distance between the gun's muzzle and the side of the radar to
optimize the precision of the measurements.
Specify the distances at which the velocity measurements are made. Dx1 to
Dx5.
Set the projectile's weight of the next shot. This value is used in some
calculations (Power Factor, Kinetic Energy) and written on the file on the SD
Card for future reference.
Change the amount of time the radar stays in transmission before it stops
transmitting automatically. This count will be reset each time a trigger is
received.
Select the idle time before the screen is turned OFF, this is an energy saving
feature. The device will continue to operate while the screen is turned off,
pressing a button or triggering the unit will wake up the screen.
5
