Address:4th floor B Building Yuanye Industrial Park Baiyun New Village
Shanghenglang Longhua Bao'an District Shenzhen China
lanxiang reserves the right to modify the specification or
printing errors without prior notice.
F-16
F-16
Fighting Falcon
Fighting Falcon
A R/C model airplane is not a toy and is not suitable for flyer
under 14 years old.Read the instructions carefully before any use.
If you are a beginner, it is necessary to let an experienced airplane
pilot assist you.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F-16 fighting falcon and is the answer not in the manual?

Questions and answers

Related Manuals for General Hobby F-16 fighting falcon

Summary of Contents for General Hobby F-16 fighting falcon

  • Page 1 F-16 F-16 Fighting Falcon Fighting Falcon A R/C model airplane is not a toy and is not suitable for flyer Address:4th floor B Building Yuanye Industrial Park Baiyun New Village under 14 years old.Read the instructions carefully before any use. Shanghenglang Longhua Bao'an District Shenzhen China If you are a beginner, it is necessary to let an experienced airplane pilot assist you.

  • Page 2: Table Of Contents

    F-16 F-16 1.BRIEF INTRODUCTION CATALOG Thank you for purchasing the“F-16”remote control model airplanes from sky flight hobby. in order to ensure your safety,please read the manual carefully 1. Brief introduction before operating this manual. 2.Safety precautions F-16 is a jet plane with twin 70 EDF which suits for intermediate 3.
  • Page 3 F-16 F-16 2.SAFETY INSTRUCTIONS (6).Only use genuine accessories as replacement for damaged parts. Meaning of the icons Accessories WARNING!: this symbol indicates where caution is essential to avoid injury to yourself or others . (7).Do not attempt to catch the model while flying. PROHIBITED: this symbol points out actions that you should not do to avoid possible damage or accidents.

  • Page 4: Main Specifications

    F-16 F-16 5.ASSEMBLY 3.MAIN SPECIFICATIONS (1).Fuselage servos Installation.(1-4) (1).Specifications Wingspan: 860mm (33.85in) Length: 1300mm (51.18 in) EDF Diameter: 70mm Thrust:≥1300g(45.85 OZ) Flying weight:1250g(44.09 OZ) Radio:8CH RC 9×Digital metal 17g servo Brushless motor: 2600KV Brushless ESC : Hobbywing 60A ESC Glue the servo and put it into the fixing servo’s Battery: 25C 18.5V 2200mAh position as shown.
  • Page 5 F-16 F-16 Glue the air intake foam parts then combine them.(17-18) Installation is finished. Fix the front landing gear steering rocker arm as shown. Rear landing gear servo fixing as shown. Landing gear steel wire Installation is finished as shown. Glue the rear landing gears and put them Put the rear landing gear into the right mounting hole.
  • Page 6 F-16 F-16 Glue another side of the spring hinges then connect them as per the corresponding mounting hole Installation is finished. Glue the ESC and fix it as shown. of fuselage. Open the retract door, use the string to lock the landing gear, then through the string out from the Installation is finished.
  • Page 7 F-16 F-16 Glue the plastic vector and attach it with the foam nozzle.(41-42) Installation is finished. Vector vent is finished as shown. (6).Main wing & Elevator Installation.(44-58) Small hinges. Main wing steel wire. Glue the main wing as shown. Install the push rod in main wing. Using diagonal pliers to cut one side of the rocker arm in servo, then glue it and insert it into the mounting hole of fuselage.(45-50) Fix screws as shown.
  • Page 8 F-16 F-16 Elevator push rod installation. Use screws to fix them as shown. Glue tail wing below the fuselage as shown. Insert them in the back of fuselage as shown. (7).Bombs Installation.(59-66) (8).Rudder Installation.(67-70) Punch holes in the pedestal of bombs. Glue the hinges and insert them to the holes.
  • Page 9 F-16 F-16 (9).The installation of nose cone, receiver, battery and canopy.(71-81) Confirm the right order of each channel as per The remote controller manual showed in Page #18.(72) Put the battery in cockpit and fix with battery bandage. Glue the top fuselage as shown, then connect nose cone &...

  • Page 10: Position Of Cg

    F-16 F-16 7.TRANSMITTER(REMOTE CONTROL) INSTRUCTIONS 6.POSITION OF CG. Check the aircraft center of gravity , wrong center of gravity will lead to failure fly.(Please refer to the following photo to check CG.)

  • Page 11: Adjustment And Test Before Flying

    F-16 F-16 8.ADJUSTMENT AND TEST BEFORE FLYING Attention: Only after turning on the mix switch,then operating the vector nozzle. If adjustment and test are approved byprevious work, then enjoy your fly. Preflight After check everything before flight, as a beginner, we should pay attention to the following issues, to make sure our flight is successful.

  • Page 12: Accessories

    F-16 F-16 10.THE POSSIBLE PROBLEMS AND SOLUTIONS 9.ACCESSORIES. Problems Causes Solutions 1.The battery is exhausted. 1. Charge the battery. 2.The transmitter battery is 2. Replace the battery or charging. exhausted. 3. Turn on the transmitter switch. 3.The transmitter switch did not 4.
