FEATURES
•
Three instruments-in-one:
• Psychrometer function measures ambient
t emperature and humidity, dew point,
a nd wet bulb.
• IR thermometer measures surface
t emperature without contact.
• Input for any style of K-type thermocouple.
•
Large, backlit LCD display allows the user to
view the IR or thermocouple input, %RH, and
ambient temp, Wb, or DP simultaneously.
•
Red laser indicator included with IR function.
•
Auto-range selection.
•
Low battery indicator.
•
Auto shutdown.
FUNCTIONS
1. Laser pointer for IR function.
2. Input jack for K-type thermocouple.
3. Temperature and humidity sensor.
4. LCD display.
5. Hold button for temp and humidity function.
6. Select from air temp, wet bulb, or dew point
readings.
7. Hold button for IR or thermocouple input.
8. LCD backlight.
9. Power ON/OFF.
10. MAX/MIN selection for IR or thermocouple
input.
11. Select between °C and °F.
12. IR measurement trigger.
13. MAX/MIN selection for temp and humidity.
© 2008 SPX
Psychrometer
with IR Thermometer
2
1
13
12
11
10
TIF3110
3
4
5
6
7
8
9
Sheet 1 of 2
Advertisement
Related Manuals for TIF TIF3110
Summary of Contents for TIF TIF3110
- Page 1 TIF3110 Psychrometer with IR Thermometer FEATURES • Three instruments-in-one: • Psychrometer function measures ambient t emperature and humidity, dew point, a nd wet bulb. • IR thermometer measures surface t emperature without contact. • Input for any style of K-type thermocouple. • Large, backlit LCD display allows the user to view the IR or thermocouple input, %RH, and ambient temp, Wb, or DP simultaneously. • Red laser indicator included with IR function. • Auto-range selection. • Low battery indicator. • Auto shutdown. FUNCTIONS 1. Laser pointer for IR function. 2. Input jack for K-type thermocouple. 3. Temperature and humidity sensor.
- Page 2 SPECIFICATIONS FUNCTION RANGE RESOLUTION ACCURACY Type K -148—2501°F 0.1°F/°C ± (1% ±1°C) Temperature (-100—1372°C) -58—-4°F 0.1°F/°C ±9.0°F Infrared (-50—-20°C) (5.0°C) Temperature -4—932°F 0.1°F/°C ±2% reading (-20—500°C) or ±4°F (2°C) Air -4—140°F 0.01°F/C ±2.0°F (1.0°C) Temperature (-20—60°C) 10%—90% 0.1%RH ±2% Humidity others 0.1%RH ±3% Wet -6.88—140°F 0.1°F/°C Bulb (-21.6—60°C) Dew...
- Page 3 UNDERSTANDING THE DISPLAY WET BULB and DEW POINT 1. Press the WB/DP button to select the opera- tion mode from air temperature: either wet bulb or dew point. TEMP, WET BULB, DEW POINT, and %RH HOLD 1. Press the HOLD button to freeze air humidity and temperature reading in the upper half of the display. The HOLD icon will appear in the upper right corner of the display. 2. Press the HOLD button again to return to nor- 1. Auto Power Shutdown indicator. mal operation and HOLD icon will disappear. 2. Low Battery indicator. 3. Ambient air temperature value. 4. IR / Thermocouple temperature indicator. 5. Ambient humidity. 6. IR / Thermocouple temperature value.
- Page 4 3. Disable Auto Shutdown: To disable auto shut- One Year of the date of purchase. down function, press and hold the IRT button as you turn the meter ON. The display will show “disAP0”; then release the IRT button. 655 Eisenhower Drive 4. Low Battery: If the battery indicator appears Owatonna, MN 55060 in the upper left corner of the display the unit’s Toll Free: (800) 327-5060 battery is low. Follow the directions in the Main- Fax: (866) 287-7222 tenance section to replace the battery. www.TIF.com Back sheet 2 of 2 Form No. 546770 Rev B January 15, 2009 © 2008 SPX...
