2.2. GENERAL DESCRIPTION

Driving handles
Control box
Pole
Pedals
∅ 4 in wheels with
brake
2.3. TECHNICAL CHARACTERISTICS
Materials :
Finish :
Class:
Weight :
Maximum patient weight to be transferred:
Electrical equipment conformed to NF EN 60 601-1 and to NF EN 60 601-1-2
Duty cycle :
Input :
Actuator input :
Battery charge required time :
Battery autonomy :
Electrical equipment protection :
Steel
Epoxy paint coating
I
base : 15 kg / 34 lb
Pole + support beam :20 kg / 44 lb
150 kg / 330lb
2 min./18 min. (10%)
230V ~ 50 HZ
24 V CC
15 hrs
±
40 cycles
remote control : IP X6
control box : IPX4
actuator : IP X4
5
Version 01/2012
Support beam
Electric actuator
Beam
Side foot
∅ 3 in twin casters
