  • Page 2 Instruction Manual TR850, TR850G DMR Repeater We are very grateful for your purchasing TR850 (TR850G) produced by Kirisun Communications Co., Ltd. We believe TR850(TR850G) can bring great convenience to your life and work. TR850 (TR850G) DMR repeater which always incorporates the advanced technology and exquisite craft, we hope that the quality and function of this product could make you feel satisfied.
  • Page 3 Kirisun or its authorized parties. ◆ Due to the update or modification of the product, Kirisun owns the right to change the specifications of software and hardware described in this manual without further notice.
  • Page 4 TR850, TR850G DMR Repeater Instruction Manual Safety Information In order to use the indoor digital repeater effectively, please read the following information. ◆ This product can only be maintained by the professional technicians. Do not disassemble the radio by yourself.

  • Page 5: Table Of Contents

    TR850, TR850G DMR Repeater Instruction Manual Contents Unpacking and checking ..................1 Standard Accessories ....................1 Radio Overview ....................... 3 Power On/Off Button ....................5 ACCY Connector ..................... 5 2.2.1 Pin Instruction ......................5 2.2.2 External Connector Instruction ................. 7 LED Indicators ......................

  • Page 6: Unpacking And Checking

    TR850, TR850G DMR Repeater Instruction Manual Unpacking and Checking Please unpack carefully and check all the items listed in the following table before discarding the packing material. If any damage or loss occurs during shipment, please contact your dealer. 1.1 Standard Accessories...
  • Page 7 TR850, TR850G DMR Repeater Instruction Manual...

  • Page 8: Radio Overview

    TR850, TR850G DMR Repeater Instruction Manual Radio Overview...
  • Page 9 TR850, TR850G DMR Repeater Instruction Manual Part Name Handles Frond Panel LED Indicators Power Switch GPS Antenna Connector ACCY Connector Network Connector(IP) 100-240V AC Cable Connector GND Screw Tx Connector Cooler RX Connector 13.6V DC Connector...

  • Page 10: Power On/Off Button

    TR850, TR850G DMR Repeater Instruction Manual 2.1 Power On/Off Button Power on/off the repeater. ACCY Connector 2.2.1 Pin Instruction Instruction PIN1 Undefined PIN2 Undefined...
  • Page 11 TR850, TR850G DMR Repeater Instruction Manual PIN3 Undefined PIN4 PIN5 ACC_MAP_ID2: It is used for test. PIN6 ACC_MAP_ID1: It is used for test. PIN7 Undefined PIN8 PIN9 +SPEAKER PIN10 -SPEAKER PIN11 PIN12 PIN13 Undefined PIN14 Undefined PIN15 Undefined PIN16 PIN17 External PTT，High level is effective...

  • Page 12: External Connector Instruction

    TR850, TR850G DMR Repeater Instruction Manual PIN22 PRGM_IO_7, External high level signal input PIN23 Undefined PIN24 Undefined PIN25 Undefined 2.2.2 External Connector Instruction  The method to activate external PTT： Short connect the Pin17 with Pin22 of VGA to activate external PTT. It can test the transmitting signal of repeater.

  • Page 13: Led Indicators

    TR850, TR850G DMR Repeater Instruction Manual 2.3 LED Indicators Indicator Description TX-A Slot 1 transmitting indicator RX-A Slot 1 receiving indicator TX-B Slot 2 transmitting indicator RX-B Slot 2 receiving indicator Repeater signal indicator Analog mode indicator Digital mode indicator...

  • Page 14: Basic Operations

    TR850, TR850G DMR Repeater Instruction Manual Basic Operations 3.1 Powering On/Off When the repeater is turned off, press the power switch " " to power on the repeater. Then the light " "is on. After the system working normally, the light "...

  • Page 15: Warning

    TR850, TR850G DMR Repeater Instruction Manual development can be made through this port. 3.4 Warning When unusual situation happens, warning indicator light will be enlightened. For example, when Receiving Frequency unlocks, the warning light will flash once one second; Transmitting frequency unlocks, the warning light will flash once two seconds;...

  • Page 16: Model Menu

    TR850, TR850G DMR Repeater Instruction Manual New：Add new channel information, repeater will create new channel configuration files, a default analog channel, and set the default configurations, Open: Open a configuration file that saved in the storage device. Save: Save the current channel configuration, in order to open the file conveniently next time.
  • Page 17 TR850, TR850G DMR Repeater Instruction Manual Work Alone：Work as single repeater, not networking with other repeaters. Connect Working Mode：If exceed one single repeater’s coverage, this mode enables the repeater to connect with other repeaters to expand the coverage. Group Call Hang Time：When a terminal radio initiates a group call, and no PTT presses, repeater shall hang on for a period of time.
  • Page 18 TR850, TR850G DMR Repeater Instruction Manual Value Range：0~7000ms, stepping is 500ms, the default value is 4000ms. Calling Hang Time: When a call ends, the repeater will hang on for a period of time, during this time, when a terminal radio presses the PTT, no need to build connect again, just communicate directly.
  • Page 19 TR850, TR850G DMR Repeater Instruction Manual Standing Wave Ratio. Power Amplifier Protect Threshold: As long as the temperature is higher than the threshold value, it stops working , the default threshold value is 80℃ Fan Work Threshold: As long as the temperature is higher the threshold value, the fan starts working.

  • Page 20: Program Menu

    TR850, TR850G DMR Repeater Instruction Manual cannot communicate with each other. Value Range: The CTCSS ranges from 0~254.1Hz, the stepping is 0.1 Hz, default value is 67 Hz. CDCSS: If select CDCSS or –CDCSS, needs to select a CDCSS value, or the transmitter and receiver cannot communicate with each other.
  • Page 21 TR850, TR850G DMR Repeater Instruction Manual pop up a dialog box, shows― Write data successfully‖. When you try to write data, tick the option ―Exit after finish‖, when finish writing data, the dialog box will exit automatically. If not tick this option, users have to press ―Exit‖ manually to close the box.
  • Page 22 TR850, TR850G DMR Repeater Instruction Manual below interface flashes back, maybe fail to open the serial port. Please check the serial port connectivity, or other program takes up the serial port. （4）if the update is finished, software will note that. Please don’t forget to switch the boot mode back to 1000.

  • Page 23: Installation Guide (Refit Guide)

    TR850, TR850G DMR Repeater Instruction Manual Installation Guide (refit guide) Duplexer Installation （1）Disassembly：As the figure below, take off the 4 screws and 6 screws of two sides of the top cover, and then slightly open the top cover.
  • Page 24 TR850, TR850G DMR Repeater Instruction Manual （2）Take off the two screws of duplexer baffle, remove the duplexer.
  • Page 25 TR850, TR850G DMR Repeater Instruction Manual （3） Slightly loosen the two screws of fixed duplexer bracket on installed clapboard to the bracket, and do not too loosen. Refer to following figure.
  • Page 26 TR850, TR850G DMR Repeater Instruction Manual （4）Fixed the duplexer tail screws to the duplexer bracket. Push the duplexer to the end three duplexer connection holes until the duplexer is locked. Then fasten the duplexer bracket and install screw. Refer to following figure.

  • Page 27: Frequently Asked Questions (Faq)

    TR850, TR850G DMR Repeater Instruction Manual Frequently Asked Questions (FAQ)  Can’t connect to the PC programming software The IP of repeater input is error in the programming software. Or the user forgets the IP of repeater.  Can’t transfer...

  • Page 28: Recommend Duplexer Parameters

    TR850, TR850G DMR Repeater Instruction Manual Recommend Duplexer Parameters Model SGQ-450 A / D Frequency Range（MHz） 380~520 Bandwidth（KHz） ± 400 Frequency Spacing（MHz） Insertion Loss（dB） <1.0 Isolation (dB) >80 Suppression(dB) >80 V.S.W.R <1.3 NormaI lmpedance（Ω） Max Power Input（W） 30 / 50...

  • Page 29: Fcc Statement

    TR850, TR850G DMR Repeater Instruction Manual FCC Statement: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 30 TR850, TR850G DMR Repeater Instruction Manual harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna.
