- Page 1 INTERNAL VIDEO RECEIVER Agata V – Agata VC FB00080-EN Agata VC/B – Agata VC/B-L USER MANUAL AGATA V - AGATA VC AGATA VC/B - AGATA VC/B-L...
- Page 2 Function of buttons Press repeatedly to adjust the ringtone volume: low, medium, high, off (red LED on). Press repeatedly to adjust the screen brightness. This function is available when video is activated. For devices with black and white LCD, press repeatedly to adjust the contrast. For devices with colour LCD, press repeatedly to adjust the screen colour saturation.
- Page 3 Standard functions Call in progress. Answering a call. Communication activated. Entry panel door lock release. Ending the communication...
- Page 4 Self-connection Press the key to activate video Where there is more than one entry panel, communication with the entry panel. press the key multiple times to show all the panels in succession. Video toggle MASTER SLAVE For simultaneous video calls on multiple receivers, all receivers will ring but video will be activated only on the...
- Page 5 Call transfer (Agata VC/B - Agata VC/B-L only) Int. 1 Int. 2 With a call active, select the internal receiver to which the call is to be transferred. As soon as the Int. 1 Int. 2 internal receiver which has been called picks up the handset, the call is active between the...
- Page 6 Intercom (Agata VC/B - Agata VC/B-L only) To call an internal receiver, Int. 1 pick up the handset and press the button for the receiver you want. During a conversation between internal receivers, a call from an entry panel is signalled to Int.
- Page 7 Concierge desk functions (Agata VC/B - Agata VC/B-L only) The functions described in this chapter are only available in systems equipped with a concierge desk. Call from concierge notification CALL ME When the Aux2 LED is on, this indicates that CALL ME the concierge wants to be called back.
- Page 8 Came S.p.A. Via Martiri Della Libertà, 15 Via Cornia, 1/b - 1/c 31030 Dosson di Casier 33079 Sesto al Reghena Treviso - Italy Pordenone - Italy (+39) 0422 4940 (+39) 0434 698111 (+39) 0422 4941 (+39) 0434 698434 www.came.com...
