  • Page 1 Use, Care, and Installation Guide Guide d’utilisation, d’entretien et d’installation Guía de instalación, uso y mantenimiento READ AND SAVE THESE INSTRUCTIONS LISEZ CES INSTRUCTIONS ET CONSERVEZ-LES LEA Y CONSERVE Models: EAI430SS ESTAS INSTRUCCIONES EAI436SS LIB0131463 Printed in Mexico...
  • Page 2: Table Of Contents

    ENGLISH Contents Important safety notice......................................... 3 Electrical & installation requirements ................................4 Before installing the hood ...................................... 4 Dimensions and clearances......................................4 List of materials..........................................5 Parts supplied ..........................................5 Parts not supplied ........................................5 Ducting options and examples....................................6 Installation ............................................
  • Page 3: Important Safety Notice

    IMPORTANT SAFETY NOTICE I CAUTION I WARNING FOR GENERAL VENTILATING USE ONLY. DO NOT USE TO TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE. EXHAUST HAZARDOUS OR EXPLOSIVE MATERIALS OR a) Never leave surface units unattended at high settings. VAPOURS.
  • Page 4: Electrical & Installation Requirements

    ELECTRICAL & INSTALLATION REQUIREMENTS IMPORTANT Copies of the standards listed may be obtained from: * National Fire Protection Association Batterymarch Park Quincy, Observe all governing codes and ordinances. Massachusetts 02269 ** CSA International 8501 East Pleasant Valley Road Cleveland, Ohio 44131-5575 It is the customer’s responsibility: •...
  • Page 5: List Of Materials

    LIST OF MATERIALS Removing the packaging. I CAUTION Remove carton carefully, Wear gloves to protect against sharp edges. I WARNING Remove the protective film covering the product before putting into operation. Supplied Part Pieces Supplied Part Pieces Rectangular duct 3 ⁄...
  • Page 6: Ducting Options And Examples

    Ducting Options Closely follow the instructions set out in this manual. All responsability, for any eventual inconveniences, damages or fires caused by not complying with the instructions in this manual, is declined. Ductless (Recirculating) Horizontal Discharge NOTE: Use a rectangular duct In cases where it should not be ⁄...
  • Page 7: Installation

    Installation- Ducting Version After having choosen the vent option, proceed as follows: Round vertical Rectangular discharge Remove the grease filters. vertical discharge Rectangular horizontal discharge For rectangular ducted discharge installations only. Attach exhaust adaptor/damper over knockout opening with two exhaust adaptor screws. Make sure damper pivot is nearest to top/back edge of Remove the junction box cover.
  • Page 8 Mark holes Installation- Recirculating Select the vent option that your installation will require Use the hood as a template and mark the locations on the and proceed to that section: cabinet for the electrical wiring and keyhole screw slots. Since the hood is to be recirculated (not to be vented outside), Outside top exhaust do not cut out any vent openings in the wall or cabinet bottom.
  • Page 9: Electrical Connection

    Electrical Connection I WARNING • Run 3 wires; black, white and green ,according to the National Electrical Code and local codes and ordinances, ELECTRICAL SHOCK HAZARD. ⁄ ” conduit from service panel to junction box. I WARNING TURN OFF POWER CIRCUIT AT THE SERVICE PANEL BEFORE WIRING THIS UNIT.
  • Page 10: Control

    Control Mainteinance REDUCTION SYSTEM Cleaning Do not spray cleaners directly to the control while cleaning the Hood. The cooker hood should be cleaned regularly (at least with the same frequency with which you carry out maintenance of the fat filters) internally and externally. Clean using the Button ON/OFF motor (stand by) cloth dampened with neutral liquid detergent.
  • Page 11 NOTE: When removing for replacing for a new one do not remove Fixing Springs, simply pull out one and rotate outwards. Fixing spring Charcoal filter Grease filter top side...
  • Page 12: Warranty

    PARTS AND SERVICE WARRANTY For the period of two (2) years from the date of the original purchase, Elica will provide free of charge, non consumable parts or components that failed due to manufacturing defects. During these two (2) years limited warranty, Elica will also provide free of charge, all labor and in-home service to replace any defective parts.
