Summary of Contents for CTS FWR5-3105 Series

  • Page 1 FWR5-3105 Series Residential Gateway User’s Guide Version 0.91...
  • Page 2: Revision History

    Revision History Version Date Description 0.90 20160715 First Release 0.90 20160930 Content Review...
  • Page 3 Trademarks Contents are subject to revision without prior notice. All other trademarks remain the property of their respective owners. Copyright Statement This publication may not be reproduced as a whole or in part, in any way whatsoever unless prior consent has been obtained from Company FCC Warning This equipment has been tested and found to comply with the limits for a Class-A digital device, pursuant to Part 15 of the FCC Rules.
  • Page 4: Table Of Contents

    Table of Contents 1. INTRODUCTION ................... 5 1.1 The Managed Residential Gateway............5 1.2 Appearance ....................6 1.3 LED Definitions ..................9 2. INSTALLATION ................... 12 2.1 Installation Requirements ............... 12 2.2 Checking the Package Contents ............12 2.3 Installing the WLAN Residential Gateway ..........13 2.4 Powering ON ..................
  • Page 5: Introduction

    1. INTRODUCTION Thank you for choosing this WLAN Residential Gateway. The WLAN Residential Gateway can provide the best performance and price ratio when multiple copper ports need to be deployed in networking environment. 1.1 The Managed Residential Gateway With 4 or 5 10/100/1000Mbps RJ-45 ports on the front panel and 1 or 2 combo ports, this compact WLAN Residential Gateway provides high performance store-and-forward switching capability plus other advanced features such as VLAN etc..
  • Page 6: Appearance

    1.2 Appearance Front Panel 2 Ports 10/100/1000Mbps, 2 USB Ports RJ-45 and 1 100/1000Mbps SFP slot; built-in IEEE802.11n WiFi and 2 combo ports uplink Residential gateway WPS Button Combo Port (10/100/1000Mbps RJ-45 WAN port + 100/1000Mbps SFP slot) LAN 1~2 Port (10/100/1000Mbps RJ-45 port) USB Port Combo Port (LAN 3 10/100/1000Mbps RJ-45 port + 100/1000Mbps SFP slot)
  • Page 7 Combo Port (10/100/1000Mbps RJ-45 WAN port + 100/1000Mbps SFP slot) LAN 1~4 Port (10/100/1000Mbps RJ-45 port) USB Port LED Button Power Input Antenna (For WiFi Model Only) Rear Panel 2 Ports 10/100/1000Mbps, 2 USB Ports RJ-45 and 1 100/1000Mbps SFP slot; built-in IEEE802.11n WiFi and 2 combo ports uplink Residential gateway 4 Ports 10/100/1000Mbps RJ-45 and 2 USB Ports;...
  • Page 8: Top Panel

    Left and Right Panel Figure 1. Left Panel Figure 2. Right Panel Reset Button:  Insert a pin or paper clip to press the Reset Button for 5 seconds to restart the system  Insert a pin or paper clip to press the Reset Button for 10 seconds to reset the device back to factory defaults.
  • Page 9: Led Definitions

    4 Ports 10/100/1000Mbps RJ-45 and 2 USB Ports; built-in IEEE802.11n WiFi and 1 combo ports uplink Residential gateway LED: For detail definitions, please refer to chapter 1.3 LED Definitions. The enlarged LED panel should be shown as below: 1.3 LED Definitions The WLAN Residential Gateway is Plug &...
  • Page 10 The port link is off. Green The link is up and works at 10/100Mbps. LAN 1 Orange The link is up and works at 1000Mbps. Blinking The traffic is present. The port link is off. Green The link is up and works at 10/100Mbps. LAN 2 Orange The link is up and works at 1000Mbps.
  • Page 11 SFP Transceiver for 1000BASE-SX Multi-mode fiber module (550m) SFP Transceiver for 1000BASE-LX Single-mode fiber module (10km) Mini-GBIC SFP Transceiver for 1000BASE-LH Single-mode fiber module (30km/50km) SFP Transceiver for 1000BASE-ZX Single-mode fiber module (80km)
  • Page 12: Installation

    2. INSTALLATION To properly install the WLAN Residential Gateway, please follow the procedures listed below. Procedures covered in this chapter are described below in separate sections.  Installation Requirements  Unpacking the WLAN Residential Gateway  Installing the WLAN Residential Gateway ...
  • Page 13: Installing The Wlan Residential Gateway

    2.3 Installing the WLAN Residential Gateway CAUTION To prevent any damage or failure of the WLAN Residential Gateway, please DO NOT block the ventilation FAN holes. Use the following guidelines when choosing a place to install the Residential Gateway:  Firm and steady flat surface. ...
  • Page 14: Connecting The Gateway To Network

    2.5 Connecting the Gateway to Network Connect to Network This WLAN Residential Gateway has 4 or 5 10/100/1000Mbps RJ-45 ports on the front panel. These ports can be inserted by 10/100/1000Base-T cables, connecting to the end devices. The connection of the fiber port on the rear panel must be matched, i.e.
  • Page 15: Maintenance

    3. MAINTENANCE It is easy to use and maintain this WLAN Residential Gateway. The procedures are suggested when you want to identify faults, perform hardware replacement and firmware upgrading. 3.1 Trouble Shooting Identifying faults can greatly reduce the time required to find the problem and solution.
  • Page 16: Hardware Replacement Procedures

    3.2 Hardware Replacement Procedures WARNING! The WLAN Residential Gateway contains no user-serviceable parts. DO NOT, UNDER ANY CIRCUMSTANCES, open and attempt to repair it. Failure to observe this warning could result in personal injury or death from electrical shock. Failure to observe the above warning will immediately void any Warranty. 3.3 Firmware Upgrade This WLAN Residential Gateway may perform firmware upgrading when required.
