Panasonic SDR-H18P Service Manual

Sd card/hard disk video camera
Hide thumbs Also See for SDR-H18P:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual
SD Card/Hard Disk Video Camera
SDR-H18P
SDR-H20P
SDR-H18PC
SDR-H20PC
Vol. 2
(S)...................Silver Type
Colours
© 2007 Panasonic Shikoku Electronics Co., Ltd. All
rights
reserved.
distribution is a violation of law.
ORDER NO. MKE0702301CE
B27
Unauthorized
copying
and

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SDR-H18P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Panasonic SDR-H18P

Summary of Contents for Panasonic SDR-H18P

  • Page 1 ORDER NO. MKE0702301CE SD Card/Hard Disk Video Camera SDR-H18P SDR-H20P SDR-H18PC SDR-H20PC Vol. 2 (S)....Silver Type Colours © 2007 Panasonic Shikoku Electronics Co., Ltd. All rights reserved. Unauthorized copying distribution is a violation of law.

  • Page 2: Table Of Contents

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC CONTENTS Page Page 1 Service Navigation 4.5. MAIN (MAIN CONNECTION (4/4)) SCHEMATIC 1.1. Introduction DIAGRAM 1.2. About Lead Free Solder (PbF) 4.6. MAIN (POWER (1/4)) SCHEMATIC DIAGRAM 2 Service Fixture & Tools 4.7. MAIN (POWER (2/4)) SCHEMATIC DIAGRAM 2.1.

  • Page 3: Service Navigation

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 1 Service Navigation 1.1. Introduction This service manual contains technical information which will allow service personnel´s to understand and service this model. Please place orders using the parts list and not the drawing reference numbers.

  • Page 4: Service Fixture & Tools

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 2 Service Fixture & Tools 2.1. Service Position 2.1.1. Extension Cables for Service Position Using the following Extension Cables, place the unit as shown for check and service. PART NUMBER PART NAME CONNECTION...
  • Page 5 SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC...
  • Page 6 SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC...

  • Page 7: Replacement Proceudres For Csp (Chip Size Package) Ic

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 2.2. Replacement Proceudres for CSP (Chip Size Package) IC 2.2.1. EQUIPMENT 1. Pre-Heater 2. Spot Heater 3. Vacuum Pick-up 4. P.C.B. Holder Fig. C1 Fig. C2...
  • Page 8 SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 2.2.2. Removal of CSP IC Fig. C3...
  • Page 9 SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 2.2.3. Installation of CSP IC Fig. C4...
  • Page 10 SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC Fig. C5...
  • Page 11 SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 2.2.4. CSP IC Location...
  • Page 12 SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 2.2.5. Temperature Profile for Heat Resistance of CSP IC Refer to the temperature profile. CSP ICs in the 2007 model have the following temperature profile.

  • Page 13: Block Diagrams

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 3 Block Diagrams 3.1. CCD DRIVE BLOCK DIAGRAM CCD DRIVE BLOCK DIAGRAM REC VIDEO(CAMERA) SIGNAL CCD P.C.B. MAIN P.C.B IC601 (CCD) IC302 (CAMERA SIGNAL PROCESS/TIMING GENERATOR) Q601 FP31 IMAGE 10BIT A/D TO VIDEO SIGNAL PROCESS...

  • Page 14: Video Signal Process Block Diagram

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 3.2. VIDEO SIGNAL PROCESS BLOCK DIAGRAM VIDEO SIGNAL PROCESS BLOCK DIAGRAM REC VIDEO SIGNAL PB VIDEO SIGNAL REC AUDIO SIGNAL PB AUDIO SIGNAL MAIN P.C.B. HDD RELAY P.C.B. HDD UNIT IC3001 (CAMERA DIGITAL SIGNAL PROCESS/SHUFFLING)

  • Page 15: Analog Video I/F Block Diagram

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 3.3. ANALOG VIDEO I/F BLOCK DIAGRAM ANALOG VIDEO I/F BLOCK DIAGRAM REC VIDEO SIGNAL PB VIDEO SIGNAL MAIN P.C.B. TO SYSTEM CONTROL AV PLUG IN DETECT (L) BLOCK DAGRAM IC3301 (VIDEO SIGNAL PROCESS)

  • Page 16: Audio Signal Process Block Diagram

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 3.4. AUDIO SIGNAL PROCESS BLOCK DIAGRAM AUDIO SIGNAL PROCESS BLOCK DIAGRAM REC AUDIO SIGNAL PB AUDIO SIGNAL MAIN P.C.B. FRONT P.C.B. IC3301(AUDIO I/F) ECM UNIT IC4801(OP AMP) V-REF FJ4801 FP41 FP6501 AUDIO DATA 0...

  • Page 17: System Control Block Diagram

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 3.5. SYSTEM CONTROL BLOCK DIAGRAM SYSTEM CONTROL BLOCK DIAGRAM MAIN P .C.B. SIDE L UNIT IC6001 (SYSTEM MICROCONTROLLER) POWER FP61 DISC ACCESS IC6004 (EEPROM) FP61 POWER FP61 EEPROM CS EEPROM CS POWER SW...

  • Page 18: Af Block Diagram

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 3.6. AF BLOCK DIAGRAM AF BLOCK DIAGRAM MAIN P.C.B LENS UNIT IC6001 (SYSTEM MICROCONTROLLER) FP71 ZOOM ENCODER FP701 ZOOM FOCUS ENCODER ENCODER ALC PWM CONTROL FP71 FROM VIDEO FOCUS ENCODER SIGNAL Q6002 IRIS CLOSE...

  • Page 19: Lcd Drive Block Diagram

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 3.7. LCD DRIVE BLOCK DIAGRAM LCD DRIVE BLOCK DIAGRAM VIDEO SIGNAL (REC & PB) MAIN P.C.B SHAFT UNIT LCD BACKLIGHT P.C.B. LCD PANEL UNIT REVERSE/NORMAL FP81 TO SYSTEM CONTROL LCD REVERSE (L) BLOCK DIAGRAM...

  • Page 20: Power Supply Block Diagram

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 3.8. POWER SUPPLY BLOCK DIAGRAM POWER SUPPLY BLOCK DIAGRAM REAR UNIT MAIN P.C.B. BATTERY (D) TO/FROM SYSTEM CONTROL BLOCK DIAGRAM BATTERY VOLTAGE DET POWER ON (H) Q1091,Q1092 L1091 L1291 +3.3V HDD +3.3V CONTROL...

  • Page 21: Schematic Diagrams

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 4 Schematic Diagrams 4.1. SCHEMATIC DIAGRAM & CIRCUIT BOARD LAYOUT NOTES...

  • Page 22: Main (Main Connection (1/4)) Schematic Diagram

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 4.2. MAIN (MAIN CONNECTION (1/4)) SCHEMATIC DIAGRAM NOTE: For placing a purchase order of the parts, NOTE: NOTE: MAIN (MAIN CONNECTION (1/4)) SCHEMATIC DIAGRAM be sure to use the part number listed in the parts list.

  • Page 23: Main (Main Connection (2/4)) Schematic Diagram

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 4.3. MAIN (MAIN CONNECTION (2/4)) SCHEMATIC DIAGRAM MAIN (MAIN CONNECTION (2/4)) SCHEMATIC DIAGRAM NOTE: NOTE: NOTE: For placing a purchase order of the parts, PARTS MARKED "PT" ARE NOT USED. FOR SCHEMATIC DIAGRAM AND CIRCUIT BOARD LAYOUT NOTES, be sure to use the part number listed in the parts list.

  • Page 24: Main (Main Connection (3/4)) Schematic Diagram

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 4.4. MAIN (MAIN CONNECTION (3/4)) SCHEMATIC DIAGRAM MAIN (MAIN CONNECTION (3/4)) SCHEMATIC DIAGRAM NOTE: NOTE: NOTE: For placing a purchase order of the parts, PARTS MARKED "PT" ARE NOT USED. FOR SCHEMATIC DIAGRAM AND CIRCUIT BOARD LAYOUT NOTES, be sure to use the part number listed in the parts list.

  • Page 25: Main (Main Connection (4/4)) Schematic Diagram

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 4.5. MAIN (MAIN CONNECTION (4/4)) SCHEMATIC DIAGRAM MAIN (MAIN CONNECTION (4/4)) SCHEMATIC DIAGRAM NOTE: For placing a purchase order of the parts, NOTE: NOTE: be sure to use the part number listed in the parts list.

  • Page 26: Main (Power (1/4)) Schematic Diagram

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 4.6. MAIN (POWER (1/4)) SCHEMATIC DIAGRAM NOTE: For placing a purchase order of the parts, NOTE: NOTE: MAIN (POWER (1/4)) SCHEMATIC DIAGRAM IMPORTANT SAFETY NOTICE: be sure to use the part number listed in the parts list.

  • Page 27: Main (Power (2/4)) Schematic Diagram

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 4.7. MAIN (POWER (2/4)) SCHEMATIC DIAGRAM MAIN (POWER (2/4)) SCHEMATIC DIAGRAM NOTE: NOTE: NOTE: For placing a purchase order of the parts, PARTS MARKED "PT" ARE NOT USED. FOR SCHEMATIC DIAGRAM AND CIRCUIT BOARD LAYOUT NOTES, be sure to use the part number listed in the parts list.

  • Page 28: Main (Power (3/4)) Schematic Diagram

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 4.8. MAIN (POWER (3/4)) SCHEMATIC DIAGRAM MAIN (POWER (3/4)) SCHEMATIC DIAGRAM NOTE: NOTE: NOTE: For placing a purchase order of the parts, PARTS MARKED "PT" ARE NOT USED. FOR SCHEMATIC DIAGRAM AND CIRCUIT BOARD LAYOUT NOTES, be sure to use the part number listed in the parts list.

  • Page 29: Main (Power (4/4)) Schematic Diagram

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 4.9. MAIN (POWER (4/4)) SCHEMATIC DIAGRAM MAIN (POWER (4/4)) SCHEMATIC DIAGRAM NOTE: For placing a purchase order of the parts, NOTE: NOTE: be sure to use the part number listed in the parts list.
  • Page 30 SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC IC1001 / IC1002 IC- DETAIL BLOCK DIAGRAM ERROR AMP ERROR AMP DRIVE CONTROL DRIVE ON/OFF DRIVE CONTROL CONTROL DRIVE V-REF DRIVE CONTROL TRIANGLE WAVE OSCILLATOR DRIVE CONTROL SHORTCIRCUIT PROTECT ERROR AMP ERROR AMP...

  • Page 31: Main (Control (1/4)) Schematic Diagram

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 4.10. MAIN (CONTROL (1/4)) SCHEMATIC DIAGRAM NOTE: For placing a purchase order of the parts, NOTE: NOTE: MAIN (CONTROL (1/4)) SCHEMATIC DIAGRAM be sure to use the part number listed in the parts list.

  • Page 32: Main (Control (2/4)) Schematic Diagram

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 4.11. MAIN (CONTROL (2/4)) SCHEMATIC DIAGRAM MAIN (CONTROL (2/4)) SCHEMATIC DIAGRAM NOTE: NOTE: NOTE: For placing a purchase order of the parts, PARTS MARKED "PT" ARE NOT USED. FOR SCHEMATIC DIAGRAM AND CIRCUIT BOARD LAYOUT NOTES, be sure to use the part number listed in the parts list.

  • Page 33: Main (Control (3/4)) Schematic Diagram

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 4.12. MAIN (CONTROL (3/4)) SCHEMATIC DIAGRAM MAIN (CONTROL (3/4)) SCHEMATIC DIAGRAM NOTE: For placing a purchase order of the parts, NOTE: NOTE: be sure to use the part number listed in the parts list.

  • Page 34: Main (Control (4/4)) Schematic Diagram

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 4.13. MAIN (CONTROL (4/4)) SCHEMATIC DIAGRAM MAIN (CONTROL (4/4)) SCHEMATIC DIAGRAM NOTE: NOTE: NOTE: For placing a purchase order of the parts, PARTS MARKED "PT" ARE NOT USED. FOR SCHEMATIC DIAGRAM AND CIRCUIT BOARD LAYOUT NOTES, be sure to use the part number listed in the parts list.
  • Page 35 SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC I/O CHART OF IC6001 Pin No. Signal Name Description Pin No. Signal Name Description Pin No. Signal Name Description (Not used) DVSS Ground TPC5 ADM[12] Address / Data 12 F Number PCST0 (Not used) FVCC3 +2.8V...

  • Page 36: Main (Tg/Afe) Schematic Diagram

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 4.14. MAIN (TG/AFE) SCHEMATIC DIAGRAM NOTE: For placing a purchase order of the parts, NOTE: NOTE: MAIN (TG/AFE) SCHEMATIC DIAGRAM be sure to use the part number listed in the parts list. PARTS MARKED "PT" ARE NOT USED.
  • Page 37 SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC IC302 IC- DETAIL BLOCK DIAGRAM IC303 IC- DETAIL BLOCK DIAGRAM DVSS1 DVDD1 DVSS4 DVDD4 DVDD5 LCD TIMING GENERATOR CCD GND DRIVER DVSS5 AVDD1 DLLC DVSS1 DRIVER AVSS12 DVDD1 BIAS AVDD2 DVDD1 CLAMP RESET...

  • Page 38: Main (Lens Drive) Schematic Diagram

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 4.15. MAIN (LENS DRIVE) SCHEMATIC DIAGRAM NOTE: For placing a purchase order of the parts, NOTE: NOTE: MAIN (LENS DRIVE) SCHEMATIC DIAGRAM be sure to use the part number listed in the parts list.

  • Page 39: Main (Memory) Schematic Diagram

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 4.16. MAIN (MEMORY) SCHEMATIC DIAGRAM NOTE: For placing a purchase order of the parts, NOTE: NOTE: MAIN (MEMORY) SCHEMATIC DIAGRAM be sure to use the part number listed in the parts list. PARTS MARKED "PT" ARE NOT USED.

  • Page 40: Main (Video (1/4)) Schematic Diagram

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 4.17. MAIN (VIDEO (1/4)) SCHEMATIC DIAGRAM NOTE: For placing a purchase order of the parts, NOTE: NOTE: MAIN (VIDEO (1/4)) SCHEMATIC DIAGRAM be sure to use the part number listed in the parts list.

  • Page 41: Main (Video (2/4)) Schematic Diagram

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 4.18. MAIN (VIDEO (2/4)) SCHEMATIC DIAGRAM MAIN (VIDEO (2/4)) SCHEMATIC DIAGRAM NOTE: NOTE: NOTE: For placing a purchase order of the parts, PARTS MARKED "PT" ARE NOT USED. FOR SCHEMATIC DIAGRAM AND CIRCUIT BOARD LAYOUT NOTES, be sure to use the part number listed in the parts list.

  • Page 42: Main (Video (3/4)) Schematic Diagram

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 4.19. MAIN (VIDEO (3/4)) SCHEMATIC DIAGRAM MAIN (VIDEO (3/4)) SCHEMATIC DIAGRAM NOTE: NOTE: NOTE: For placing a purchase order of the parts, PARTS MARKED "PT" ARE NOT USED. FOR SCHEMATIC DIAGRAM AND CIRCUIT BOARD LAYOUT NOTES, be sure to use the part number listed in the parts list.

  • Page 43: Main (Video (4/4)) Schematic Diagram

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 4.20. MAIN (VIDEO (4/4)) SCHEMATIC DIAGRAM MAIN (VIDEO (4/4)) SCHEMATIC DIAGRAM NOTE: NOTE: NOTE: For placing a purchase order of the parts, PARTS MARKED "PT" ARE NOT USED. FOR SCHEMATIC DIAGRAM AND CIRCUIT BOARD LAYOUT NOTES, be sure to use the part number listed in the parts list.
  • Page 44 SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC I/O CHART OF IC3001 (1/2) Pin No. Signal Name Description Pin No. Signal Name Description Pin No. Signal Name Description Pin No. Signal Name Description ( Not used ) DRAMSDAT(6) SDRAM Data 6...
  • Page 45 SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC I/O CHART OF IC3001 (2/2) Pin No. Signal Name Description Pin No. Signal Name Description Pin No. Signal Name Description (Not used) (Not used) ADAT(10) Flash Memory Data 10 ADC0 YCIN(5) (Not used)

  • Page 46: Main (Lcd) Schematic Diagram

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 4.21. MAIN (LCD) SCHEMATIC DIAGRAM NOTE: For placing a purchase order of the parts, NOTE: NOTE: MAIN (LCD) SCHEMATIC DIAGRAM be sure to use the part number listed in the parts list. PARTS MARKED "PT" ARE NOT USED.

  • Page 47: Main (Av Io) Schematic Diagram

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 4.22. MAIN (AV IO) SCHEMATIC DIAGRAM NOTE: For placing a purchase order of the parts, NOTE: NOTE: MAIN (AV IO) SCHEMATIC DIAGRAM be sure to use the part number listed in the parts list.

  • Page 48: Voltage Chart

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 4.23. VOLTAGE CHART NOTE: FOR SCHEMATIC DIAGRAM AND CIRCUIT BOARD LAYOUT NOTES, REFER TO BEGINNING OF SCHEMATIC SECTION. MAIN P.C.B. MODE MODE MODE MODE MODE MODE MODE MODE MODE MODE MODE MODE PIN NO.
  • Page 49 SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC NOTE: FOR SCHEMATIC DIAGRAM AND CIRCUIT BOARD LAYOUT NOTES, REFER TO BEGINNING OF SCHEMATIC SECTION. LCD BACKLIGHT P.C.B. FRONT P.C.B. HDD RELAY P.C.B. MODE MODE MODE MODE MODE MODE MODE MODE MODE MODE PIN NO.
  • Page 50 SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC...

  • Page 51: Printed Circuit Board

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 5 Printed Circuit Board MAIN P.C.B. LSEP8388A1 (COMPONENT SIDE) NOTE: MULTILAYER P.C.B. THIS P.C.B. IS Multi-Layer P.C.B.THIS CIRCUIT BOARD SHOWS COMPONENT LAYOUT-PATTERN FOR COMPONENT SIDE AND FOIL SIDE. LAYOUT PATETRNS ARE SINGLE PATTERN FOR EACH SIDE THAT MAKE EASY TO SIGHT THE COMPONENT LAYOUT.
  • Page 52 SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC MAIN P.C.B. LSEP8388A1 (FOIL SIDE) NOTE: MULTILAYER P.C.B. THIS P.C.B. IS Multi-Layer P.C.B.THIS CIRCUIT BOARD SHOWS COMPONENT LAYOUT-PATTERN FOR COMPONENT SIDE AND FOIL SIDE. LAYOUT PATETRNS ARE SINGLE PATTERN FOR EACH SIDE THAT MAKE EASY TO SIGHT THE COMPONENT LAYOUT.
  • Page 53 SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC Parts Location MAIN P.C.B. TP81 FP71 L4503 C1001 C1372 C3069 C6032 R726 R1371 R3108 R6003 R6088 Integrated circuit IC301 TP91 FP72 L4504 C1002 C1381 C3070 C6033 R727 R1372 R3109 R6004 R6089 IC302 TP92...
  • Page 54 SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC...

  • Page 55: Appendix Information Of Schematic Diagram

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 6 Appendix Information of Schematic Diagram 6.1. CHECKING POINT TABLE OF THE CSP IC...
  • Page 56 SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC...
  • Page 57 SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC...
  • Page 58 SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC...
  • Page 59 SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC...
  • Page 60 SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC...
  • Page 61 SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC...
  • Page 62 SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC...
  • Page 63 SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC...

  • Page 64: Waveform Table

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 6.2. WAVEFORM TABLE 50ns 10ms WF10 10ms 10ms WF11 WF12 WF13 WF14 WF15 10ms 10ms 20µs 0.5V WF16 WF17 WF18 WF19 WF20 0.2V 20µs 0.2V 20µs 50ns 50ns WF21 WF22 WF23 WF24 WF25 0.1µs...
  • Page 65 SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC WF36 WF37 WF38 WF39 WF40 WF41 WF42 WF43 WF44 WF45 20µs 0.5V 10µs...

  • Page 66: Replacement Parts List

    SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC 7 Replacement Parts List BEFORE REPLACING PARTS, READ THE FOLLOWING: Ref. Part No. Part Name & Description Remarks 1. Use only original replacement parts: IC3001 MN2WS0056SP1 IC, LINEAR 1 CSP To maintain original function and reliability of repaired units,...
  • Page 67 SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC Ref. Part No. Part Name & Description Remarks Ref. Part No. Part Name & Description Remarks B1ADCF000073 TRANSISTOR SI PNP CHIP D1411 MA2S111008 DIODE SI CHIP Q1461 B0ACCK000003 DIODE SI CHIP Q1462 B1ABCF000226...
  • Page 68 SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC Ref. Part No. Part Name & Description Remarks Ref. Part No. Part Name & Description Remarks R738 ERJ2GEJ151X MGF CHIP 1/16W 150 R1462 D0GA223JA015 MGF CHIP 1/16W 22K R739 D0GA103JA015 MGF CHIP 1/16W 10K...
  • Page 69 SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC Ref. Part No. Part Name & Description Remarks Ref. Part No. Part Name & Description Remarks R3130 D0GA182JA015 MGF CHIP 1/16W 1.8K R6029 D0GA392JA015 MGF CHIP 1/16W 3.9K R3131 D0GA473JA015 MGF CHIP 1/16W 47K...
  • Page 70 SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC Ref. Part No. Part Name & Description Remarks Ref. Part No. Part Name & Description Remarks R6120 D0GA102JA015 MGF CHIP 1/16W 1K C716 F1G1C103A048 C CHIP 16V 0.01UF R6121 D0GA102JA015 MGF CHIP 1/16W 1K...
  • Page 71 SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC Ref. Part No. Part Name & Description Remarks Ref. Part No. Part Name & Description Remarks C1271 F1J1C335A121 C CHIP 16V 3.3UF C3060 F1J1A1050004 C CHIP 10V 1UF C1281 F1H1E105A116 C CHIP 25V 1UF...
  • Page 72 SDR-H18P / SDR-H20P / SDR-H18PC / SDR-H20PC Ref. Part No. Part Name & Description Remarks Ref. Part No. Part Name & Description Remarks C6031 F1G1C103A048 C CHIP 16V 0.01UF L7004 J0JBC0000107 BEAD INDUCTOR CHIP C6032 F1G1C103A048 C CHIP 16V 0.01UF...
