CommScope PFU-P-C-O-060-02 Hardware Manual

CommScope PFU-P-C-O-060-02 Hardware Manual

Two port poe extender
Hide thumbs Also See for PFU-P-C-O-060-02:
Table of Contents

Advertisement

Quick Links

Two Port PoE Extender
Hardware Manual
860634349

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PFU-P-C-O-060-02 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CommScope PFU-P-C-O-060-02

Summary of Contents for CommScope PFU-P-C-O-060-02

  • Page 1 Two Port PoE Extender Hardware Manual 860634349...

  • Page 3: Table Of Contents

    Installing to a Wall ....................26 Attaching an Earth Point..................27 Installing to a Pole ....................28 Operating Temperature Advice..................29 4 Detailed Specifications............... 31 Copyright, Trademarks and Commercial Disclaimer ............ 34 This product is copyright © 2017 CommScope, LLC. All Rights Reserved.
  • Page 4 Two Port PoE Extender Hardware Manual This product is copyright © 2017 CommScope, LLC. All Rights Reserved.

  • Page 5: Electrical Safety

    Reliable earthing of rack-mounted equipment should be maintained. Particular attention should be given to supply connections other than direct connections to the branch circuit (e.g. use of power strips). This product is copyright © 2017 CommScope, LLC. All Rights Reserved.

  • Page 6: General

    Ultimate disposal of this equipment must be carried out according to relevant national laws. The equipment should be installed by suitably trained personnel, and installation should follow good working practice. This product is copyright © 2017 CommScope, LLC. All Rights Reserved.

  • Page 7: Sécurité Electrique

    Il convient de maintenir une mise à la terre fiable d'équipement monté en rack. Il convient de faire particulièrement attention aux raccordements d'alimentation autres que ceux directement en contact avec le circuit de dérivation (p. ex., utiliser des bars d'alimentation). This product is copyright © 2017 CommScope, LLC. All Rights Reserved.

  • Page 8: Dispositions Générales

    La suppression définitive de cet équipement devra être effectuée conformément aux lois nationales pertinentes. L'équipement doit être installé par du personnel parfaitement qualifié, et l'installation devra être conforme aux bonnes pratiques. This product is copyright © 2017 CommScope, LLC. All Rights Reserved.

  • Page 9: Elektrische Sicherheit

    Typenschildern, um die Gesamtlast zu ermitteln. Es muss eine zuverlässige Erdung der Rack-Geräte gegeben sein. Besondere Aufmerksamkeit gilt dabei der indirekten Anbindung an Zweigstromkreise (z. B. Verwendung von Mehrfachsteckerleisten). This product is copyright © 2017 CommScope, LLC. All Rights Reserved.

  • Page 10: Allgemeines

    Die Entsorgung dieses Geräts muss nach den einschlägigen nationalen Rechtsvorschriften erfolgen. Das Gerät muss durch entsprechend geschultes Personal installiert werden. Bei der Installation ist auf gute Arbeitspraxis zu achten. This product is copyright © 2017 CommScope, LLC. All Rights Reserved.

  • Page 11: Ce Notice

    FCC rules. This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numerique de la class B est conforme a la norme ICES-003 du Canada This product is copyright © 2017 CommScope, LLC. All Rights Reserved.

  • Page 12: Return Product Procedure

    If the unit is found to be defective please contact Technical Support via www.commscope.com/ SupportCenter/TechnicalSupport.aspx Product user Guide This document details the physical features of the Two Port PoE Extender. This product is copyright © 2017 CommScope, LLC. All Rights Reserved.

  • Page 13: Introduction

    Circuit protection electronics Optical to electrical Media Conversion When coupled with any standard NEC Class II 48V DC power supply CommScope’s Powered Fiber Cable system can power and communicate with PoE standard devices at far greater distances than "category style" copper cabling systems which are typically limited to 90 meters, and still meet NEC Class II and SELV standards, eliminating the need for qualified electricians during installation.
  • Page 14 4A non replaceable fuses • No exposed high voltage pads • High power inductors used as coordinating elements to maximize energy efficiency • Sealed enclosure for environmental protection • This product is copyright © 2017 CommScope, LLC. All Rights Reserved.

  • Page 15: Package Contents

    2. Package Contents Two Port PoE Extender Part Number The part number for the Two Port PoE Extender is PFU-P-C-O-060-02 In the Box The PoE Extender is supplied ready for cable installation with the solar shield attached. This product is copyright © 2017 CommScope, LLC. All Rights Reserved.

  • Page 16: Also Required (Not Included)

    12 AWG or 2mm diameter wire stripper for 12 AWG cable • 16 AWG or 1.2mm wire diameter stripper for the 16 AWG cable • Fastenings for wall/pole mounting • This product is copyright © 2017 CommScope, LLC. All Rights Reserved.

  • Page 17: Installation

    Unscrew the caps and then remove the grommets from the 3 pass through connectors. Note: Do not unscrew any of the pass throughs from the PoE Extender. These have been factory fitted and sealed to the correct torque setting. This product is copyright © 2017 CommScope, LLC. All Rights Reserved.
  • Page 18 Two Port PoE Extender Hardware Manual This product is copyright © 2017 CommScope, LLC. All Rights Reserved.

  • Page 19: Connect Ethernet Cables

    Connection from the PoE Extender to the Customer’s equipment should be via a Cat 5E / Cat 6 screened (STP) cable. CommScope recommend installing the cables in the following order, when facing the connector pass throughs: Left hand ethernet connection...

  • Page 20: Splitting The Powered Fiber Cable

    Repeat steps 1-7 for the right hand ethernet connection. Splitting the Powered Fiber Cable The CommScope Powered Fiber Cable consists of 2 copper power threads and a third containing the fiber threads. You need to separate the three cores to allow the power to be connected to the screw terminals, and the fiber thread to be connected to a fiber terminal, which is then inserted in to the SFP.

  • Page 21: Cable Split Dimensions

    Two Port PoE Extender Hardware Manual Cable Split Dimensions 23cm 75cm Figure: 3.1 Cable Split Dimensions This product is copyright © 2017 CommScope, LLC. All Rights Reserved.
  • Page 22 Two Port PoE Extender Hardware Manual Snip the cable end at the indentations in the cable jacket between the center fiber element and the two outer conductor elements. This product is copyright © 2017 CommScope, LLC. All Rights Reserved.
  • Page 23 Two Port PoE Extender Hardware Manual Peel one conductor side away to the desired length (75cm) by hand. This product is copyright © 2017 CommScope, LLC. All Rights Reserved.

  • Page 24: Sfp Relationship To Ethernet Ports

    The SFP relationship to the Ethernet ports is as follows: If both SFPs are connected, the bottom SFP data goes via Ethernet port one (nearest the • SFPs). The top SFP data goes via Ethernet port two. This product is copyright © 2017 CommScope, LLC. All Rights Reserved.

  • Page 25: Setting The Sfp Connection Speed

    By default both the PoE Extender SFP ports are configured for 1Gbit/s. If required you can configure one or both to 100Mbit/s. To change the default configuration: Remove the white fiber splice tray for the PoE Extender. This product is copyright © 2017 CommScope, LLC. All Rights Reserved.

  • Page 26: Connecting The Powered Fiber Cable To The Poe Extender

    Connecting the Powered Fiber Cable to the PoE Extender Thread the strands through the cap, then thread the strands through the supplied grommet. Use some silicone grease on the grommet, which helps pulling the strands through the This product is copyright © 2017 CommScope, LLC. All Rights Reserved.

  • Page 27: Connecting The Power Strands

    Use tape or heat shrink to prevent the cables splitting further than the required length. Thread the two cables in to the power connectors and tighten the screws. Note: Due to the cross-polarity protection, the circuit will work regardless of the input polarity. This product is copyright © 2017 CommScope, LLC. All Rights Reserved.

  • Page 28: Connecting The Fiber

    The fibers should wrap around the splice tray twice. The splice to the fiber connectors should sit in the splice island in the tray as below. This product is copyright © 2017 CommScope, LLC. All Rights Reserved.

  • Page 29: Sealing The Poe Extender

    Sealing the PoE Extender Ensure the supplied seal ring is seated in the channel of the PoE Extender and all cables are secured. Apply Loctite 222 to all lid bolts This product is copyright © 2017 CommScope, LLC. All Rights Reserved.

  • Page 30: Installing The Poe Extender To Wall Or Pole

    Installing the PoE Extender to Wall or Pole Installing to a Wall The PoE extender has 4 holes on the exterior of the device for attaching to a wall or flat surface. This product is copyright © 2017 CommScope, LLC. All Rights Reserved.

  • Page 31: Attaching An Earth Point

    A minimum 16AWG bonding connection from the PoE Extender to the Customer’s equip- ment earth terminal A minimum 16AWG bonding connection from the PoE Extender to a reliable earth (ground) point. Figure: 3.1 PoE Extender Earth Point This product is copyright © 2017 CommScope, LLC. All Rights Reserved.

  • Page 32: Installing To A Pole

    The PoE extender has 4 holes on the raised sections of the underneath of the device for attaching to a pole via fastenings such as jubilee clips. PoE pole mounted with solar shield This product is copyright © 2017 CommScope, LLC. All Rights Reserved.

  • Page 33: Operating Temperature Advice

    At the top of the Two Port PoE Extender’s operating temperature range, the physical temperature of the PoE Extender may exceed 70ºC. Ensure the supplied solar shield is in place for protection. See Table 4.2 on page 31 for operating temperature details. This product is copyright © 2017 CommScope, LLC. All Rights Reserved.
  • Page 34 Two Port PoE Extender Hardware Manual This product is copyright © 2017 CommScope, LLC. All Rights Reserved.

  • Page 35: Detailed Specifications

    C to +65 65°C assumes 45°C ambient air temperature, plus 20°C sun loading. Table 4.3: Physical Dimensions Item Specification Dimensions including solar shield 283mm x 225mm x 77mm Weight 3.8kg This product is copyright © 2017 CommScope, LLC. All Rights Reserved.
  • Page 36 Note: PoE standard IEEE 802.3 af (IEEE 802.3at type 1) assumes 12.95W power consumption. PoE+ standard (IEEE 802.3at type 2) assumes 25.5W. This product is copyright © 2017 CommScope, LLC. All Rights Reserved.
  • Page 37 Accepts all MSA compliant 100Base-X and 1000Base-X SFP transceivers Optical Input Singlemode ITU-T G657.A2 Optical Input 50um Multimode OM3 or OM4 RJ45 Connector Output Half and Full Duplex Modes Supported. 10/100/1000Mb Ethernet This product is copyright © 2017 CommScope, LLC. All Rights Reserved.

  • Page 38: Copyright, Trademarks And Commercial Disclaimer

    CommScope, Inc. All other trademarks are property of their respective owners. For planning purposes only. CommScope reserves the right to modify the specifications or product without notice. This document is not intended to modify or supplement any specifications or warranties relating to CommScope products or services.
