  • Page 1 Pioneering for You Wilo-Star-Z 15 TT en Installation and operating instructions da Monterings- og driftsvejledning Notice de montage et de mise en service hu Beépítési és üzemeltetési utasítás Inbouw- en bedieningsvoorschriften pl Instrukcja montażu i obsługi cs Návod k montáži a obsluze Instrucciones de instalación y funcionamiento Istruzioni di montaggio, uso e manutenzione ru Инструкция по монтажу и эксплуатации...

  • Page 2: Table Of Contents

    Basic display (exit menu)  Page 9 Connect  Page 10  The red button Page 8  Settings Page 11  Electrical connection Page 11  Safety Page 5  How it works Page 7  Installation Page 9 WILO SE 08/2015...
  • Page 3 Conversion, spares The pump must not be technically modified or converted. Only use original spares. Transport Unpack and check the pump and all accessories upon receipt. Report any damage that has occurred in transit immediately. Despatch the pump in the original packing only. Installation and operating instructions Wilo-Star-Z 15 TT...

  • Page 4: Connections

    140 mm Max. admissible operating 10 bar (1000 kPa) pressure Permitted fluid temperature 2 °C to 65 °C, range in short-term operation up to 2 hours 70 °C See name plate or Wilo catalogue for further information. WILO SE 08/2015...
  • Page 5 68 °C. Irrespective of the timer function, it then runs continuously for approximately 2 hours and then switches off again. Installation and operating instructions Wilo-Star-Z 15 TT...

  • Page 6: Valves

    The red button All menu settings are made using the red button: • Press for > 5 seconds 5 sec. 5 sec. Call up the menu. • Press briefly Select menu items and confirm the para- meters input. • Turn Set menu items and set parameters. WILO SE 08/2015...

  • Page 7: Mechanical Installation

    Installation site Choose a weatherproof, frost-free, dust-free and well-venti- lated room for the installation. Make sure that the installation site is easily accessible. Caution: Dirt can cause pump failure. Flush the pipe sys- tem before installation. Installation and operating instructions Wilo-Star-Z 15 TT...
  • Page 8 15 Nm (hand-tight). If the tightening torque is too high, this will destroy the valve screw connection and the O-ring. When installing the valve, use a wrench to prevent it from turn- ing! WILO SE 08/2015...

  • Page 9: To Set The Current Time

    6 Settings 6.1 To set the current time 5 sec. 2. Select clock (flashes). 5 sec. 3. Set the hours. 4. Set the minutes. 5. Select the basic display. Installation and operating instructions Wilo-Star-Z 15 TT...
  • Page 10 5 sec. 2. Select control system (flashes). 5 sec. 3. Set temperature. 65 °C Selection range 40-70 °C. Means that the temperature con- trol system is switched off. The pump continues to run independently of the return temperature. WILO SE 08/2015...
  • Page 11 Allow the pump to cool down first. Close the stop valves before removing the motor head. To replace the motor head  Page 10. 8 Spares Order the service motor from a trade specialist. Installation and operating instructions Wilo-Star-Z 15 TT...
  • Page 12 Avoid damage to the • Do not dispose of the pump in household waste. environment • Recycle the pump. • If in doubt, contact local authorities and specialist waste management companies. Note: For further information on recycling, see www.wilo-recycling.com. WILO SE 08/2015...
  • Page 13 Nous, fabricant, déclarons que les types de circulateurs de la série (Die Seriennummer ist auf dem Typenschild des Produktes angegeben / The serial number is Wilo-Star-Z 15 TT marked on the product site plate / Le numéro de série est inscrit sur la plaque signalétique du produit) in der gelieferten Ausführung folgenden einschlägigen Bestimmungen entsprechen :...
  • Page 14 WILO Norge AS Australia 2ILFLQD &RPHUFLDO :,/2 ,EžULFD 6$ Jakarta Timur, 13950 0975 Oslo WILO Australia Pty Limited (GLILFLR 6LPRQD $SWR   $OFDO– GH +HQDUHV T +62 21 7247676 T +47 22 804570 Murrarrie, Queensland, 6LERQH\ /D +DEDQD &XED...
  • Page 15 WILO SE Nortkirchenstraße 100 D-44263 Dortmund Germany T +49(0)231 4102-0 F +49(0)231 4102-7363 wilo@wilo.com Pioneering for You www.wilo.com...
