TB-FMCH-HDMI2 Hardware User Manual
TB-FMCH-HDMI2
Hardware User Manual
Rev.1.05
1
Rev.1.05

Advertisement

Table of Contents
loading

Related Manuals for Inrevium TB-FMCH-HDMI2

Summary of Contents for Inrevium TB-FMCH-HDMI2

  • Page 1 TB-FMCH-HDMI2 Hardware User Manual TB-FMCH-HDMI2 Hardware User Manual Rev.1.05 Rev.1.05...
  • Page 2 TB-FMCH-HDMI2 Hardware User Manual Revision History Version Date Description Publisher Rev.1.00 2011/02/01 Initial release Yoshioka Rev.1.01 2011/03/29 Modified Figure4-2, 4-3, 5-2, 5-3 Yoshioka Rev.1.02 2012/10/18 Add Table5-6 Yanagisawa Rev.1.03 2014/04/15 Add EC Declaration of Conformity Amano Rev.1.04 2014/08/13 Modify Table 5-7 Amano Rev.1.05...

  • Page 3: Table Of Contents

    TB-FMCH-HDMI2 Hardware User Manual Table of Contents Related Documents and Board Accessories ................8 Overview ............................8 Feature ............................9 TB-FMCH-HDMI2-RX ........................ 10 4.1. Block Diagram ......................... 10 4.2. External View of the Board ....................... 11 4.3. Board Specification ........................12 4.4.
  • Page 4 Figure 3-1 FMC Connector Pin Layout ....................9 Figure 4-1 TB-FMCH-HDMI2-RX Block Diagram................10 Figure 4-2 External View of TB-FMCH-HDMI2-RX (component side) ..........11 Figure 4-3 External View of TB-FMCH-HDMI2-RX (solder side) ............11 Figure 4-4 TB-FMCH-HDMI2-RX Board Dimensions ..............12 Figure 4-5 TB-FMCH-HDMI2-RX Power Supply Structure ..............
  • Page 5 TB-FMCH-HDMI2 Hardware User Manual Introduction Thank you for purchasing the TB-FMCH-HDMI2－RX/TB-FMCH-HDMI2-TX boards. Before using the product, be sure to carefully read this user manual and fully understand how to correctly use the product. First read through this manual, then always keep it handy.
  • Page 6 TB-FMCH-HDMI2 Hardware User Manual Warning In the event of a failure, disconnect the power supply. If the product is used as is, a fire or electric shock may occur. Disconnect the power supply immediately and contact our sales personnel for repair.
  • Page 7 TB-FMCH-HDMI2 Hardware User Manual Caution Do not use or place the product in the following locations.  Humid and dusty locations  Airless locations such as closet or bookshelf  Locations which receive oily smoke or steam  Locations exposed to direct sunlight ...

  • Page 8: Related Documents And Board Accessories

    Accessories: Interboard spacers and screws Interboard jumper cable 2. Overview The TB-FMCH-HDMI2 comes either with AnalogDevices’s HDMI Receiver "ADV7612BSWZ-P" or HDMI Transmitter "ADV7511KSTZ-P". (Collectively, there are called TB-FMCH-HDMI2. This document specifically describes these optional boards in the RX and TX sections respectively).

  • Page 9: Feature

    TB-FMCH-HDMI2 Hardware User Manual 3. Feature HDMI Devices Receiver : AnalogDevices’s ADV7612BSWZ-P Transmitter : AnalogDevices’s ADV7511KSTZ-P FMC Connector : Samtec’s ASP-134488-01 HDMI Connector (common) : Molex’s 5002541927 Power Supply (common) : Jumper switch selection The RX board has an EEPROM for Display Data Channel (hereafter referred to as DDC) and allows setting the AnalogDevices’s ADV7612BSWZ-P board operation via jumpers.

  • Page 10: Tb-Fmch-Hdmi2-Rx

    TB-FMCH-HDMI2 Hardware User Manual 4. TB-FMCH-HDMI2-RX 4.1. Block Diagram Figure 4-1 shows the TB-FMCH-HDMI2-RX block diagram. The FMC-HPC connector is mounted on the solder side of the board. FMC-HPC FPGA DEC#0 HDMI#0（RX) RX#0_P[35:0] RX#0_C、RX#0_0～2 RX#0_VS/HS/DE RX#0_DDCA_SCL LA[33:00]_P/N RX#0_LLC RX#0_DDCA_SDA HA[23:00]_P/N...

  • Page 11: External View Of The Board

    TB-FMCH-HDMI2 Hardware User Manual 4.2. External View of the Board Figures 4-2 and 4-3 show the external view of the TB-FMCH-HDMI2-RX board. Caution : This board has a plastic cover for protecting HDMI devices. Do not remove a plastic cover. FPGA...

  • Page 12: Board Specification

    TB-FMCH-HDMI2 Hardware User Manual 4.3. Board Specification The following shows TB-FMCH-HDMI2-RX board specifications. External Dimensions : W:160mm x H:69mm Number of Layers : 8 layers Board Thickness : 1.6 mm Material : FR-4 FPGA : Xilinx’s XC6SLX45-3FGG484C FMC Connector : Samtec’s ASP-134488-01 HDMI Connector : Molex’s 5002541927...

  • Page 13: Supplying Power To The Board

    TB-FMCH-HDMI2 Hardware User Manual 4.4. Supplying Power to the Board Figure 4-5 shows a TB-FMCH-HDMI2-RX power supply structure. VCC_12V_IN VCC_5V LT3503EDCB 24LCS22A: 3mA x2 = 6mA 135mA VCC_1.2V LT3568EDD （0.677W） FPGA_VCCINT : 485mA 562mA LT3503EDCB VCC_3.3V FPGA_VCAUX : 50mA FPGA_VCCIO : 29mA ADV7612 :　312.5mA x2 = 625mA...

  • Page 14: Hdmi Receiver

    TB-FMCH-HDMI2 Hardware User Manual 4.5. HDMI Receiver HDMI Connector uses a 5002541927 (MOLEX). HDMI Receiver uses an ADV7612BSWZ-P (Analog Devices). The following device is used as ESD protection. ESD protection: RCLAMP0524 and RCLAMP0504 (Semtech) Table 4-1 shows the HDMI connector pin assignments.

  • Page 15: Fmc Connector

    FMC Connector The FMC connector (High-Pin Count) connecting to the main board uses an ASP-134488-01 (SAMTEC). Power to the TB-FMCH-HDMI2-RX is supplied from a +12V on the main board. An external power source can also be used. Table 4-3 shows JP1 jumper setting for power supply.

  • Page 16: Table 4-4 Fmc Connector Pin Assignment

    TB-FMCH-HDMI2 Hardware User Manual Table 4-4 shows the FMC connector pin assignment. Table 4-4 FMC Connector Pin Assignment A-row B-row C-row D-row E-row RES1 PG_C2M DP1_M2C_P DP0_C2M_P HA01_P_CC DP1_M2C_N DP0_C2M_N HA01_N_CC DP9_M2C_P GBTCLK0_M2C_P DP9_M2C_N GBTCLK0_M2C_N DP2_M2C_P DP0_M2C_P HA05_P DP2_M2C_N DP0_M2C_N...
  • Page 17 TB-FMCH-HDMI2 Hardware User Manual F-row G-row H-row J-row K-row PG_M2C VREF_A_M2C VREF_B_M2C CLK1_M2C_P PRSNT_M2C_L CLK3_M2C_P CLK1_M2C_N CLK3_M2C_N HA00_P_CC CLK0_M2C_P CLK2_M2C_P HA00_N_CC CLK0_M2C_N CLK2_M2C_N LA00_P_CC HA03_P LA00_N_CC LA02_P HA03_N HA02_P HA04_P LA02_N HA02_N HA04_N LA03_P HA07_P LA03_N LA04_P HA07_N HA06_P HA08_P...

  • Page 18: Other Interfaces

    TB-FMCH-HDMI2 Hardware User Manual 4.7. Other Interfaces The board also has the following interfaces. 4.7.1. EEPROM Interface I2C interface used to control the EEPROM from the FPGA EEPROM device: 24LCS22A-SN (Micro Chip) 4.7.2. JTAG Interface JTAG connector for FPGA configuration...

  • Page 19: Led Status

    TB-FMCH-HDMI2 Hardware User Manual 4.8. LED Status Table 4-6 shows the onboard LEDs. Table 4-6 LED Status Circuit # Silk Purpose Description LED0 General-purpose LED0 [RX0]I2C config state Off: CFG done / On: CFG active LED1 General-purposeLED1 [RX0]I2C read back...

  • Page 20: Fpga Pin Assignment

    TB-FMCH-HDMI2 Hardware User Manual 4.10. FPGA Pin Assignment Table 4-8 shows the FPGA pin assignment. In case of 8-bit signal format, active bits are assigned to MSB 8-bit of each RGB pin of FMC. LSB 2-bit are always 2'b00 in 8-bit signal format.
  • Page 21 TB-FMCH-HDMI2 Hardware User Manual Pin Name Spec Description LA00_N_CC LVCMOS25 RX#1_VSYNC signal (FPGA to FMC) LA01_N_CC LVCMOS25 RX#1_HSYNC signal (FPGA to FMC) LA02_N LVCMOS25 RX#1_DE signal (FPGA to FMC) LA03_N LVCMOS25 RX#1_P0 signal (FPGA to FMC) [B0] LA04_N LVCMOS25 RX#1_P1 signal (FPGA to FMC)
  • Page 22 TB-FMCH-HDMI2 Hardware User Manual Pin Name Spec Description HA06_P LVCMOS25 Unused HA07_P LVCMOS25 Unused HA08_P LVCMOS25 Unused HA09_P LVCMOS25 Unused HA10_P LVCMOS25 Unused HA11_P LVCMOS25 Unused HA12_P LVCMOS25 Unused HA13_P LVCMOS25 Unused HA14_P LVCMOS25 Unused HA15_P LVCMOS25 Unused HA16_P LVCMOS25...
  • Page 23 TB-FMCH-HDMI2 Hardware User Manual Pin Name Spec Description HA22_N LVCMOS25 Unused HA23_N LVCMOS25 Unused RX#0_P35 LVCMOS33 RX#0 Video data 35 (RX to FPGA) RX#0_P34 LVCMOS33 RX#0 Video data 34 (RX to FPGA) RX#0_P33 LVCMOS33 RX#0 Video data 33 (RX to FPGA)
  • Page 24 TB-FMCH-HDMI2 Hardware User Manual Pin Name Spec Description SYSCLK_P LVCMOS33 System Clock (27MHz) RX#0_HSYNC LVCMOS33 RX#0 HSYNC (RX to FPGA) RX#0_VSYNC LVCMOS33 RX#0 VSYNC (RX to FPGA) RX#0_SPDIF AA10 LVCMOS33 RX#0 SPDIF Digital Audio (RX to FPGA) RX#0_I2S0 AB10 LVCMOS33...
  • Page 25 TB-FMCH-HDMI2 Hardware User Manual Pin Name Spec Description RX#1_P13 LVCMOS33 RX#1 Video Data 13 (RX to FPGA) RX#1_P12 LVCMOS33 RX#1 Video Data 12 (RX to FPGA) RX#1_P11 LVCMOS33 RX#1 Video Data 11 (RX to FPGA) RX#1_P10 LVCMOS33 RX#1 Video Data 10 (RX to FPGA)
  • Page 26 TB-FMCH-HDMI2 Hardware User Manual Pin Name Spec Description DSW2 LVCMOS33 DIP Switch 2 DSW3 LVCMOS33 DIP Switch 3 DSW4 LVCMOS33 DIP Switch 4 DSW5 LVCMOS33 DIP Switch 5 DSW6 LVCMOS33 DIP Switch 6 DSW7 LVCMOS33 DIP Switch 7 LED0 LVCMOS33...

  • Page 27: Fpga Output Data Phase

    TB-FMCH-HDMI2 Hardware User Manual 4.11. FPGA Output Data Phase Figure 4-6 shows the output data phase of FPGA on TB-FMCH-HDMI2-RX. FPGA to FMC data is output at the falling edge of the video clock. The data should be latched at the rising edge on the main board side.

  • Page 28: Image Size

    TB-FMCH-HDMI2 Hardware User Manual 4.12. Image Size 4.12.1. 2D Image Size TB-FMCH-HDMI2-RX supports HDMI1.4-compliant primary format and part of secondary format (1080p@60Hz). Supported image size:  640x480p@59.94/60Hz  1280x720p@59.94/60Hz  1920x1080i@59.94/60Hz  720x480p @ 59.94/60Hz  720(1440)x480i@59.94/60Hz  1280x720@50Hz ...

  • Page 29: Tb-Fmch-Hdmi2-Tx

    TB-FMCH-HDMI2 Hardware User Manual 5. TB-FMCH-HDMI2-TX 5.1. Block Diagram Figure 5-1 shows a TB-FMCH-HDMI2-TX block diagram. The FMC-HPC connector is mounted on the solder side of the board. FMC-HPC FPGA ENC#0 HDMI#0（TX) TX#0_D[35:0] TX#0_C、TX#0_0～2 TX#0_VS/HS/DE TX#0_DDCA_SCL LA[33:00]_P/N TX#0_CLK TX#0_DDCA_SDA HA[23:00]_P/N...

  • Page 30: External View Of The Board

    TB-FMCH-HDMI2 Hardware User Manual 5.2. External View of the Board Figures 5-2 and 5-3 show the external view of the TB-FMCH-HDMI2-TX board. FPGA HDMI Transmitter HDMI Connector Figure 5-2 TB-FMCH-HDMI2-TX (component side) FMC-HPC Figure 5-3 TB-FMCH-HDMI2-TX (solder side) Rev.1.05...

  • Page 31: Board Specification

    TB-FMCH-HDMI2 Hardware User Manual 5.3. Board Specification Figure 5-4 shows the TB-FMCH-HDMI2-TX board specification. External Dimensions : W:160mm x H:69mm Number of Layers : 8 Layers Board Thickness : 1.6 mm Material : FR-4 FPGA : Xilinx’s XC6SLX45-3FGG484C FMC Connector : Samtec’s ASP-134488-01...

  • Page 32: Power Supply To The Board

    TB-FMCH-HDMI2 Hardware User Manual 5.4. Power Supply to the Board Figure 5-5 shows the TB-FMCH-HDMI2-TX power supply structure. VCC_12V_IN VCC_5V LT3503EDCB ADG702: 0.001mA x2 = 0.002mA 134mA VCC_1.2V LT3568EDD （0.671W） FPGA_VCCINT : 503mA 349mA LT3503EDCB VCC_3.3V FPGA_VCAUX : 68mA FPGA_VCCIO : 311mA ADV7511 :　0.3mA x2 = 0.6mA...

  • Page 33: Hdmi Transmitter

    TB-FMCH-HDMI2 Hardware User Manual 5.5. HDMI Transmitter The HDMI connector uses MOLEX’s 5002541927. The HDMI transmitter uses Analog Devices’s ADV7511KSTZ-P. The following device is used for ESD protection: ESD protection: Semtech’s RCLAMP0524 and RCLAMP0504 Table 5-1 shows the HDMI connector pin assignment.

  • Page 34: Fmc Connector

    FMC Connector The FMC connector connecting to the High-Pin Count uses SAMTEC’s ASP-134488-01. Power to the TB-FMCH-HDMI2-TX is supplied from a +12V on the main board. An external power source can also be used. Table 5-2 shows JP3 jumper setting for power supply.

  • Page 35: Table 5-3 Fmc Connector Pin Assignment

    TB-FMCH-HDMI2 Hardware User Manual Table 5-3 shows the FMC connector pin assignment. Table 5-3 FMC Connector Pin Assignment A-row B-row C-row D-row E-row RES1 PG_C2M DP1_M2C_P DP0_C2M_P HA01_P_CC DP1_M2C_N DP0_C2M_N HA01_N_CC DP9_M2C_P GBTCLK0_M2C_P DP9_M2C_N GBTCLK0_M2C_N DP2_M2C_P DP0_M2C_P HA05_P DP2_M2C_N DP0_M2C_N...
  • Page 36 TB-FMCH-HDMI2 Hardware User Manual F-row G-row H-row J-row K-row PG_M2C VREF_A_M2C VREF_B_M2C CLK1_M2C_P PRSNT_M2C_L CLK3_M2C_P CLK1_M2C_N CLK3_M2C_N HA00_P_CC CLK0_M2C_P CLK2_M2C_P HA00_N_CC CLK0_M2C_N CLK2_M2C_N LA00_P_CC HA03_P LA00_N_CC LA02_P HA03_N HA02_P HA04_P LA02_N HA02_N HA04_N LA03_P HA07_P LA03_N LA04_P HA07_N HA06_P HA08_P...

  • Page 37: Other Interfaces

    TB-FMCH-HDMI2 Hardware User Manual 5.7. Other Interfaces The board also provides the following interfaces. 5.7.1. JTAG Interface The board has a JTAG connector FPGA configuration. JTAG Connector: Molex’s 87832-1420 Table 5-4 JTAG Connector Signal Signal Name 3.3V 5.7.2. General-Purpose Clock Interface The board has a general-purpose clock on FPGA (27MHz crystal oscillator) KC5032C027.0000C30E00 (Kyocera)

  • Page 38: Led Status

    12V display On: 12V active 5.9. Relation of ROM and Input Video Format TB-FMCH-HDMI2-RX and TB-FMCH-HDMI2-TX have 3 types of FPGA ROM. Relation between ROM and Input Format is below. Table 5-6 Relation of ROM and Input Video Format HDMI...

  • Page 39: Control Function

    TB-FMCH-HDMI2 Hardware User Manual 5.10. Control Function Table 5-7 shows the onboard switch function. Table 5-7 Switch Function Circuit # Silk Description S1-1 ADV7511 config ROM selection: 8bit Output : S1-1 OFF, S1-2 ON, S1-3 ON, S1-4 ON S1-2 10bit Output : S1-1 ON, S1-2 ON, S1-3 OFF, S1-4 ON...

  • Page 40: Fpga Pin Assignment

    TB-FMCH-HDMI2 Hardware User Manual 5.11. FPGA Pin Assignment Table 5-8 shows the FPGA pin assignment. In case of 8-bit signal format, active bits are assigned to MSB 8-bit of each RGB pin of FMC. LSB 2-bit are always 2'b00 in 8-bit signal format.
  • Page 41 TB-FMCH-HDMI2 Hardware User Manual Pin Name Spec. Description LA00_N_CC LVCMOS25 TX#1_VSYNC Signal (FMC to FPGA) LA01_N_CC LVCMOS25 TX#1_HSYNC Signal (FMC to FPGA) LA02_N LVCMOS25 TX#1_DE Signal (FMC to FPGA) LA03_N LVCMOS25 TX#1_D0 Signal (FMC to FPGA) [B0] LA04_N LVCMOS25 TX#1_D1 Signal (FMC to FPGA)
  • Page 42 TB-FMCH-HDMI2 Hardware User Manual Pin Name Spec. Description HA06_P LVCMOS25 Unused HA07_P LVCMOS25 Unused HA08_P LVCMOS25 Unused HA09_P LVCMOS25 Unused HA10_P LVCMOS25 Unused HA11_P LVCMOS25 Unused HA12_P LVCMOS25 Unused HA13_P LVCMOS25 Unused HA14_P LVCMOS25 Unused HA15_P LVCMOS25 Unused HA16_P LVCMOS25...
  • Page 43 TB-FMCH-HDMI2 Hardware User Manual Pin Name Spec. Description HA22_N LVCMOS25 Unused HA23_N LVCMOS25 Unused TX#0_D35 LVCMOS33 TX#0 Video data 35 (FPGA to TX) TX#0_D34 LVCMOS33 TX#0 Video data 34 (FPGA to TX) TX#0_D33 LVCMOS33 TX#0 Video data 33 (FPGA to TX)
  • Page 44 TB-FMCH-HDMI2 Hardware User Manual Pin Name Spec. Description TX#0_VSYNC LVCMOS33 TX#0 VSYNC (FPGA to TX) TX#0_DSD0 LVCMOS33 TX#0 DSD Audio data 0 (FPGA to TX) TX#0_DSD1 LVCMOS33 TX#0 DSD Audio data 1 (FPGA to TX) TX#0_DSD2 LVCMOS33 TX#0 DSD Audio data 2 (FPGA to TX)
  • Page 45 TB-FMCH-HDMI2 Hardware User Manual Pin Name Spec. Description TX#1_D15 LVCMOS33 TX#1 Video data 15 (FPGA to TX) TX#1_D14 LVCMOS33 TX#1 Video data 14 (FPGA to TX) TX#1_D13 LVCMOS33 TX#1 Video data 13 (FPGA to TX) TX#1_D12 LVCMOS33 TX#1 Video data 12 (FPGA to TX)
  • Page 46 TB-FMCH-HDMI2 Hardware User Manual Pin Name Spec. Description RSW2 LVCMOS33 Rotary switch 2 RSW3 LVCMOS33 Rotary switch 3 DSW0 LVCMOS33 DIP switch 0 DSW1 LVCMOS33 DIP switch 1 DSW2 LVCMOS33 DIP switch 2 DSW3 LVCMOS33 DIP switch 3 DSW4 LVCMOS33...

  • Page 47: Fpga Input Data Phase

    TB-FMCH-HDMI2 Hardware User Manual 5.12. FPGA Input Data Phase Figure 5-6 shows the input data phase of the FPGA on the TB-FMCH-HDMI2-TX. FMC connector to FPGA data is captured by the FPGA at the rising edge of a video clock. Data from the main board is transferred at the falling edge of a video clock.

  • Page 48: Image Size

    TB-FMCH-HDMI2 Hardware User Manual 5.13. Image Size 5.13.1. 2D Image Size TB-FMCH-HDMI2-TX supports HDMI1.4-compliant primary format and part of secondary format (1080p@60Hz). Supported image size:  640x480p@59.94/60Hz  1280x720p@59.94/60Hz  1920x1080i@59.94/60Hz  720x480p @ 59.94/60Hz  720(1440)x480i@59.94/60Hz  1280x720@50Hz ...

  • Page 49: Ddc Connection (Normal/ Through)

    TB-FMCH-HDMI2 Hardware User Manual 6. DDC Connection (Normal/ Through) Two types of DDC connections are supported: 6.1. DDC Connection (Normal) Table 6-1 shows DDC connection jumper setting (Normal) and Figure 6-1 shows DDC connection structure. Table 6-1 DDC Jumper Setting (Normal)

  • Page 50: Ddc Connection (Through)

    TB-FMCH-HDMI2 Hardware User Manual 6.2. DDC Connection (Through) Table 6-2 shows DDC connection jumper setting (Through) and Figure 6-2 shows DDC connection structure (Through). Table 6-2 DDC Jumper Setting (Through) TB-FMCH-HDMI2-RX TB-FMCH-HDMI2-TX Jumper Setting Jumper Setting JP6: SCL0 Open JP7: SDA0...

  • Page 51: Default Switch Setting

    TB-FMCH-HDMI2 Hardware User Manual 7. Default Switch Setting Figure 7-1 shows default TB-FMCH-HDMI2-RX switch settings (portions enclosed by dotted lines). JP7、JP12、JP10、JP8 JP6、JP11、JP9 JP4、JP3、JP16、JP14 JP17、JP15、JP13 Figure 7-1 TB-FMCH-HDMI2-RX Default Switch Settings (component side) Table 7-1 TB-FMCH-HDMI2-RX Default Settings (JP pin) Silk No.

  • Page 52: Table 7-2 Tb-Fmch-Hdmi2-Rx Default Setting (Dsw/Rsw)

    TB-FMCH-HDMI2 Hardware User Manual Table 7-2 TB-FMCH-HDMI2-RX Default Setting (DSW/RSW) Silk No. Default Setting S1-1 S1-2 S1-3 S1-4 S1-5 S1-6 S1-7 S1-8 For the setting at the time of use, refer to Table 4-7 Switches Rev.1.05...

  • Page 53: Figure 7-2 Tb-Fmch-Hdmi2-Tx Default Settings (Component Side)

    TB-FMCH-HDMI2 Hardware User Manual Figure 7-2 shows TB-FMCH-HDMI2-TX default switch settings (portions enclosed by dotted lines). JP8、JP5、JP4、JP6 JP12 JP13、JP10、JP9、JP11 Figure 7-2 TB-FMCH-HDMI2-TX Default Settings (component side) Table 7-3 TB-FMCH2-TX Default Settings (JP Pin) Silk No. Initial Setting Function 1-2 short...

  • Page 54: Table 7-4 Tb-Fmch-Hdmi2-Tx Default Switch Settings (Dsw/Rsw)

    TB-FMCH-HDMI2 Hardware User Manual Table 7-4 TB-FMCH-HDMI2-TX Default Switch Settings (DSW/RSW) Silk No. Default Setting S1-1 S1-2 S1-3 S1-4 S1-5 S1-6 S1-7 S1-8 For the setting at the time of use, refer to Table 5-7 Switch Function. Rev.1.05...

  • Page 55: Usage Example

    8. Usage Example Figure 8-1 shows a usage example. Be careful about the jumper setting of the TB-6S-LX150T-IMG2 main board. If the image is not output, push the S3 of the TB-FMCH-HDMI2-RX or TB-FMCH-HDMI2-TX for only a short period of time. TB-FMCH-HDMI2-RX...
  • Page 56 TB-FMCH-HDMI2 Hardware User Manual Rev.1.05...
  • Page 57 TB-FMCH-HDMI2 Hardware User Manual PLD Solution Dept. PLD Division URL: http://solutions.inrevium.com/ E-mail: psd-support@teldevice.co.jp HEAD Quarter: Yokohama East Square, 1-4 Kinko-cho, Kanagawa-ku, Yokohama City, Kanagawa, Japan 221-0056 TEL: +81-45-443-4016 FAX: +81-45-443-4058 Rev.1.05...
