Page 1: User Manual
USER MANUAL MINI Pro/E-FAT BIKE IMPORTANT! In order to ensure your safety and get the most from your product please read this Manual carefully before first use. www.ecomotionbikes.com | contact@ecomotionbikes.com EcoMotion Bikes... -
Page 2: Table Of Contents
Tips for proper use 14-15 Bicycle maintenance 16-17 The battery 17-19 Dismounting / mounting of battery from the bicycle Emphases for battery charging 20-21 Preserving of battery's lifespan 21-22 Warranty, liability and company's policies Problems & solutions 23-24 EcoMotion Bikes... -
Page 3: Important General Information And Warnings
Accidents / falls may cause severe injuries and in extreme cases even to death! Please read this user manual responsibly, with care and judiciousness! Also always make sure that the bicycle is in order by using this user manual prior to riding! EcoMotion Bikes... -
Page 4: Definitions
PAS - Pedal Assist Sensor - Sensor which is located near the pedals’ axis, recognizes the pedals movement and operates the motor accordingly. TAG - Twist And Go - The motor is activated while twisting the throttle, that is located on the handlebar. Main parts location: EcoMotion Bikes... -
Page 5: General Information
Make sure that the handlebars’ wires are loose and not tight onto the frame / fork so the fork can move freely to the sides without resistance. EcoMotion Bikes... - Page 6 WARNING! To avoid component breakage, when raising the handlebar, make sure the safety line is unrevealed to the eye! EcoMotion Bikes...
- Page 7 5. Assemble the seat into the frame, and lock it into its place with its hoop. EcoMotion Bikes...
- Page 8 6. Assemble bicycle pedals 7. Tighten handlebar stem EcoMotion Bikes...
-
Page 9: Folding Of The Bicycle
Folding the handlebar: (1) Open the folding mechanism lock. (2) Pull the lever down. (3) Fold the handlebar. Rising the handlebar: (3) Straighten the handlebar. (2) Lock the folding lever. (1) Lock the folding mechanism lock. EcoMotion Bikes... -
Page 10: Bicycle Prepare / Inspection Prior To Riding
It is recommended to adjust the seat in the way that the user’s feet are touching the ground . Important! – To avoid component breakage, when raising the seat, make sure that its safety line is unrevealed to the eye! EcoMotion Bikes... - Page 11 Make sure that the wheel spokes are tightly screwed and are not loose. And that the wheels are not missing any of them. Be sure to check that all of the bicycle’s bearings are operating and rotating freely (are not jittery or vibrating). EcoMotion Bikes...
- Page 12 Make sure the bicycle’s battery is functioning and any physical pulping or damage does not appear on it. Make sure that the battery is properly mounted on the bicycle prior to use. Make sure that the TAG / PAS systems are properly functioning. EcoMotion Bikes...
-
Page 13: Operating Of Bicycle's Electric System
Operating the motor by using the TAG system: A throttle is located on the right side of the handlebar. While turning the throttle, the motor goes into action. The bicycle can be used as a regular bicycle while the electric system is off. EcoMotion Bikes... -
Page 14: Tips For Proper Use
It is recommended to wear a proper bicycle helmet for riding, even if this is not mandated by law in certain situations. All applicable laws and regulations should be read carefully before using the electric bicycle. You must comply with traffic laws and regulations. EcoMotion Bikes... - Page 15 Using the bicycle near the beach exposes it to salt & humidity. The bicycle ought to be cleaned and oiled more frequently if used in such areas, to make sure that the components do not rust and malfunction. EcoMotion Bikes...
-
Page 16: Bicycle Maintenance
The bicycle should be cleaned using a wet cloth only (do not pour / spray water directly onto the bicycle). After cleaning the bicycle, the metal parts, that are not aluminum, should be oiled. All bicycle’s moving components should be cleaned on a regular basis. EcoMotion Bikes... -
Page 17: The Battery
Do not store them where it can be exposed to rain or poor weather. The battery: This battery model is a chargeable Lithium Polymer battery powered by LG cells. It is highly recommend that the battery will be charged in full prior to use. EcoMotion Bikes... - Page 18 , and in most extreme cases cause battery explosion! Recommended storage temperature for the battery is between 32°F - 72°F! WARNING! Avoid exposing the battery to extreme temperatures (104°F or higher) for prolonged period! EcoMotion Bikes...
-
Page 19: Dismounting / Mounting Of Battery From The Bicycle
IMPORTANT! Make sure that while mounting the battery back onto the frame, the battery is sliding on its allocated rail, if the battery is misplaced it may get stuck. EcoMotion Bikes... -
Page 20: Emphases For Battery Charging
Do not place the battery and / or the charger near flammable substances during charging. The battery works better when it is fully charged, it is recommended to begin riding when battery is fully charged. EcoMotion Bikes... -
Page 21: Preserving Of Battery's Lifespan
Average battery lifespan depends on its use and on its conditions. Even with proper care, rechargeable batteries do not last forever. This battery model will last between 700-1000 charging cycles. A partial charge/discharge counts fractionally against those EcoMotion Bikes... -
Page 22: Warranty, Liability And Company's Policies
In case of product malfunction that you cannot solve by yourself according to this manual guide, please contact us at: warranty@ecomotionbikes.com For more information regarding our company’s policies including warranty & Liability, please visit us on: www.ecomotionbikes.com EcoMotion Bikes... -
Page 23: Problems & Solutions
PAS magnets away Attached the magnets to the from sensor sensor and retest PAS system doesn't work Faulty PAS sensor Replace the sensor and retest Faulty controller Replace controller and retest Display rupture wire Replace the display and retest EcoMotion Bikes... - Page 24 Charger indicator light flashes and not change Faulty charger Replace the charger into red (not charging) Loose connector Check all connectors Bicycle has intermittent Loose fuse Check fuse connector power Damaged wires Inspect all wires EcoMotion Bikes...
