4.6

Setting the armature-voltage range

Analog control mode
Digital control mode
4.6.1 Procedure
Set jumper LK2 as follows:
Maximum armature voltage
0 ~ ±470V
4.7

Setting the maximum and minimum field current

Analog control mode
External control of the field-current
Internal control of the field-current
During the following procedures, you will be required to apply AC power to the
FXM5 controller and the motor. Before applying AC power, ensure the following:
The controller is correctly connected
WARNING
The controller cover is securely fitted
22
Figure 4-8 Location of jumper LK2
Setting
>±470V
