technIcal SpecIfIcatIonS:

input impedance:
sensivity:
impedance EFFFECTS LOOP
EFFECT SEND:
EFFECT RETURN/LINE IN: 100 kOhm
nominal output:
impedance LINE OUT:
Nennpegel LINE OUT:
impedance DI:
nominal output DI:
DI OUT
GRD LIFT
POST MASTER GROUND
18 19
Input: 1 mOhm
-10DB: 120kOhm
Input: max -26 dBu
-10 DB: max -20 dBu
2 kOhm
0 dBu
600 Ohm
+6 db
600 Ohm
+6 dBu
SPEAKER OUTPUT
20
TONE CONTROL SECTION:
LO:
LO MID:
HI MID:
HI:
Output power:
Fuse:
230V/AC
115V/AC
Bias:
dimensions (W x H x D):
weight:
11
IMPEDANCE
2
4
8
21
30Hz/+-15dB
200Hz/+-15dB
800Hz/+-15dB
8k/+-15dB
300 Watt RMS
6,3 A/T (Slow Blow)
12 A/T (Slow Blow)
50mA/tube
60 cm x 26 cm x 31 cm
23.7" x 10.3" x 12.2"
25 kg / 55.12 lbs
