Long Range CCD Barcode Scanner
- MS340 -
User's Manual
Version 1.2
© 2015 unitech Electronics Co., Ltd. All rights reserved.
unitech is a registered trademark of unitech Electronics Co., Ltd

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS340 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Unitech MS340

  • Page 1 Long Range CCD Barcode Scanner - MS340 - User's Manual Version 1.2 © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd...
  • Page 2: Revision History

    2016/1/8  Delete 4.2.4- WAND emulation  Update 4.4 – Reading level 4.1.2 Reading Mode Selection-- Replace Auto sense to presentation © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd...
  • Page 3: Preface

    –Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. –Consult the dealer or an experienced radio/TV technician for help. © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 4 Interference-Causing Equipment Regulations. Cet appareil numerique de la classe B respecte les exigences du Reglement sur le material broilleur du Canada. © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 5 European Conformity Statement unitech Electronics co., Ltd herewith declares that the unitech product is in compliance with the essential requirements and all other provisions of the R&TTE 1999/5/EC directive, the EMC 2004/108/EC directive and the Low Voltage 2006/95/EC directive. The declaration of conformity is available for download at : https://portal.unitech.eu/public/Safetyregulatorystatement...
  • Page 6 Taiwan NCC Warning Statement 交通部電信總局低功率電波輻射性電機管理辦法 第十二條:經型式認證合格之低功率射頻電機,非經許可,公司、商號或使用者 均不得擅自變更頻率、加大功率或變更原設計之特性及功能。 第十四條:低功率射頻電機之使用不得影響飛航安全及干擾合法通信;經發現有 干擾現象時,應立即停用,並改善至無干擾時方得繼續使用。 低功率射頻電機需忍受合法通信或工業、科學及醫療用電波輻射性電機設備 之干擾。 注意事項: 1. 使用過度恐傷害視力。 2. 使用30分鐘請休息10分鐘;2歲以下幼兒不看螢幕,2歲以上每天看螢幕不要超過 1小時。 © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 7 Laser Information The unitech product is certified in the U.S. to conform to the requirements of DHHS/CDRH 21CFR Subchapter J and to the requirements of IEC 825-1. Class II and Class 2 products are not considered to be hazardous. The unitech product contains internally a Visible Laser Diode (VLD) whose emissions do not exceed the maximum limits as set forth in the above regulations.
  • Page 8 It may not be functional anymore. Please only use the original battery from unitech. Using a third party battery can damage our products. Please note that when such damage occurs, it is not covered by your warranty.
  • Page 9 Please follow the limitation of suggested temperature conditions to avoid failure, damage or malfunction. *For applicable temperature conditions, please refer to the specification of each product. © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 10 Please remove the power adapter when the battery is fully recharged. The bundled power adapter that comes with your unitech product is not meant to be used outdoors. An adapter exposed to water or rain, or a very humid environment can cause damage to both the adapter and the product.
  • Page 11 Worldwide Support unitech’s professional support team is available to quickly answer questions or assist with technical-related issues. Should an equipment problem occur, please contact the nearest unitech regional service representative. For complete contact information please visit the Web sites listed below: Taipei, Taiwan –...
  • Page 12 The warranty period is varied from each country. Please consult with your supplier or unitech local office for actual length of warranty period to your purchased product. Warranty becomes void if equipment is modified, improperly installed or used, damaged by accident or neglect, or if any parts are improperly installed or replaced by the user.
  • Page 13: Table Of Contents

    3.6 Industrial 25 Parameters ..............18 3.7 Matrix 25 Parameters ................19 3.8 CODABAR/NW7 Parameters ...............20 3.9 Code 93 Parameters ................22 3.10 Code 11 Parameters................23 © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 14 4.10 Setup Insertion ...................44 Appendix A –Numeric Bar Codes............47 Appendix B –ASCII Table...............48 Appendix C –Function Key Table............52 Appendix D–Numeric Bar Codes2............53 © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 15: Regulatory Compliance Statements

    Chapter 1 - Overview 1.1 Package Please make sure the following contents are in the MS340 gift box. If something is missing or damaged, please contact your unitech representative. The standard package contents: MS340 Scanner  Quick Start Guide ...
  • Page 16: Scanner Detail

    1.2 Scanner Detail Scan Window Trigger Cable connector LED indicator Pin-hole © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 17: Specifications

    Printing Contrast Scale minimum 30% Decoding Supports most standard 1D bar code, GS1 Databar linear and stacked Codes Depth of Field (DOF Code39 PCS=90% ) © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 18 Operating 0°C to 50°C Temperature Storage -20°C to 70°C Temperature Relative Humidity 20% to 95% non-condensing Regulation Approvals CE, FCC, BSMI, VCCI © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 19: Getting Started

    “click” when the connection is made. Step 2: Installing the scanner to the Host System: 1. Connect the USB cable of MS340 to the USB port on your host PC. 2. After six beeps, MS340 is successfully connected with your host PC, then the driver will be started to install automatically.
  • Page 20: Pin Assignment

    1. PC Keyboard Output DIN 5 Male DIN 5 Female MiniDIN 6 Male MiniDIN 6 Female 2. RS232 Output DB 9 Female © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 21: Led Indicator / Beeper Sequence

    Data sent to PC Green Light blinks once One Beep successfully Barcode reading Fail sent data to PC No action No action © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 22: Chapter 2 - Configuration-General

    Chapter 2 – Configuration-General 2.1 Flow Chart *Please scan the following barcodes for configuration Start Configuration End Configuration Abort Configuration Save Parameters © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 23: Loop Of Programming

    By scanning “Set All Default” label, the settings will go back to the factory default settings. ( Please refer to – Main Page of Configuration) © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 24: Main Page Of Configuration

    Set AII Defaults - Set all the parameters to the factory default settings. Abort Configuration - Terminate current programming status. Version Information - Display the decoder version information and date code. © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 25: Chapter 3 -Bar Codes & Others

    Code 2 of 6 ON Code 2 of 6 OFF * Interleave 25 ON * Interleave 25 OFF LCD25 ON LCD25 OFF * © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 26 Reserved5 OFF * OFF * GS1 DataBar GS1 DataBar Reserved6 ON Reserved6 OFF * Expanded ON Expanded OFF * Select All Bar Codes © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 27: Upc/Ean/Jan Parameters

    Supplement Supplement * Expand UPC-E Expand UPC-E Disable * Enable EAN8=EAN13 EAN8=EAN13 Disable * Enable GTIN Format GTIN Format Enable Disable * © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 28 EAN-13 Check Digit Transmission ON * EAN-13 Check Digit Transmission OFF ISSN Check Digit Transmission ON * ISSN Check Digit Transmission OFF © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 29: Code 39 Parameters

    3. 2 Set Complete 2. Numeric Bar Codes (Appendix A) Minimum Length 1. Begin 3. Complete 2. Numeric Bar Codes (Appendix A) © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 30: Code 128 Parameters

    3. 2 Set Complete 2. Numeric Bar Codes (Appendix A) Minimum Length 1. Begin 3. Complete 2. Numeric Bar Codes (Appendix A) © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 31: Interleave 25 Parameters

    3. 2 Set Complete 2. Numeric Bar Codes (Appendix A) Minimum Length 1. Begin 3. Complete 2. Numeric Bar Codes (Appendix A) © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 32: Industrial 25 Parameters

    3. 2 Set Complete 2. Numeric Bar Codes (Appendix A) Minimum Length 1. Begin 3. Complete 2. Numeric Bar Codes (Appendix A) © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 33: Matrix 25 Parameters

    3. 2 Set Complete 2. Numeric Bar Codes (Appendix A) Minimum Length 1. Begin 3. Complete 2. Numeric Bar Codes (Appendix A) © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 34: Codabar/Nw7 Parameters

    A/B/C/D Start * A/B/C/D Stop * A Start A Stop B Start B Stop C Start C Stop D Start D Stop © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 35 Set Begin 3. 2 Complete 2. Numeric Bar Codes (Appendix A) Minimum Length 1. Begin 3. Complete 2. Numeric Bar Codes (Appendix A) © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 36: Code 93 Parameters

    3. 2 Set Complete 2. Numeric Bar Codes (Appendix A) Minimum Length 1. Begin 3. Complete 2. Numeric Bar Codes (Appendix A) © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 37: Code 11 Parameters

    3. 2 Set Complete 2. Numeric Bar Codes (Appendix A) Minimum Length 1. Begin 3. Complete 2. Numeric Bar Codes (Appendix A) © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 38: Msi/Plessey Code Parameters

    3. 2 Set Complete 2. Numeric Bar Codes (Appendix A) Minimum Length 1. Begin 3. Complete 2. Numeric Bar Codes (Appendix A) © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 39: Code 2 Of 6 Parameters

    3. 2 Set Complete 2. Numeric Bar Codes (Appendix A) Minimum Length 1. Begin 3. Complete 2. Numeric Bar Codes (Appendix A) © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 40: Lcd25 Parameters

    3. 2 Set Complete 2. Numeric Bar Codes (Appendix A) Minimum Length 1. Begin 3. Complete 2. Numeric Bar Codes (Appendix A) © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 41: Telepen Parameters

    3. 2 Set Complete 2. Numeric Bar Codes (Appendix A) Minimum Length 1. Begin 3. Complete 2. Numeric Bar Codes (Appendix A) © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 42: Gs1 Databar

    Symbology ID * Symbology ID Symbology ID * Transmit Symbology C. GS1 DataBar Expanded Parameters Don’t Transmit Symbology ID * Transmit Symbology ID © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 43: Bar Code Id

    CODE 11 China Postage MSI / PLESSEY Code 2 of 6 LCD 25 Telepen GS1 DataBar Omnidirectional GS1 DataBar GS1 DataBar Limited Expanded © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 44: User Define Code Id

    CODE 128 CODE 39 Interleave 25 CODABAR/NW7 Matrix 25 Industrial 25 CODE 93 CODE 11 ChinaPostage MSI/PLESSEY Code 2 of 6 Telepen © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 45 LCD25 GS1 DataBar Omnidirectional ON GS1 DataBar Limited ON GS1 DataBar Expanded ON Reserved5 Reserved6 © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 46: Chapter 4 - Command Setting

    Keyboard Mode 4.1.2 Reading Mode Selection Trigger ON/OFF * Good Read OFF Continuous/Trigger OFF Testing Continuous/Auto Power On Flash Flash/Auto Power On Presentation © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 47: Communication Parameters

    C. Set Up Stop Bits 9600 * 8 Data Bits * 1 Bit* 1200 7 Data Bits 2 Bits 2400 4800 19200 38400 © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 48 E. Handshaking None * RTS/CTS Disable * RTS/CTS Enable Even ACK/NAK Disable * ACK/NAK Enable XON/XOFF Disable * XON/XOFF Enable Mark Space © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 49: Keyboard Wedge Mode Parameters

    E. Select Numerical Case Detection by ALT Method No Change * Disable * Disable * OFF * Upper Case Enable Enable Lower Case © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 50: Output Characters Parameters

    0ms * None 5 ms CR +LF 10 ms 25 ms Space 50 ms HT(TAB) 100 ms STX-ETX 200 ms 300 ms © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 51: Language Selection

    4.3 Language Selection US English * Hungarian UK English Janpanese Italian Belgium Spanish Portuguese French Denmark German Netherlands Swedish Turkey Switzerland Reserved 2 © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 52: Reading Level

    The Polarity can be sent as standard with black bars high, or reversed with white bars high. Black Bars High * White Bars High © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 53: Accuracy

    Note: It will cause the scanning process to slow down by choosing more than 1 time to verify the data. 1 Time * 2 Times 3 Times 4 Times 4.6 Buzzer Beep Tone High * Medium © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 54: Sensitivity Of Continuous Reading Mode

    3. Scan the "Complete" label Repeat the steps 1-3 to set time out of same symbol 1. Begin 3. Complete 2. Numeric Bar Codes (Appendix A) © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 55: Reverse Output Characters

    6. Scan the “Complete” label of “Number of Characters to be Deleted”. Repeat the steps 1 – 6 to set additional deletion. A. Select Deletion Set Number © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 56 MSI/PLESSEY CODABAR/NW7 Code 2 of 6 Interleave 25 Telepen LCD25 GS1 DataBar Omnidirectional GS1 DataBar Limited GS1 DataBar Expanded None All Codes © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 57 2. Complete 1. Numeric Bar Codes (Appendix A) D. Number of Characters to be Deleted 2. Complete 1. Numeric Bar Codes (Appendix A) © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 58: Setup Insertion

    6. Scan the “Complete” label of “Characters to be inserted”. Repeat the steps 1 – 6 to set additional insertion. A. Select Insertion Set Number © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 59 MSI/PLESSEY CODABAR/NW7 Code 2 of 6 Interleave 25 Telepen LCD25 GS1 DataBar Omnidirectional GS1 DataBar Limited GS1 DataBar Expanded None All Codes © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 60 C. Character Position to be Inserted 2. Complete 1. Numeric Bar Codes (Appendix A) D. Characters to be Inserted 2. Complete 1. ASCII Table (Appendix B) © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 61: Appendix A -Numeric Bar Codes

    Appendix A –Numeric Bar Codes © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 62: Appendix B -Ascii Table

    Appendix B –ASCII Table © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 63 © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 64 © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 65 © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 66: Appendix C -Function Key Table

    Appendix C –Function Key Table © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
  • Page 67: Appendix D-Numeric Bar Codes2

    Appendix D–Numeric Bar Codes2 © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co.,Ltd...
