Mitsubishi MELSEC iQ-F User Manual

Fx5
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MELSEC iQ-F
FX5 User's Manual
(Analog Control - Intelligent function module)

Advertisement

Table of Contents
loading

Related Manuals for Mitsubishi MELSEC iQ-F

Summary of Contents for Mitsubishi MELSEC iQ-F

  • Page 1 MELSEC iQ-F FX5 User's Manual (Analog Control - Intelligent function module)

  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS (Read these precautions before use.) Before using this product, please read this manual and the relevant manuals introduced in this manual carefully and pay full attention to safety in order to handle the product correctly. This manual classifies the safety precautions into two categories: [ WARNING] and [ CAUTION].
  • Page 4 [DESIGN PRECAUTIONS] CAUTION ● When an inductive load such as a lamp, heater, or solenoid valve is controlled, a large current (approximately ten times greater than normal) may flow when the output is turned from off to on. Take proper measures so that the flowing current dose not exceed the value corresponding to the maximum load specification of the resistance load.
  • Page 5 [WIRING PRECAUTIONS] WARNING ● Make sure to cut off all phases of the power supply externally before attempting installation or wiring work. Failure to do so may cause electric shock or damage to the product. ● Make sure to attach the terminal cover, provided as an accessory, before turning on the power or initiating operation after installation or wiring work.
  • Page 6 ● Do not disassemble or modify the PLC. Doing so may cause fire, equipment failures, or malfunctions. For repair, contact your local Mitsubishi Electric representative. ● Turn off the power to the PLC before connecting or disconnecting any extension cable. Failure to do so may cause device failures or malfunctions.
  • Page 7 [TRANSPORTATION PRECAUTIONS] CAUTION ● The PLC is a precision instrument. During transportation, avoid impacts larger than those specified in the general specifications of the User's Manual (Hardware) of the CPU module used by using dedicated packaging boxes and shock-absorbing palettes. Failure to do so may cause failures in the PLC.

  • Page 8: Introduction

    This manual contains text, diagrams and explanations which will guide the reader in the correct installation, safe use and operation of the multiple input module of MELSEC iQ-F series and should be read and understood before attempting to install or use the module.
  • Page 9 MEMO...

  • Page 10: Table Of Contents

    CONTENTS SAFETY PRECAUTIONS ..............1 INTRODUCTION .
  • Page 11 CHAPTER 5 SYSTEM CONFIGURATION CHAPTER 6 WIRING Spring Clamp Terminal Block............. . 76 Terminal Arrangement .

  • Page 12: Relevant Manuals

    Functions and programming for the synchronous control of the Simple Motion Synchronous Control) module. <IB0300255> MELSEC iQ-F FX5 User's Manual (Analog Control - CPU module built- Describes the analog function of the CPU module built-in and the analog adapter. in, Expansion adapter) <JY997D60501>...

  • Page 13: Terms

    TERMS Unless otherwise specified, this manual uses the following terms. For details on the FX3 devices that can be connected with the FX5, refer to the User’s Manual (Hardware) of the CPU module to be used. Terms Description ■Devices Generic term for FX5U and FX5UC PLCs Generic term for FX3S, FX3G, FX3GC, FX3U, and FX3UC PLCs FX5 CPU module Generic term for FX5U CPU module and FX5UC CPU module...
  • Page 14 Different name for FX3U-32BL Peripheral device Generic term for engineering tools and GOTs Generic term for Mitsubishi Electric Graphic Operation Terminal GOT1000 and GOT2000 series ■Software packages Engineering tool The product name of the software package for the MELSEC programmable controllers...

  • Page 15: Chapter 1 Overview

    OVERVIEW FX5-8AD multiple input module can convert 8 points of analog input values (voltage input, current input, thermocouple and resistance temperature detector) into digital values. It is added to FX5 CPU module, and is possible to capture voltage/current/thermocouple/resistance temperature detector data of 8 channels.

  • Page 16: Chapter 2 Specifications

    General Specifications The general specifications other than below are the same as those for the CPU module to be connected. For general specifications, refer to the following. MELSEC iQ-F FX5U User's Manual (Hardware) MELSEC iQ-F FX5UC User's Manual (Hardware) Items...

  • Page 17: Voltage/Current Input Specifications

    Voltage/current input specifications Items Specifications Analog input voltage -10 to 10 V DC (Input resistance 1 MΩ) -20 to +20 mA DC (Input resistance 250 Ω) Analog input current Digital output value 16-bit signed binary (-32000 to +32000) Input characteristics, resolution Analog input range Digital output value Resolution...

  • Page 18: Resistance Temperature Detector (Rtd) Input Specifications

    Resistance temperature detector (RTD) input specifications Items Specifications Usable resistance temperature detector Pt100, Ni100 Resolution 0.1 (0.2) Temperature measuring range Pt100: -200 to +850 (-328 to +1562) Ni100: -60 to +250 (-76 to +482) Digital output value (16-bit signed binary) Pt100: -2000 to +8500 (-3280 to +15620) Ni100: -600 to +2500 (-760 to +4820) Accuracy...

  • Page 19: I/O Conversion Characteristics

    I/O Conversion Characteristics The I/O conversion characteristics of A/D conversion are expressed by the slope of the straight line connecting the offset value and the gain value, both of which are used when an analog signal (voltage or current) from outside the programmable controller is converted to the corresponding digital output value.
  • Page 20 Input range setting Digital output value Minimum Maximum 0 to 10 V -768 +32767 0 to 5 V 1 to 5 V -10 to +10 V -32768 • Set values within the practical range of the analog input and the digital output at each input range. If the range is exceeded, the resolution and accuracy may not fall within the range of the performance specifications.
  • Page 21 Input range setting Digital output value Minimum Maximum 4 to 20 mA -768 +32767 0 to 20 mA -20 to +20 mA -36768 • Set values within the practical range of the analog input and the digital output at each input range. If the range is exceeded, the resolution and accuracy may not fall within the range of the performance specifications.

  • Page 22: Accuracy

    Accuracy The following shows the accuracy of a multiple input module. Accuracy at voltage/current input The accuracy of A/D conversion is the accuracy for the full scale of digital output value. The fluctuation range varies as follows depending on ambient temperature and input range. Analog input range Ambient temperature 25±5...
  • Page 23 Accuracy at thermocouple connection The accuracy () is given by the following formula: Full scale × Thermocouple accuracy + Cold junction compensation accuracy Accuracy when B thermocouple is used, the operating ambient temperature is 25, and measured temperature is 1000 (1700...

  • Page 24: Part Names

    Part Names This section describes the names of each part of the multiple input module. 2-φ4.5 mounting holes [10] Name Description Terminal block (Spring clamp terminal Use for the current/voltage and temperature sensor input. block) Expansion cable Cable for connecting the module when adding the multiple input module. Direct mounting hole Screw holes (2-φ4.5, mounting screw: M4 screw) for direct installation.

  • Page 25: Chapter 3 Procedures Before Operation

    Check the multiple input module specifications. (Page 14 SPECIFICATIONS) Installation of multiple input module Install a multiple input module to a CPU module. For details, refer to the following. MELSEC iQ-F FX5U User's Manual (Hardware) MELSEC iQ-F FX5UC User's Manual (Hardware) Wiring Perform wiring of external devices to a multiple input module.

  • Page 26: Chapter 4 Functions

    FUNCTIONS This chapter describes the functions of a multiple input module and the setting procedures for those functions. For details on the buffer memory areas, refer to the following. Page 108 Buffer Memory Areas • This chapter describes buffer memory addresses for CH1. For details on the buffer memory addresses after CH2, refer to the following.

  • Page 27: Function List

    Function List This chapter lists the functions of multiple input module. Item Description Reference Operation mode Select the operation mode (normal mode, 2CH conversion mode, offset/gain setting Page 27 mode) of the multiple input module. Input type/Range setting function Input type, and input range can be checked for each channel. Disabling the Page 28 conversion on unused channels reduces the conversion cycles.

  • Page 28: Processing Of Each Function

    Processing of Each Function The functions are processed in the order shown below depending on the mode. If multiple functions are enabled, the output of the first processed function is used as the input of the next function. • Normal mode Disconnection A/D conversion Analog input...

  • Page 29: Operation Mode

    • 2CH conversion mode CH Digital Sampling Analog input output value processing (CH1 to CH8) CH Digital operation value CH Maximum value Maximum value/ minimum value hold function CH Minimum value Digital output value The digital values after the sampling processing or each average processing are stored. Logging data When the logging function is used, digital output values or digital operation values are collected.

  • Page 30: Input Type/Range Setting Function

    Input Type/Range Setting Function The Input type/Range setting can be selected for each channel according to the type of sensor to be connected. Operation The analog input value is A/D converted or temperature converted by the set input type, input range, or Input type/Range setting (offset/gain setting), and the value is stored in the following area.

  • Page 31: Conversion Method

    Conversion Method This function sets the A/D conversion or temperature conversion method for each channel. The conversion speed is 1 ms when the input range is current and voltage, 40 ms in the case of resistance temperature detector and thermocouple. A/D conversion or temperature conversion is performed asynchronously.
  • Page 32 Averaging processing Averaging processing is performed for analog input value or temperature input value for each channel. Averaged values are stored as digital output values and digital operation values. The following three types of averaging processing are provided. • Time average •...
  • Page 33 ■Count average A multiple input module executes the conversion for a set number of times and averages the total value excluding the maximum value and the minimum value. The averaged value is stored in the digital output value and the digital operation value.
  • Page 34 Setting procedure ■Sampling processing Set "Average processing setting" to "Sampling processing". [Navigation window]  [Parameter]  [Module Information]  Module model name  [Module Parameter]  [Basic setting]  [Conversion system] ■Average processing Set "Average processing setting" to "Time average", "Count average", or "Moving average". [Navigation window] ...

  • Page 35: Scaling Function

    Scaling Function Performs scale conversion on digital output values within the range from a scaling upper limit value to a scaling lower limit value, both of which are set at desired values. The converted values are stored in 'CH1 Digital operation value' (Un\G402). Concept of scaling setting The concepts of each setting item are described below.
  • Page 36 Calculating the scaling value The scale value conversion is based on the following formula. (In scale conversion, values are rounded off to the nearest whole number.) The calculation formula for a scaling value varies depending on the input type/range. Input type/Range Relational expression Element •...
  • Page 37 Setting example ■Example 1 An example of the following settings is shown below. Item Setting Input type/range Voltage (-10 to +10 V) Scaling enable/disable setting Enable Scaling upper limit value 20000 Scaling lower limit value 4000 Input voltage and scaling value become as follows. +32000 Scaling upper limit value: 20000 Scaling lower limit value: 4000...

  • Page 38: Alert Output Function

    Alert Output Function This section describes process alarms and rate alarms used for the alert output function. Process alarm Outputs an alert when a digital operation value falls within the preset alert output range. Digital operation value Alert output range Out of alert output range Included Alert...
  • Page 39 ■Operation after an alert was output After an alert was output, if the digital operation value does not satisfy the alert output condition due to being smaller than 'CH1 Process alarm upper lower limit value' (Un\G516) or being greater than 'CH1 Process alarm lower upper limit value' (Un\G518), Normal (0) is stored in a bit corresponding to the channel of 'Alert output flag (Process alarm upper limit)' (Un\G36) or 'Alert output flag (Process alarm lower limit)' (Un\G37).

  • Page 40: Rate Alarm

    Rate alarm This function outputs an alert when the change rate of a digital output value is equal to or greater than the rate alarm upper limit value, or the rate is equal to or smaller than the rate alarm lower limit value. 'CH1 Digital output value' (Un\G400) Rate alarm alert...
  • Page 41 Operation ■Operation performed when an alert is output Digital output values are monitored on the rate alarm alert detection cycle. When a change rate of a digital output value (from a previous value) is equal to or more than the rate alarm upper limit value, or the rate is equal to or less than the rate alarm lower limit value, an alert is output as follows.
  • Page 42 The judgment under the following conditions Setting item Setting content Conversion enabled channels CH1 Input type/range setting Current (4 to 20 mA) Rate alarm change rate selection Rate specification CH1 Average processing specification Sampling processing CH1 Rate alarm alert detection cycle setting 5 times CH1 Rate alarm upper limit value 250 (25.0%)
  • Page 43 Application examples of rate alarms A rate alarm serves to monitor that the variation of a digital output value lies in a limited range as shown below: ■Example 1 To monitor that a rising rate of a digital output value is within the specified range Change rate of the digital output value (%) Rate alarm upper value +30%...
  • Page 44 Setting procedure Set "Warning output setting (Rate alarm)" to "Enable". [Navigation window]  [Parameter]  [Module Information]  Module model name  [Module Parameter]  [Application setting]  [Warning output function (Rate alarm)] Set the value to "Rate alarm change rate selection". Item Setting range Rate alarm change rate selection...

  • Page 45: Disconnection Detection Function

    Disconnection Detection Function This function detects disconnection of a thermocouple or resistance temperature detector. Notification of disconnection • Disconnection detection (1) is stored in a bit corresponding to the channel of 'Disconnection detection flag' (Un\G41). • 'Disconnection detection signal' (Un\G69, b6) turns on. •...
  • Page 46 ■Case of Disable (1) ‘Disconnection detection flag' (Un\G41), 'Disconnection detection signal' (Un\G69, b6), and the ALM LED hold the status at the time of the disconnection detection. To return to the normal status, make a recovery from disconnection of all the channels, and turn off→on→off 'Error clear request' (Un\G70, b15).
  • Page 47 ■Any value At the time of the disconnection detection, a value set in 'CH1 Conversion setting value at disconnection detection' (Un\G532) is stored in 'CH1 Digital output value' (Un\G400). The default value of 'CH1 Conversion setting value at disconnection detection' (Un\G532) is 0. The value can be changed to any value although using 0 is no problem.

  • Page 48: Input Signal Error Detection Function

    Input Signal Error Detection Function Outputs an alarm when an analog input value exceeds the preset range. Detection range Out of detection range Analog input value Included Input signal error detection upper limit value CH2 Analog input value CH1 Analog input value Normal Input signal error detection...
  • Page 49 Detection method One of the following detection methods can be selected. Detection method Detection condition 0: Disable Input signal errors are not detected.  1: Upper and lower limit An input signal error is detected when the Analog input value detection analog input value is equal to or greater than the input signal error detection upper...
  • Page 50 ■Simple disconnection detection Outputs an alarm when an analog input value is 0.5 V or smaller or 2 mA or smaller. By the input range setting, simple disconnection detection is enabled. The simple broken wire detection is supported only in the "4 to 20 mA"...
  • Page 51 Clearing input signal errors One of the following methods for clearing input signal errors can be selected by setting 'Input signal error detection auto-clear enable/disable setting' (Un\G302). ■When Input signal error detection auto-clear enable/disable setting is set to Enable (0) After the analog input value returns within the setting range, the multiple input module arranges the following status automatically.
  • Page 52 The following figure shows the operation when an analog input value falls below 2.4 mA and returns within the normal range under the following condition. Item Setting 'Input signal error detection auto-clear enable/disable setting' (Un\G302) Enable (0) Input range 4 to 20 mA 'CH1 Input signal error detection setting' (Un\G528) Upper and lower limit detection (1) 'CH2 Input signal error detection setting' (Un\G728)
  • Page 53 Setting the input signal error detection upper or lower limit value ■Input signal error detection upper limit value Set the input signal error detection upper limit value by 1 (0.1%) based on the input signal error detection upper limit set value. This value is calculated by adding "Analog input range width (Gain value - Offset value) ×...
  • Page 54 Setting example ■Setting example of the input signal error detection In the channel where the following values are set, an input error is detected when an analog input value exceeds +10.235 V or falls below -10.24 V. Item Setting value Input range -10 to +10 V 'Input signal error detection auto-clear enable/disable setting' (Un\G302)

  • Page 55: Shift Function

    4.10 Shift Function Adds (shifts) a set conversion value shift amount to a digital output value, and stores the result in the buffer memory area. A change in conversion value shift amount is reflected to the digital operation value in real time, which facilitates fine adjustment at system start-up.
  • Page 56 When the I/O characteristics is adjusted in a channel where the input range of -10 to +10 V is set by the shift function 'CH1 Digital output value' (Un\G400) (+52000) 'CH1 Conversion value shift amount' (Un\G472) "+20000" ↓ 'CH1 Digital operation value' (Un\G402) +32767 +32000 -12000...
  • Page 57 When the following values are used for multiple input module with the input range of 0 to 5 V Item Setting ‘CH1 Scaling enable/disable setting’ (U\G504) Enable (0) ‘CH1 Scaling upper limit value’ (Un\G506) 12000 ‘CH1 Scaling lower limit value’ (Un\G508) 2000 ‘CH1 Conversion shift amount’...

  • Page 58: Digital Clipping Function

    4.11 Digital Clipping Function Fixes a possible digital operation value to the maximum digital output value or the minimum digital output value when an input current or voltage exceeds the input range. List of output ranges The following table lists the output ranges of the digital operation values when the digital clipping function is enabled with each range.
  • Page 59 Setting example When the following values are used for multiple input module with the input range of 0 to 5 V Item Setting ‘CH1 Scaling enable/disable setting’ (Un\G504) Enable (0) ‘CH1 Scaling upper limit value’ (Un\G506) 12000 ‘CH1 Scaling lower limit value’ (Un\G508) 2000 ‘CH1 Conversion shift amount’...

  • Page 60: Maximum Value/Minimum Value Hold Function

    4.12 Maximum Value/Minimum Value Hold Function Stores the maximum and minimum values of digital operation values in the buffer memory area for each channel. Time average and count average are processed on the average processing cycle. The values of the sampling processing, and moving average are updated on the sampling cycle.

  • Page 61: Logging Function

    4.13 Logging Function Logs (records) digital output values or digital operation values. 10000 points of data can be logged for each channel. Logging data are stored in the buffer memory area. In addition, the data collection can be stopped by using the status change of the data as a trigger.
  • Page 62 Operation of logging ■Starting logging data collection Logging data collection starts when Enable (0) is set in 'CH1 Logging enable/disable setting' (Un\G535)' and 'Operating condition setting request' (Un\G70, b9) turns off→on→off. The data in 'CH1 Digital output value' (Un\G400) or 'CH1 Digital operation value' (Un\G402) is stored in CH1 Logging data (Un\G10000 to Un\G19999) on the set logging cycle.
  • Page 63 Logging cycle ■Logging cycle setting Set the logging cycle with 'CH1 Logging cycle setting value' (Un\G537) and 'CH1 Logging cycle unit setting' (Un\G538). The following table lists the setting range for each cycle. Setting value of 'CH1 Logging cycle unit setting' (Un\G538) Setting range of 'CH1 Logging cycle setting value' (Un\G537) ms (1) •...
  • Page 64 ■When the logging function becomes disabled The logging is not performed when even one of the following errors occurs after the logging function is enabled and 'Operating condition setting request' (Un\G70, b9) is turned off→on→off. • ‘CH1 Time Average/Count Average/Moving Average’ (Un\G502) setting error: Error code (192H to 194H) •...
  • Page 65 ■Head pointer and latest pointer The storage location of the oldest data and the latest data in CH1 Logging data (Un\G10000 to Un\G19999) can be checked with the following buffer memory areas. Buffer Memory Areas Description CH1 Head pointer (Un\G434) The buffer memory address of the oldest data in CH1 Logging data (Un\G10000 to Un\G19999) can be checked with this buffer memory area.

  • Page 66: Stopping The Logging Operation

    Stopping the Logging Operation Logging operation stops (holds) when the preset trigger condition is satisfied and the set points of the data are collected. A trigger that is generated when the condition is satisfied is called a hold trigger. To generate a hold trigger, the following two methods are available. Page 67 Logging hold request Page 68 Level trigger When a hold trigger is detected during data collection, the logging operation stops after the points of the data set in 'CH1 Post-...
  • Page 67 ■Checking the trigger generation time The trigger generation time can be checked with 'CH1 Trigger generation time' (Un\G444 to Un\G448). When 'CH1 Trigger generation time' (Un\G444 to Un\G448) is monitored b8 b7 First two digits of the year Last two digits of the year 'CH1 Trigger generation time (First/Last two digits of the year)' (Un\G444) Month 'CH1 Trigger generation time (Month/Day)' (Un\G445)
  • Page 68 Resuming the logging It may take time until ON (1) is stored in 'CH1 Logging hold flag' (Un\G409) after 'CH1 Logging hold request' (Un\G471) is changed off→on. To resume logging, check that ON (1) is stored in 'CH1 Logging hold flag' (Un\G409) and change 'CH1 Logging hold request' (Un\G471) on→off.

  • Page 69: Logging Hold Request

    Logging hold request A hold trigger is generated from a program at any timing. After ON (1) is set to 'CH1 Logging hold request' (Un\G471), a preset number of data is collected and then the logging stops. Controlled by the multiple input module 'CH1 Logging hold request' OFF(0) ON(1)

  • Page 70: Level Trigger

    Level trigger When a value in the monitored buffer memory area of multiple input module satisfies a preset condition, a hold trigger is generated. The level trigger is monitored at the conversion cycle. Initial setting of a level trigger ■Setting a target to be monitored As a condition to generate a hold trigger, set the buffer memory address to be monitored to 'CH1 Trigger data' (Un\G541).
  • Page 71 ■Setting the monitoring condition • Set a condition to generate a hold trigger in 'CH1 Level trigger condition setting' (Un\G540). Setting value Description 1: Level trigger (Condition: A hold trigger is generated under the Stored value of a buffer memory area to be monitored Rise) condition (a).
  • Page 72 Operation of a level trigger To use a level trigger, set ON (1) to 'CH1 Logging hold request' (Un\G471) in advance. At the point where ON (1) has been set to 'CH1 Logging hold request' (Un\G471), the module becomes the trigger condition wait status. After the trigger condition has been satisfied, and the set points of the data have been collected from that point, the logging stops.

  • Page 73: Initial Settings Of The Logging Function

    Initial settings of the logging function The following describes the initial setting procedure to use the logging function. Setting procedure Set the “Input type”, and “Input range”. [Navigation window]  [Parameter]  [Module Information]  Module model name  [Module Parameter]  [Basic setting] ...

  • Page 74: Fx2N Allocation Mode Function

    4.15 FX2N Allocation Mode Function It is a function to operate the buffer memory areas of the multiple input module with the same layout as the buffer memory address equivalent to FX2N-8AD. This compatibility enables the reuse of programs that have proven performance on FX2N-8AD. Operation In FX2N allocation mode, only allocation of buffer memory area is changed.

  • Page 75: 2Ch Conversion Mode Function

    Setting procedure When adding a new module, select the module whose module model name has "(FX2N)" at the end. [Navigation window]  [Parameter]  [Module Information]  Right-click  [Add New Module] Configure the same parameter setting as the one of when the Normal mode is used. After writing the module parameter, turn off→on or reset the CPU module.
  • Page 76 Compatible functions The following functions can be used with the 2CH conversion mode. Settings used with other functions are invalid. Function Input type/Range setting function Voltage, current conversion function Conversion method (Sampling processing) Maximum value/Minimum value hold function Setting procedure Set "Operation mode setting"...

  • Page 77: Chapter 5 System Configuration

    SYSTEM CONFIGURATION The system configuration using the multiple input module is as follows. • System configuration example (1) FX5 CPU module (2) Multiple input module (FX5-8AD) (3) Analog device connection cable (4) Current input (5) Voltage input (6) Resistance temperature detector input (7) Thermocouple input 5 SYSTEM CONFIGURATION...

  • Page 78: Chapter 6 Wiring

    WIRING This section explains the multiple input module wiring. Spring Clamp Terminal Block Suitable wiring The wires to connect the spring clamp terminal block are described below. No. of wire per terminal Wire size Single wire, Strand wire Ferrule with insulation sleeve Single wiring AWG24 to 16 AWG23 to 19...
  • Page 79 Removing and installing the terminal block The following shows how to remove and install the terminal block. ■Lever position to lock and release A 3-step stopper is attached to prevent the lever from rotating, facilitating installation and removal of the terminal block. When removing or installing the terminal block, move the lever to the corresponding position.
  • Page 80 Connection and disconnection of the cable ■Connection of the cable Fully insert a cable whose end has been properly processed into the wire insertion opening. If the cable cannot be inserted with this procedure, fully insert the cable while pushing the open/close button with a flathead screwdriver having a tip width of 2.0 to 2.5 mm.

  • Page 81: Terminal Arrangement

    Terminal Arrangement A/TC+ b/VI+ B/TC- A/TC+ b/VI+ B/TC- A/TC+ b/VI+ B/TC- A/TC+ b/VI+ B/TC- A/TC+ b/VI+ B/TC- A/TC+ b/VI+ B/TC- A/TC+ b/VI+ B/TC- A/TC+ b/VI+ B/TC- Terminal name Description A/TC+ CH1 Resistance temperature detector input/thermocouple input B/TC- b/VI+ CH1 Voltage/current input/resistance temperature detector input CH1 Voltage/current input A/TC+ CH2 Resistance temperature detector input/thermocouple input...

  • Page 82: Power Supply Wiring

    Power Supply Wiring Power connector layout (Green) (Black) (Red) Power supply wiring (1)Red (2)Black (3)Green Multiple input module (1) (2) (3) 24 V DC Grounding (Ground resistance: 100 Ω or less.) Grounding Perform the following. • Perform class D grounding (Grounding resistance: 100 Ω or less). •...

  • Page 83: External Wiring Example

    External Wiring Example The followings show the examples of external wiring. Voltage input, and current input 24 V DC Multiple input module Grounding (Grounding resistance: 100  or less) CH Shielded wire For  in CH, the CH number is entered. Precautions Use a two-conductor shielded twisted pair cable for analog input lines and carry out the wiring while separating them from other power lines and lines susceptible to induction.

  • Page 84: Chapter 7 Parameter Setting

    PARAMETER SETTING Set the parameters of each channel. Setting parameters here eliminates the need to program them. When adding a new multiple input module, if selecting the module whose module model name has "(FX2N)" at the end, it can be used as FX2N allocation mode. •...

  • Page 85: Application Setting

    Application Setting Setting procedure Open "Application setting" of GX Works3. [Navigation window]  [Parameter]  [Module information]  Target module  [Module Parameter]  [Application setting] Double-click the item to be changed to enter the setting value. • Item where a value is selected from the pull-down Click [] button of the item to be set, and from the pull-down list that appears, select the value.

  • Page 86: Refresh Setting

    Refresh Setting Setting procedure Set the buffer memory area of a multiple input module to be refreshed automatically. This refresh setting eliminates the need for reading/writing data by programming. Start a module parameter. [Navigation window]  [Parameter]  [Module Information]  Target module  [Module Parameter]  [Refresh setting] Double-click the item to be set to enter the numeric value.

  • Page 87: Offset/Gain Setting

    Offset/Gain Setting Using the user range setting requires setting the offset and gain values. Access to the offset/gain setting window in GX Works3 to set the offset and gain values. Setting procedure When input type is current/voltage [Tool]  [Module Tool List] In "Multiple Input", select "Offset/gain setting"...
  • Page 88 Mark the checkbox of the channel where offset and gain values are to be set. Set the input type (other than conversion disable) to be used in "Input type/Range setting" and "Setting Input type/range (Offset/gain setting)" to the user range setting in advance. Select voltage or current and click the [Offset Setting] button.
  • Page 89 Apply the gain voltage or current to the corresponding channel, and click the [Yes] button. Check that "Gain Status" has changed to "Changed", and click the [Close] button. Click the [Yes] button. When the input type is "current", "voltage", offset value < gain value 7 PARAMETER SETTING 7.4 Offset/Gain Setting...
  • Page 90 When input type is resistance temperature detector/thermocouple [Tool]  [Module Tool List] Select "Multiple Input"  "Offset/gain setting", and click [OK] button. Select the target module for the offset/gain setting, and click [OK] button. Click [Yes] button. Mark the checkbox of the channel where offset and gain values are to be set.
  • Page 91 Click [Offset Setting] button. Apply a value that becomes an offset value to the terminal of the corresponding channel, and click [Yes] button. Check that "Offset Status" has changed to "Changed". Write the temperature setting value corresponding to the gain value to "Gain Setting Value". Click [Gain Setting] button.
  • Page 92 Click [Yes] button. When the input type is "resistance temperature detector" or "thermocouple", offset value - gain value > 0.1 Precautions If a broken wire is detected while setting the offset and gain, the offset and gain channel change error (error code: 1EBH) will occur.

  • Page 93: Chapter 8 Programming

    PROGRAMMING This chapter describes the programming procedure and the basic program of a multiple input module. Programming Procedure Take the following steps to create a program for running a multiple input module: Set parameters. Create a program. System configuration example System configuration (1) CPU module (FX5U CPU module) (2) Multiple input module (FX5-8AD)
  • Page 94 ■Application setting Configure the application setting as shown below. 8 PROGRAMMING 8.1 Programming Procedure...

  • Page 95: Program Example

    Program example Label settings Classification Device Description Device Module label FX5_8AD_1.bConversionCompletedFlag_D Conversion completed flag U1\G69, b14 FX5_8AD_1.bModuleREADY_D Module READY U1\G69, b0 FX5_8AD_1.bOperatingConditionSettingCompletedFlag_D Operating condition setting completed flag U1\G69, b9 FX5_8AD_1.stnMonitor_D[0].wDigitalOutputValue_D Digital output value U1\G400 FX5_8AD_1.stnMonitor_D[2].wDigitalOutputValue_D Digital output value U1\G800 FX5_8AD_1.stnMonitor_D[4].wDigitalOutputValue_D Digital output value U1\G1200 FX5_8AD_1.stnMonitor_D[6].wDigitalOutputValue_D...
  • Page 96 Program example ■Digital output value readout processing ■Maximum/minimum value readout/clear processing ■Process alarm occurrence processing ■Rate alarm occurrence processing 8 PROGRAMMING 8.1 Programming Procedure...
  • Page 97 ■Input signal error occurrence processing ■Disconnection detection processing ■Error clear processing 8 PROGRAMMING 8.1 Programming Procedure...

  • Page 98: Chapter 9 Troubleshooting

    Reset the CPU module, and check if the RUN LED turns on. If the RUN LED still remains off, the possible cause is a failure of the module. Please consult your local Mitsubishi representative. 9 TROUBLESHOOTING 9.1 Troubleshooting with the LEDs...
  • Page 99 When the ERROR LED turns on or flashes ■When it is on Check item Corrective action Check whether any error has occurred. Check 'Latest error code' (Un\G0) and take actions described in the list of error codes. Page 100 List of Error Codes ■When flashing Check item Corrective action...

  • Page 100: When The Input Type Is "Resistance Temperature Detector", And "Thermocouple

    Reset the CPU module, and check if the RUN LED turns on. If the RUN LED still remains off, the possible cause is a failure of the module. Please consult your local Mitsubishi representative. When the ERROR LED turns on or flashes ■When it is on...
  • Page 101 When the ALM LED turns on or flashes ■When it is on Check item Corrective action Check whether any alert has been issued. Check Alert output flag (Process alarm upper limit), Alert output flag (Process alarm lower limit), Alert output flag (Rate alarm upper limit), and Alert output flag (Rate alarm lower limit).

  • Page 102: List Of Error Codes

    Check item Corrective action Check whether the offset/gain setting is correct. Check that the offset/gain setting is correct. If the user range setting is used, change to the factory shipment setting, and check that the conversion is performed. When the conversion is correct, perform the offset/gain setting again. Check whether average processing specification is correct.
  • Page 103 Error code Error name Description and cause Corrective action ■When the input type is “current”, and “voltage” ■When the input type is “current”, and “voltage” 192H Time average setting range error When Time average is selected in CH Set a value of 4 to 10000 in CH Time average/ Average processing specification, a value other Count average/Moving average setting.
  • Page 104 If the error occurs again, the possible cause is a failure of the module. Please consult your local Mitsubishi representative. 1E6H User range data invalid (CH An invalid value is set in CH Offset/gain...

  • Page 105: List Of Alarm Codes

    Flash memory error The data in the flash memory is abnormal. Check the digital output values. If the values are abnormal, please consult your local Mitsubishi representative. List of Alarm Codes If an alarm occurs during operation, a multiple input module stores the alarm code into 'Latest alarm code' (Un\G2) of the buffer memory.

  • Page 106: Appendices

    APPENDICES Appendix 1 External Dimensions This chapter describes the external dimensions of the multiple input module. 19.2 (Unit: mm) APPX Appendix 1 External Dimensions...

  • Page 107: Appendix 2 Standards

    When the FX5-8AD is used, attach a ferrite core to the power supply of the CPU module. Make 2 turns around the ferrite core and attach within approximately 200 mm from the terminal block and connectors of the power cable. (Ferrite core used in Mitsubishi Electric's test: E04SR401938 manufactured by SEIWA ELECTRIC MFG. CO., LTD.)
  • Page 108 For users of proprietary cables (dedicated for sensors or actuators), these users should follow those manufacturers' installation requirements. Mitsubishi Electric recommends that shielded cables be used. If no other EMC protection is provided, users may experience temporary loss of accuracy between +10%/-10% in very heavy industrial areas.

  • Page 109: Appendix 3 Module Label

    Appendix 3 Module Label The functions of the multiple input module can be set by using module labels. Module Label The module label name is defined with the following structure: "Module name"_"Module number".b"Label name" or "Module name"_"Module number".b"Label name"_D FX5_8AD_1.bModuleREADY_D ■Module name The character string of a module model name is given.

  • Page 110: Appendix 4 Buffer Memory Areas

    Appendix 4 Buffer Memory Areas List of buffer memory areas This section lists the buffer memory areas of the multiple input module. For details on the buffer memory, refer to the following. Page 121 Details of buffer memory addresses The buffer memory areas of the multiple input module are classified into the data types described below. Data type Description Setting data...
  • Page 111 Address Address Name Default value Data type Auto refresh (decimal) (hexadecimal) Output signals Control     71 to 89 47H to 59H System area  Level data 0 Control  Level data 1 Control  Level data 2 Control Level data 3 Control...
  • Page 112 Address Name Default Data Auto Decimal (hexadecimal) value type refresh  1023 1223 1423 1623 1823 CH Minimum value reset Monitor (1A7H) (26FH) (337H) (3FFH) (4C7H) (58FH) (657H) (71FH) completed flag 424 to 624 to 824 to 1024 to 1224 to ...
  • Page 113 Address Name Default Data Auto Decimal (hexadecimal) value type refresh  1071 1271 1471 1671 1871 CH Logging hold request Control (1D7H) (29FH) (367H) (42FH) (4F7H) (5BFH) (687H) (74FH) 1072 1272 1472 1672 1872 CH Conversion value shift Control  (1D8H) (2A0H) (368H)
  • Page 114 Address Name Default Data Auto Decimal (hexadecimal) value type refresh    1123 1323 1523 1723 1923 System area (20BH) (2D3H) (39BH) (463H) (52BH) (5F3H) (6BBH) (783H) 1124 1324 1524 1724 1924 CH Rate alarm upper limit Setting  (20CH) (2D4H) (39CH)
  • Page 115 Address Name Default Data Auto Decimal (hexadecimal) value type refresh    565 to 765 to 965 to 1165 to 1365 to 1565 to 1765 to 1965 to System area 1197 1397 1597 1797 1997 (235H to (2FDH (3C5H (48DH (555H to (61DH...
  • Page 116 Address Address Name Default Data type Auto (decimal) (hexadecimal) value refresh 3746 to 3749 EA2H to EA5H System area     3750 to 3755 EA6H to EABH Error history 16 Same as error history 1 Monitor 3756 to 3759 EACH to EAFH System area ...
  • Page 117 ■Offset/gain setting (Un\G4000 to Un\G9999) Address Name Default Data Auto Decimal (hexadecimal) value type refresh    4000 to 4131 System area (FA0H to 1023H)  4132 4134 4136 4138 4140 4142 4144 4146 CH Offset/gain setting Setting (1024H) (1026H) (1028H) (102AH)
  • Page 118 Address Name Default Data Auto Decimal (hexadecimal) value type refresh  CH Process alarm upper Setting (49H) (4AH) (4BH) (4CH) (4DH) (4EH) (4FH) (50H) upper limit value 89, 90 (51H, 52H) System area     CH Rate alarm upper limit Setting (53H) (54H)
  • Page 119 Address Name Default Data Auto Decimal (hexadecimal) value type refresh  1081 1082 1083 1084 1085 1086 1087 1088 CH Averaging process Setting (439H) (43AH) (43BH) (43CH) (43DH) (43EH) (43FH) (440H) specification 1089, 1090 (441H, 442H) System area   ...
  • Page 120 Address Name Default Data Auto Decimal (hexadecimal) value type refresh    1267 to 1270 (4F3H, 4F6H) System area  1271 1272 1273 1274 1275 1276 1277 1278 CH Conversion setting at Setting (4F7H) (4F8H) (4F9H) (4FAH) (4FBH) (4FCH) (4FDH) (4FEH) disconnection detection...
  • Page 121 Address Name Default Data Auto Decimal (hexadecimal) value type refresh  8880 to 8889 (22B0H to 22B9H) Alarm history 13 Monitor 8890 to 8899 (22BAH to 22C3H) Alarm history 14 Monitor   8900 to 8909 (22C4H to 22CDH) Alarm history 15 Monitor 8910 to 8919 (22CEH to 22D7H) Alarm history 16...
  • Page 122 Address Name Default Data Auto Decimal (hexadecimal) value type refresh  9201 9202 9203 9204 9205 9206 9207 9208 CH Post-trigger logging 5000 Setting (23F1H) (23F2H) (23F3H) (23F4H) (23F5H) (23F6H) (23F7H) (23F8H) points 9209, 9210 (23F9H, 23FAH) System area  ...

  • Page 123: Details Of Buffer Memory Addresses

    Details of buffer memory addresses This section indicate the details of the buffer memory areas of the multiple input module. This section describes buffer memory addresses for CH1 in normal mode. Latest error code The latest error code detected in the multiple input module is stored. For details on the error codes, refer to the following. Page 100 List of Error Codes ■Buffer memory address The following shows the buffer memory address of this area.
  • Page 124 Module information Module information of FX5-8AD is stored. For module information, 61E0H (fixed hexadecimal value) is stored. ■Buffer memory address The following shows the buffer memory address of this area. Buffer memory name Module information Module information [FX2N Allocation Mode] The FX5-8AD module information in FX2N allocation mode function is stored.
  • Page 125 Warning output flag (Process alarm lower limit) The lower limit alarm of the process alarm can be checked for each channel. b15 b14 b13 b12 b11 b10 b9 (1) 0: Normal, 1: Alarm ON (2) The values of b8 to b15 are fixed to 0. ■Buffer memory address The following shows the buffer memory address of this area.
  • Page 126 Warning output flag (Rate alarm upper limit) The upper limit alarm of the rate alarm can be checked for each channel. b15 b14 b13 b12 b11 b10 b9 (1) 0: Normal, 1: Alarm ON (2) The values of b8 to b15 are fixed to 0. ■Buffer memory address The following shows the buffer memory address of this area.
  • Page 127 Warning output flag (Rate alarm upper limit/lower limit) [FX2N allocation mode] When the FX2N allocation mode function is used, the upper/lower limit alarm of the rate alarm can be checked. b15 b14 b13 b12 b11 b10 b9 CH8 CH8 CH6 CH5 CH4 CH4 CH2 CH1 (1) 0: Normal, 1: Alarm ON...
  • Page 128 ■Clearing Input signal error detection flag Clearing input signal errors detection flag differs depending on Input signal error detection/disconnection detection auto-clear enable/disable setting. When Input signal error detection/disconnection detection auto-clear enable/disable setting is set to Enable (0) • When an analog input value falls within the normal range, Normal (0) is stored in the corresponding bit of 'Input signal error detection flag' (Un\G40).
  • Page 129 ■Buffer memory address The following shows the buffer memory address of this area. Buffer memory name Input signal error detection flag/disconnection detection flag ■Status of Input signal error detection flag/disconnection detection flag • When an analog input value out of the range specified in Input signal error detection setting value is detected, Input signal error detection flag corresponding to each channel turns to Input signal error (1).
  • Page 130 Operation mode monitor The operation mode status in operation can be checked. Monitor value Description Normal mode Offset/gain setting mode FX2N Allocation Mode 2CH conversion mode ■Buffer memory address The following shows the buffer memory address of this area. Buffer memory name Operation mode monitor Operation mode monitor (In FX2N allocation mode function) Input signals...
  • Page 131 ■Offset/gain initialization completed flag (b5) • Use as an interlock condition to turn off→on→off 'Offset/gain initialization request' (Un\G70, b5). • Offset/gain initialization is not be performed unless ‘Offset/gain initialization enabled code' (Un\G305) is set to E20FH. • It is possible to perform offset/gain initialization in normal mode only. •...
  • Page 132 ■Warning output signal (b8) Alert output signal (Un\G69, b8) turns on when the process alarm or rate alarm has been detected. When the alert output function (process alarm/rate alarm) is disabled for all channels, 'Alert output signal' (Un\G69, b8) is always off. Alarm Operation Process alarm...
  • Page 133 ■Offset/gain setting mode status flag (b10) When registering the value, which has been adjusted with the offset/gain setting, use as an interlock condition to turn off→on→off 'User range write request' (Un\G70, b10). Controlled by the multiple input module Controlled by the program 'Module READY' (Un\G69, b0) 'Offset/gain setting mode status...
  • Page 134 ■Input signal error detection signal (b12) Set 'CH1 Input signal error detection setting' (Un\G528) to one of upper lower limit detection, upper limit detection, lower limit detection, and simple disconnection detection, and turns on if the analog input value exceeds the setting range that is set in 'CH1 Input signal error detection lower limit setting value (Un\G529) or 'CH1 Input signal error detection upper limit setting value’...
  • Page 135 ■Error flag (b15) Error flag (Un\G69, b15) turns on when an error has occurred. Controlled by the multiple input module Controlled by the program 'Latest error code' (Un\G0), Error or alarm 'Latest alarm code' (Un\G2) 'Error flag' (Un\G69, b15) 'Error clear request' (Un\G70, b15) 'Error flag' (Un\G69, b15), 'Latest error code' (Un\G0), and 'Latest alarm code' (Un\G2) are cleared at the timing when 'Error clear request' (Un\G70, b15) turns off→on.
  • Page 136 ■Channel change request (b11) Turn off→on→off Channel change request (b11) to change a channel to perform the offset/gain setting. For the timing of turning the signal off→on→off, refer to the following. Page 131 Channel change completed flag (b11) ■Error clear request (b15) Turn off→on→off Error clear request (b15) when Error flag (Un\G69, b15), Disconnection detection signal (Un\G69, b6), Input signal error detection signal (Un\G69, b12), and Latest error code are cleared.
  • Page 137 Mode switching setting Set a setting value for the mode to be switched. Switching mode Setting value Buffer memory address Normal mode 4658H 4144H Offset/gain setting mode 4144H 4658H When a value out of the above is written and 'Operating condition setting request' (Un\G70, b9) is turned off→on→off, the mode setting is not performed and only the operating condition is changed.
  • Page 138 Input signal error/Disconnection detection automatic clear enable/disable setting Set whether to enable or disable auto-clear of input signal error or disconnection detection with the input signal error detection function or disconnection detection function. Setting value Description Enable Disable Setting a value other than in the table above results in operation with Disable (1). ■Buffer memory address The following shows the buffer memory address of this area.
  • Page 139 CH1 Digital operation value When the digital clipping function, scaling function, shift function are used, digital values to which the digital clipping, scale conversion, and shift-and-add were performed are stored in 16-bit signed binary in the digital operation value. b15 b14 b13 b12 b11 b10 b9 (1) Data section (2) Sign bit 0: Positive, 1: Negative ■Buffer memory address...
  • Page 140 CH1 Minimum value The minimum value of the digital operation value is stored in 16-bit signed binary value. b15 b14 b13 b12 b11 b10 b9 (1) Data section (2) Sign bit 0: Positive, 1: Negative In the following cases, 'CH1 Minimum value' (Un\G406) is updated with the current value. •...
  • Page 141 CH1 Conversion status The conversion status is stored. Monitor value Conversion status Setting content Conversion disable A status of conversion disable. Conversion of the relevant channel is not executed. Conversion start A status from the conversion enabled to the initial conversion completed. Conversion completed A status after the initial conversion completed.
  • Page 142 CH1 Minimum value reset completed flag The reset status of minimum value can be checked. Controlled by the multiple input module Controlled by the program 'CH1 Maximum value' (Un\G404) Current digital operation value 'Minimum value reset request' (Un\G474) 'Minimum value reset completed flag' (Un\G423) ■Buffer memory address The following shows the buffer memory address of this area.
  • Page 143 CH1 Input type/Range monitor Set input type, and input range can be checked. Monitor value Input type Input range 000FH Conversion not allowed (Default)  0003H Current 4 to 20 mA 0010H 0 to 20 mA 0006H -20 to +20 mA 0011H Voltage 1 to 5 V...
  • Page 144 CH1 Input type/Range monitor (Offset/gain setting) Offset/gain values, which are set in ‘CH1 Input type/range setting’ (Un\G598), can be checked. Monitor value Description Factory default setting User range setting ■Buffer memory address The following shows the buffer memory address of this area. Buffer memory name CH...
  • Page 145 CH1 Latest pointer The buffer memory address of the latest data in CH1 Logging data (Un\G10000 to Un\G19999) can be checked with this buffer memory area. The offset value at the start address of CH1 Logging data (Un\G10000 to Un\G19999) is stored. ■Buffer memory address The following shows the buffer memory address of this area.
  • Page 146 CH1 Trigger pointer In CH1 Logging data (Un\G10000 to Un\G19999), the buffer memory address where the data at the time of a hold trigger event is stored can be checked. The difference between the buffer memory address where the data at the time of a hold trigger event is stored and the start address in CH1 Logging data (Un\G10000 to Un\G19999) is stored.
  • Page 147 CH1 Trigger generation time The time when a trigger is generated is recorded. For details on the logging function, refer to the following. Page 59 Logging Function b8 b7 First two digits of the year Last two digits of the year 'CH1 Trigger generation time (First/Last two digits of the year)' (Un\G444) Month 'CH1 Trigger generation time (Month/Day)' (Un\G445)
  • Page 148 CH1 Celsius/Fahrenheit display monitor A status of Celsius/Fahrenheit display in operation is stored. Monitor value Setting content Celsius Fahrenheit ■Buffer memory address The following shows the buffer memory address of this area. Buffer memory name CH Celsius/Fahrenheit display monitor 1052 1252 1452 1652...
  • Page 149 CH1 NowSetting user range base input range monitor This area is used to check the input range of user range setting that is registered in the offset/gain setting mode. When the input type is current, and voltage, 0000H is stored. Monitor value Setting content ■Case of resistance temperature detector...
  • Page 150 CH1 Logging hold request Use this buffer memory area as a trigger to hold (stop) logging at any timing during the logging. For details on the logging function, refer to the following. Page 59 Logging Function Logging hold request Setting value Setting a value other than the above causes a logging hold request range error (error code: 1D7H).
  • Page 151 CH1 Conversion value shift amount Set 'CH1 Conversion value shift amount' (Un\G472) used for the shift function. The digital operation value to which the conversion value shift amount is applied is stored in 'CH1 Digital operation value' (Un\G402). For details on the shift function, refer to the following. Page 53 Shift Function b15 b14 b13 b12 b11 b10 b9 (1) Data section...
  • Page 152 Maximum value reset request [FX2N allocation mode] When resetting the maximum value, and updating with the current value in FX2N allocation mode, turn off→on. b15 b14 b13 b12 b11 b10 b9 (1) 0: No reset request, 1: Reset request (2) The values of b8 to b15 are fixed to 0. ■Buffer memory address The following shows the buffer memory address of this area.
  • Page 153 CH1 Average processing specification Set which processing is to be used, sampling processing or averaging processing. Averaging processing consists of time average, count average, and moving average. Setting value Setting content Sampling processing Time average Count average Moving average Setting a value other than the above causes an averaging process specification setting range error (error code: 191H). ■Buffer memory address The following shows the buffer memory address of this area.
  • Page 154 ■Default value The default value is set to 0. • Since the default value is 0, change the setting value according to the processing method. • The setting for this area is ignored in the channel where Sampling processing (0) is set to 'CH1 Averaging process specification' (Un\G501).
  • Page 155 CH1 Scaling lower limit value Set a lower limit value for the range of the scale conversion. ■Buffer memory address The following shows the buffer memory address of this area. Buffer memory name CH Scaling lower limit value 1108 1308 1508 1708 1908...
  • Page 156 CH1 Warning output function (Process alarm) Set whether to enable or disable the alert output of the process alarm. For details on the alert output function, refer to the following. Page 36 Alert Output Function Setting value Setting content Enable Disable Setting a value other than the above causes an alert output setting (Process alarm) range error (error code: 1B0H).
  • Page 157 CH1 Process alarm upper upper limit value Set an upper upper limit value of the alert output function (Process alarm). For details on the alert output function, refer to the following. Page 36 Alert Output Function ■Buffer memory address The following shows the buffer memory address of this area. Buffer memory name CH...
  • Page 158 CH1 Process alarm lower upper limit value Set a lower upper limit value of the alert output function (Process alarm). For details on the alert output function, refer to the following. Page 36 Alert Output Function ■Buffer memory address The following shows the buffer memory address of this area. Buffer memory name CH...
  • Page 159 CH1 Rate alarm alert detection cycle setting Set the cycle to detect the change amount of digital output values. The value of the cycle to detect a rate alarm alert is the product of the value in 'CH1 Rate alarm alert detection cycle setting' (Un\G522) and the conversion cycle.
  • Page 160 CH1 Rate alarm lower limit value Set a lower limit value of the change rate of digital operation values to detect a rate alarm. For details on the alert output function, refer to the following. Page 36 Alert Output Function ■Buffer memory address The following shows the buffer memory address of this area.
  • Page 161 ■Enabling the setting Turn off→on→off 'Operating condition setting request' (Un\G70, b9) to enable the setting. ■Default value The default value is Disable (0). CH1 Input signal error detection lower limit setting value Set a lower limit value to detect an error for the input analog value. For details on the input signal error detection function, refer to the following.
  • Page 162 CH1 Input signal error detection upper limit setting value Set an upper limit value to detect an error for the input analog value. For details on the input signal error detection function, refer to the following. Page 46 Input Signal Error Detection Function ■Buffer memory address The following shows the buffer memory address of this area.
  • Page 163 CH1 Disconnection detection enable/disable setting Set whether to enable or disable the disconnection detection function. For details on the disconnection detection function, refer to the following. Page 43 Disconnection Detection Function Setting value Setting content Enable Disable Setting a value other than the above causes a disconnection detection enable/disable setting range error (error code: 1C5H).
  • Page 164 CH1 Conversion setting at disconnection detection Set what value is to be stored in 'CH1 Digital output value' (Un\G400) at the time of disconnection detection. For details on the disconnection detection function, refer to the following. Page 43 Disconnection Detection Function Setting value Setting content Upscale...
  • Page 165 CH1 Logging data setting Determine the target to be collected: digital output value or digital operation value. For details on the logging function, refer to the following. Page 59 Logging Function Setting value Setting content Digital output value Digital operation value Setting a value other than the above causes a logging data setting range error (error code: 1D3H).
  • Page 166 CH1 Logging cycle unit setting Set a cycle unit for storing the logging data. For details on the logging function, refer to the following. Page 59 Logging Function Setting value Setting content • Setting a value other than the above causes a logging cycle setting value range error (error code: 1D1H). Logging cannot be performed.
  • Page 167 CH1 Level trigger condition setting Set the condition for the occurrence of a hold trigger when using the level trigger in the logging function. To use the level trigger, perform level trigger condition setting to one of Level trigger (Condition: Rise)(1), Level trigger (Condition: Fall)(2), or Level trigger (Condition: Rise and fall)(3).
  • Page 168 ■Default value The default values are set as shown below. Channel In the normal mode In FX2N allocation function mode Default value Buffer memory area to be Default value Buffer memory area to be (Decimal) monitored (Decimal) monitored CH1 Digital operation value (Un\G402) CH1 Digital operation value (Un\G10) CH2 Digital operation value (Un\G602) CH2 Digital operation value (Un\G11)
  • Page 169 CH1 Offset setting value As Channel change request (Un\G70, b11) is turned off→on→off in offset/gain setting mode, the measured temperature value is corrected by a value written in this area. Specify the value of a 16-bit signed binary number. ■Buffer memory address The following shows the buffer memory address of this area.
  • Page 170 CH1 Gain setting value As Channel change request (Un\G70, b11) is turned off→on→off in offset/gain setting mode, the measured temperature value is corrected by a value written in this area. Specify the value of a 16-bit signed binary number. ■Buffer memory address The following shows the buffer memory address of this area.
  • Page 171 CH1 Input type/range setting This area is for setting an input type and range setting. Setting value (Hexadecimal) Input type Input range 000FH Conversion disable  0003H Current 4 to 20 mA 0010H 0 to 20 mA 0006H -20 to +20 mA 0011H Voltage 1 to 5 V...
  • Page 172 CH1 Input type/range setting [FX2N allocation mode] When the FX2N allocation mode function is used, this area is for setting an input type and range setting. b12 b11 b8 b7 CH1 to 4 input type/range setting (Un\G0) b12 b11 b8 b7 CH5 to 8 input type/range setting (Un\G1) Setting value (Hexadecimal)
  • Page 173 CH1 Input type/range setting (Offset/gain setting) The area is to set the range setting (Offset/gain setting). Setting value Description Factory default setting User range setting Setting a value other than the above causes an input type/range setting range error (error code: 190H). ■Buffer memory address The following shows the buffer memory address of this area.
  • Page 174 Alarm history Up to 16 alarms that occurred in the module are recorded. b8 b7 Un\G3760 Alarm code First two digits of the year Last two digits of the year Un\G3761 Month Un\G3762 Hour Minute Un\G3763 Second Day of the week Un\G3764 Millisecond (higher-order digits) Millisecond (lower-order digits)
  • Page 175 CH1 Offset/gain setting mode Specify the channel where the offset/gain setting is adjusted. • Offset/gain setting mode (offset specification): Channel to adjust the offset • Offset/gain setting mode (gain specification): Channel to adjust the gain Setting value Setting content Disable Setting channel Set one of the offset specification or gain specification to the Setting channel (1), and the other to Disable (0).

  • Page 176: Index

    INDEX ..157 CH1 Rate alarm alert detection cycle setting ... .158 CH1 Rate alarm lower limit value ......20 Accuracy .
  • Page 177 . . 58 Maximum Value/Minimum Value Hold Function ....135 Mode switching setting ..... 122 Module Information .

  • Page 178: Revisions
