MELSEC iQ-R Temperature Control Module
User's Manual (Startup)
-R60TCTRT2TT2
-R60TCTRT2TT2BW
-R60TCRT4
-R60TCRT4BW

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MELSEC iQ-R series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mitsubishi MELSEC iQ-R series

Summary of Contents for Mitsubishi MELSEC iQ-R series

  • Page 1 MELSEC iQ-R Temperature Control Module User's Manual (Startup) -R60TCTRT2TT2 -R60TCTRT2TT2BW -R60TCRT4 -R60TCRT4BW...

  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS (Read these precautions before using this product.) Before using this product, please read this manual and the relevant manuals carefully and pay full attention to safety to handle the product correctly. The precautions given in this manual are concerned with this product only. For the safety precautions of the programmable controller system, refer to the MELSEC iQ-R Module Configuration Manual.
  • Page 4 [Design Precautions] WARNING ● Configure safety circuits external to the programmable controller to ensure that the entire system operates safely even when a fault occurs in the external power supply or the programmable controller. Failure to do so may result in an accident due to an incorrect output or malfunction. (1) Emergency stop circuits, protection circuits, and protective interlock circuits for conflicting operations (such as forward/reverse rotations or upper/lower limit positioning) must be configured external to the programmable controller.
  • Page 5 [Design Precautions] WARNING ● If a communication cable is disconnected, the network may be unstable, resulting in a communication failure of multiple stations. Configure an interlock circuit in the program to ensure that the entire system will always operate safely even if communications fail. Failure to do so may result in an accident due to an incorrect output or malfunction.
  • Page 6 [Installation Precautions] WARNING ● Shut off the external power supply (all phases) used in the system before mounting or removing the module. Failure to do so may result in electric shock or cause the module to fail or malfunction. [Installation Precautions] CAUTION ●...
  • Page 7 [Wiring Precautions] CAUTION ● Individually ground the FG and LG terminals of the programmable controller with a ground resistance of 100 ohms or less. Failure to do so may result in electric shock or malfunction. ● Use applicable solderless terminals and tighten them within the specified torque range. If any spade solderless terminal is used, it may be disconnected when the terminal screw comes loose, resulting in failure.
  • Page 8 [Wiring Precautions] CAUTION ● Individually ground the shielded cables of the programmable controller with a ground resistance of 100 ohms or less. Failure to do so may result in electric shock or malfunction. [Startup and Maintenance Precautions] WARNING ● Do not touch any terminal while power is on. Doing so will cause electric shock or malfunction. ●...
  • Page 9 [Startup and Maintenance Precautions] CAUTION ● When connecting an external device with a CPU module or intelligent function module to modify data of a running programmable controller, configure an interlock circuit in the program to ensure that the entire system will always operate safely. For other forms of control (such as program modification, parameter change, forced output, or operating status change) of a running programmable controller, read the relevant manuals carefully and ensure that the operation is safe before proceeding.
  • Page 10 [Operating Precautions] CAUTION ● When changing data and operating status, and modifying program of the running programmable controller from an external device such as a personal computer connected to an intelligent function module, read relevant manuals carefully and ensure the safety before operation. Incorrect change or modification may cause system malfunction, damage to the machines, or accidents.

  • Page 11: Conditions Of Use For The Product

    Notwithstanding the above, restrictions Mitsubishi may in its sole discretion, authorize use of the PRODUCT in one or more of the Prohibited Applications, provided that the usage of the PRODUCT is limited only for the specific applications agreed to by Mitsubishi and provided further that no special quality assurance or fail-safe, redundant or other safety features which exceed the general specifications of the PRODUCTs are required.

  • Page 12: Introduction

    Before using this product, please read this manual and the relevant manuals carefully and develop familiarity with the functions and performance of the MELSEC iQ-R series programmable controller to handle the product correctly. When applying the program and circuit examples provided in this manual to an actual system, ensure the applicability and confirm that it will not cause system control problems.
  • Page 13 MEMO...

  • Page 14: Table Of Contents

    CONTENTS SAFETY PRECAUTIONS ..............1 CONDITIONS OF USE FOR THE PRODUCT .
  • Page 15 TRADEMARKS ................82...

  • Page 16: Relevant Manuals

    This manual does not include information on the module function blocks. For details, refer to the Function Block Reference for the module used. e-Manual refers to the Mitsubishi FA electronic book manuals that can be browsed using a dedicated tool. e-Manual has the following features: •...

  • Page 17: Terms

    (normal mode), mix control (expanded mode), position proportional control (normal mode), and position proportional control (expanded mode) CPU module The generic term of MELSEC iQ-R series CPU modules Engineering tool The product name of the MELSEC programmable controller software package...

  • Page 18: Chapter 1 Part Names

    PART NAMES This chapter describes the part names of the temperature control module. Name Description RUN LED Indicates the operating status of the temperature control module. On: The module is operating normally. Flashing: The module is selected as a module for the online module change. Off: 5V power off, watchdog timer error occurred, or module replacement is allowed in the process of the online module change ERR LED...
  • Page 19 MEMO 1 PART NAMES...

  • Page 20: Chapter 2 Specifications

    SPECIFICATIONS This chapter describes the performance specifications. Performance Specifications The following table lists the performance specifications of the temperature control module. Item R60TCTRT2TT2 R60TCRT4 R60TCTRT2TT2BW R60TCRT4BW Control output Transistor output Number of temperature input points 4 channels/module Applicable thermocouple/platinum resistance thermometer Refer to the following.
  • Page 21 Item R60TCTRT2TT2 R60TCRT4 R60TCTRT2TT2BW R60TCRT4BW Withstand voltage Between input terminals and programmable controller power supply: 500VAC, 1 minute Between input channels: 500VAC, 1 minute Insulation resistance Between input terminals and programmable controller power supply: 500VDC, 20M or higher Between input channels: 500VDC, 20M or higher ...

  • Page 22: Resistance

    Type of Temperature Sensors, Temperature Measuring Range, Resolution, and Effect from Wiring Resistance This section describes the types of temperature sensors that can be used with the temperature control module, the temperature measuring range, the resolution, and the effect from wiring resistance of 1 Thermocouple The following table lists the types of thermocouples that can be used with the R60TCTRT2TT2 and R60TCTRT2TT2BW, the temperature measuring range, the resolution, and the effect from wiring resistance of 1.
  • Page 23 Platinum resistance thermometer The following table lists the types of platinum resistance thermometers that can be used with the temperature control module and the temperature measuring range.   Platinum resistance thermometer type Temperature measuring Resolution Temperature measuring Resolution range range Pt100 -200.0 to 600.0...

  • Page 24: Chapter 3 Function List

    FUNCTION LIST The following table lists the functions of the temperature control module. For details on each function, refer to the following.  MELSEC iQ-R Temperature Control Module User's Manual (Application) : Available, : Not available Item Description Availability Standard Heating- Position control...
  • Page 25 Item Description Availability Standard Heating- Position control cooling control proportional control    Derivative action selection function This function improves dynamic characteristics by selecting a suitable derivative action for fixed value actions or ramp actions.    Simple two-degree-of-freedom In addition to the PID control, this function selects a suitable response speed for the set value (SV) change from three levels to simply achieve the two-degree-of-...
  • Page 26 Item Description Availability Standard Heating- Position control cooling control proportional control    Inter-module Inter-module This function links multiple modules to suppress the link function peak current peak current by automatically changing the values of suppression the upper limit output limiter of each channel and function dividing the timing of the transistor output.

  • Page 27: Chapter 4 Procedures Before Operation

    PROCEDURES BEFORE OPERATION This chapter describes the procedures before operation. Mounting modules Mount the temperature control module in a desired configuration. Page 27 SYSTEM CONFIGURATION Wiring Wire external devices to the temperature control module. Page 29 INSTALLATION AND WIRING Addition of modules Use an engineering tool to add the temperature control module to the module configuration.
  • Page 28 MEMO 4 PROCEDURES BEFORE OPERATION...

  • Page 29: Chapter 5 System Configuration

    SYSTEM CONFIGURATION Temperature sensor For usable temperature sensors, refer to the following. Page 20 Type of Temperature Sensors, Temperature Measuring Range, Resolution, and Effect from Wiring Resistance Current sensor for heater disconnection detection The following table lists current sensors for heater disconnection detection available with the R60TCTRT2TT2BW or R60TCRT4BW.
  • Page 30 (3): Terminal block converter module for temperature control (4): Thermocouple or compensation conductor Item Model Manufacturer Temperature control dedicated cable with Q FA-CBLQ64TC** (**: Cable length) Your local Mitsubishi Electric sales office or terminal block representative Terminal block converter module for temperature FA-TB20TC control Precautions When using the terminal block converter module for temperature control and the temperature control dedicated cable with Q terminal block, set a thermocouple type for input ranges of all channels.

  • Page 31: Chapter 6 Installation And Wiring

    INSTALLATION AND WIRING This chapter describes the installation and wiring of the temperature control module. Terminal Block Precautions Tighten the terminal block screws within the following specified tightening torque range. Undertightening can cause drop of the screw, short circuit, or malfunction. Overtightening can damage the screw and/or module, resulting in drop, short circuit, or malfunction.
  • Page 32 Signal names of terminal blocks ■R60TCTRT2TT2 and R60TCTRT2TT2BW (Terminal block for I/O) • Standard control, heating-cooling control (normal mode), mix control (normal mode), and position proportional control (normal mode) Terminal Standard control Heating-cooling control Mix control (normal mode) Position proportional (normal mode) control (normal mode) Symbol...
  • Page 33 Terminal Standard control Heating-cooling control Mix control (normal mode) Position proportional (normal mode) control (normal mode) Symbol Name Symbol Name Symbol Name Symbol Name CH2-/ CH2 Thermocouple -/ CH2-/ CH2 Thermocouple -/ MT2-/ Monitor 2 CH2-/ CH2 Thermocouple -/ CH2b CH2 Resistance CH2b CH2 Resistance...
  • Page 34 • Heating-cooling control (expanded mode), mix control (expanded mode), and position proportional control (expanded mode) Terminal Heating-cooling control (expanded Mix control (expanded mode) Position proportional control mode) (expanded mode) Symbol Name Symbol Name Symbol Name CH1 Heating output CH1 Heating output CH1 Open output OPEN CH1 Cooling output...
  • Page 35 ■R60TCRT4 and R60TCRT4BW (Terminal block for I/O) • Standard control, heating-cooling control (normal mode), mix control (normal mode), and position proportional control (normal mode) Terminal Standard control Heating-cooling control Mix control (normal mode) Position proportional (normal mode) control (normal mode) Symbol Name Symbol...
  • Page 36 Terminal Standard control Heating-cooling control Mix control (normal mode) Position proportional (normal mode) control (normal mode) Symbol Name Symbol Name Symbol Name Symbol Name CH3B CH3 Resistance MT3B Monitor 3 resistance CH3B CH3 Resistance MT3B Monitor 3 resistance thermometer B thermometer B thermometer B thermometer B...
  • Page 37 • Heating-cooling control (expanded mode), mix control (expanded mode), and position proportional control (expanded mode) Terminal Heating-cooling control (expanded Mix control (expanded mode) Position proportional control mode) (expanded mode) Symbol Name Symbol Name Symbol Name CH1 Heating output CH1 Heating output CH1 Open output OPEN CH1 Cooling output...
  • Page 38 ■R60TCTRT2TT2BW (for CT input) and R60TCRT4BW (for CT input) Terminal No. Standard control and heating-cooling control Symbol Name Not used CT input 1 CT input 1 CT input 2 CT input 2 CT input 3 CT input 3 CT input 4 CT input 4 CT input 5 CT input 5...

  • Page 39: Wiring Precautions

    Wiring Precautions External wiring that is less likely to be affected by noise is one of the conditions for a highly reliable system that fully utilizes the temperature control module. This section describes wiring precautions. • Use separate cables for the AC control circuit and the temperature control module's external I/O signals to avoid influence of AC side surges and induction.

  • Page 40: External Wiring

    External Wiring The following figure shows the external wiring. R60TCTRT2TT2 Standard control R60TCTRT2TT2 Internal circuit · · Internal circuit COM- 24VDC Controlled Filter CH1+ object CH1- Internal Filter circuit · CH2+ CH2- Filter CH4+ CH4- *1 Use the shielded compensation lead wire. *2 Use the shielded cable.
  • Page 41 Heating-cooling control R60TCTRT2TT2 Internal circuit Internal circuit Internal circuit Internal circuit COM- 24VDC Heating Cooling Controlled object Filter CH1+ CH1- Internal circuit Filter CH2+ CH2- *1 Use the shielded compensation lead wire. *2 Use the shielded cable. Use the compensation lead wire for the cable of a thermocouple. The shielded cable cannot be used. If the compensation lead wire is not used, and when the cold junction temperature compensation resistor (1) is away from the end tip (2) of a thermocouple, the (ambient) temperature (3) difference may lead to a faulty temperature process value (PV).
  • Page 42 Position proportional control Positioner R60TCTRT2TT2 Internal OPEN circuit CLOSE · Control motor OPEN Internal power supply CLOSE circuit COM- OUT1 OUT2 24VDC (CH1 open side) (CH1 close side) Filter CH1+ CH1- Internal Filter CH2+ circuit CH2- Control motor Filter Fluid CH4+ Controlled CH4-...

  • Page 43: R60Tctrt2Tt2Bw

    R60TCTRT2TT2BW Standard control R60TCTRT2TT2BW Internal circuit · · Internal circuit COM- Current sensor 24VDC (CT) Controlled Filter CH1+ object CH1- Internal Filter circuit CH2+ · CH2- Filter CH4+ CH4- Connector Connector CT input circuit *1 Use the shielded compensation lead wire. *2 Use the shielded cable.
  • Page 44 Heating-cooling control R60TCTRT2TT2BW Internal circuit Internal circuit Internal circuit Internal circuit Current sensor COM- (CT) Cooling 24VDC Controlled Filter object CH1+ CH1- Heating Internal circuit Filter CH2+ CH2- Connector Connector CT input circuit *1 Use the shielded compensation lead wire. *2 Use the shielded cable.
  • Page 45 Position proportional control The CT input is invalid in the position proportional control. For wiring examples, refer to the following. Page 40 Position proportional control 6 INSTALLATION AND WIRING 6.3 External Wiring...

  • Page 46: R60Tcrt4

    R60TCRT4 Standard control R60TCRT4 Internal circuit · · Internal circuit COM- 24VDC Filter CH1 A CH1 B CH1 b Controlled Internal Filter object circuit CH2 A · CH2 B CH2 b Filter CH4 A CH4 B CH4 b *1 Use the shielded cable. 6 INSTALLATION AND WIRING 6.3 External Wiring...
  • Page 47 Heating-cooling control R60TCRT4 Internal circuit Internal circuit Internal circuit Internal circuit COM- 24VDC Heating Cooling Filter CH1 A CH1 B Internal CH1 b circuit Controlled object Filter CH2 A CH2 B CH2 b *1 Use the shielded cable. Position proportional control Positioner R60TCRT4 Internal...

  • Page 48: R60Tcrt4Bw

    R60TCRT4BW Standard control R60TCRT4BW Internal circuit · · Internal circuit COM- Current sensor (CT) 24VDC Filter CH1 A CH1 B CH1 b Controlled Internal object Filter circuit CH2 A · CH2 B CH2 b Filter CH4 A CH4 B CH4 b Connector Connector CT input circuit...
  • Page 49 Heating-cooling control R60TCRT4BW Internal circuit Internal circuit Internal circuit Internal circuit COM- Current sensor 24VDC (CT) Cooling CH1 A Filter Internal CH1 B Heating circuit CH1 b Controlled objectd CH2 A Filter CH2 B CH2 b Connector Connector CT input circuit *1 Use the shielded cable.

  • Page 50: Heater Disconnection Detection Wiring And Setting Example For Three-Phase Heater

    Heater Disconnection Detection Wiring and Setting Example for Three-phase Heater The following shows the wiring and setting examples to detect a disconnection of a three-phase heater with the heater disconnection detection function. R60TCTRT2TT2BW R60TCRT4BW COM- Controlled object The disconnection of the three-phase heater is detected by measuring the currents of two of the three cables. In the above wiring example, set "CT input channel assignment setting"...

  • Page 51: Unused Channel Setting

    Unused Channel Setting When no temperature sensor is connected to a channel, the temperature control module performs upscale processing for the channel. Therefore, when no temperature sensor has not been connected to a channel where no temperature control is to be performed, the module determines that the temperature process value (PV) has exceeded the temperature measuring range for the input range, and the ALM LED blinks.
  • Page 52 MEMO 6 INSTALLATION AND WIRING 6.5 Unused Channel Setting...

  • Page 53: Chapter 7 Operation Examples

    OPERATION EXAMPLES This chapter describes the programming procedure and basic program of the temperature control module. Programming Procedure Create a program that operates the temperature control module using the following procedure. Set parameters. Create a program. Using function blocks (FBs) can reduce the load at programming and improve the readability of a program. For details on the function blocks, refer to the following.
  • Page 54 Parameter settings Connect an engineering tool to the CPU module and set parameters. In these program examples, use the default setting for the parameters other than the set parameters. For parameters, refer to the following.  MELSEC iQ-R Temperature Control Module User's Manual (Application) ■Setting modules Set the CPU module as follows.
  • Page 55 Click the [OK] button and add labels of the R60TCTRT2TT2. ■Setting parameters of the temperature control module Configure the settings in "Base Setting" as follows. [Navigation window]  [Parameter]  [Module Information]  [R60TCTRT2TT2]  [Module Parameter]  [Base Setting] 7 OPERATION EXAMPLES 7.2 Program Examples...
  • Page 56 Configure the settings in "Application Setting" as follows. [Navigation window]  [Parameter]  [Module Information]  [R60TCTRT2TT2]  [Module Parameter]  [Application Setting] • "Control basic parameters" Set "Target Value(SV) Setting" of CH1 and "Unused channel setting" of CH2 to CH4 as shown below. •...
  • Page 57 Auto tuning Perform auto tuning. [Tool]  [Module Tool List] Select "Temperature trace" of "Temperature Control Module" and click the [OK] button. Select the module to configure the temperature control setting and click the [OK] button. Select "Monitor data write" from the following. [Setting] ...
  • Page 58 Setting labels GX Works3 has functions supporting program creation. The following table lists the module labels and global labels used in these program examples. Do not change the settings of the module labels. For details on global labels, refer to the following. ...
  • Page 59 Program examples ■Program that changes the setting/operation mode ■Program that processes data when the upper limit input alert occurs ■Program that displays and clears an error code 7 OPERATION EXAMPLES 7.2 Program Examples...

  • Page 60: Standard Control (When Using The Inter-Module Simultaneous Temperature Rise Function)

    Standard control (When using the inter-module simultaneous temperature rise function) System configuration The following shows a system configuration example. (1) Power supply module (R61P) (2) CPU module (R120CPU) (3) Temperature control module 1 (R60TCTRT2TT2) (4) Temperature control module 2 (R60TCTRT2TT2) (5) Input module (RX10) Parameter settings Connect an engineering tool to the CPU module and set parameters.
  • Page 61 ■Setting parameters of the temperature control module 1 Configure the settings in "Base Setting" as follows. [Navigation window]  [Parameter]  [Module Information]  [R60TCTRT2TT2]  [Module Parameter]  [Base Setting] • "Multiple module interaction function" Set "Simultaneous temperature rise function enable/disable between multiple module" and "Simultaneous temperature rise function master/slave selection between multiple module"...
  • Page 62 Configure the settings in "Application Setting" as follows. [Navigation window]  [Parameter]  [Module Information]  [R60TCTRT2TT2]  [Module Parameter]  [Application Setting] • "Control basic parameters" Set "Target Value(SV) Setting" of CH1 and CH2, and "Unused channel setting" of CH3 and CH4 as shown below. •...
  • Page 63 ■Setting parameters of the temperature control module 2 Configure the settings in "Base Setting" as follows. [Navigation window]  [Parameter]  [Module Information]  [R60TCTRT2TT2]  [Module Parameter]  [Base Setting] • "Multiple module interaction function" Set "Simultaneous temperature rise function enable/disable between multiple module" as shown below. 7 OPERATION EXAMPLES 7.2 Program Examples...
  • Page 64 Configure the settings in "Application Setting" as follows. [Navigation window]  [Parameter]  [Module Information]  [R60TCTRT2TT2]  [Module Parameter]  [Application Setting] • "Control basic parameters" Set "Target Value(SV) Setting" of CH1 and CH2, and "Unused channel setting" of CH3 and CH4 as shown below. •...
  • Page 65 Setting labels GX Works3 has functions supporting program creation. The following table lists the module labels and global labels used in these program examples. Do not change the settings of the module labels. For details on global labels, refer to the following. ...

  • Page 66: Standard Control (When Using The Inter-Module Peak Current Suppression Function)

    Standard control (When using the inter-module peak current suppression function) System configuration The following shows a system configuration example. (1) Power supply module (R61P) (2) CPU module (R120CPU) (3) Temperature control module 1 (R60TCTRT2TT2) (4) Temperature control module 2 (R60TCTRT2TT2) (5) Input module (RX10) Parameter settings Connect an engineering tool to the CPU module and set parameters.
  • Page 67 ■Setting parameters of the temperature control module 1 Configure the settings in "Base Setting" as follows. [Navigation window]  [Parameter]  [Module Information]  [R60TCTRT2TT2]  [Module Parameter]  [Base Setting] • "Multiple module interaction function" Set "Peak current suppression function enable/disable between multiple module" and "Peak current suppression function master/slave selection between multiple module"...
  • Page 68 Configure the settings in "Application Setting" as follows. [Navigation window]  [Parameter]  [Module Information]  [R60TCTRT2TT2]  [Module Parameter]  [Application Setting] • "Control basic parameters" Set "Target Value(SV) Setting" of CH1 and CH2, and "Unused channel setting" of CH3 and CH4 as shown below. •...
  • Page 69 ■Setting parameters of the temperature control module 2 Configure the settings in "Base Setting" as follows. [Navigation window]  [Parameter]  [Module Information]  [R60TCTRT2TT2]  [Module Parameter]  [Base Setting] • "Multiple module interaction function" Set "Peak current suppression function enable/disable between multiple module" as shown below. 7 OPERATION EXAMPLES 7.2 Program Examples...
  • Page 70 Configure the settings in "Application Setting" as follows. [Navigation window]  [Parameter]  [Module Information]  [R60TCTRT2TT2]  [Module Parameter]  [Application Setting] • "Control basic parameters" Set "Target Value(SV) Setting" of CH1 and CH2, and "Unused channel setting" of CH3 and CH4 as shown below. •...
  • Page 71 Setting labels GX Works3 has functions supporting program creation. The following table lists the module labels and global labels used in these program examples. Do not change the settings of the module labels. For details on global labels, refer to the following. ...

  • Page 72: Heating-Cooling Control

    Heating-cooling control System configuration The following shows a system configuration example. (1) Power supply module (R61P) (2) CPU module (R120CPU) (3) Temperature control module (R60TCTRT2TT2) (4) Input module (RX10) Parameter settings Connect an engineering tool to the CPU module and set parameters. In these program examples, use the default setting for the parameters other than the set parameters.
  • Page 73 ■Setting parameters of the temperature control module Configure the settings in "Base Setting" as follows. [Navigation window]  [Parameter]  [Module Information]  [R60TCTRT2TT2]  [Module Parameter]  [Base Setting] • "Control mode selection" Set "Control mode selection" as shown below. 7 OPERATION EXAMPLES 7.2 Program Examples...
  • Page 74 Configure the settings in "Application Setting" as follows. [Navigation window]  [Parameter]  [Module Information]  [R60TCTRT2TT2]  [Module Parameter]  [Application Setting] • "Control basic parameters" Set "Target Value(SV) Setting" of CH1 and "Unused channel setting" of CH2 as shown below. •...

  • Page 75: Position Proportional Control

    Position proportional control System configuration The following shows a system configuration example. (1) Power supply module (R61P) (2) CPU module (R120CPU) (3) Temperature control module (R60TCTRT2TT2) (4) Input module (RX10) Parameter settings Connect an engineering tool to the CPU module and set parameters. In these program examples, use the default setting for the parameters other than the set parameters.
  • Page 76 ■Setting parameters of the temperature control module Configure the settings in "Base Setting" as follows. [Navigation window]  [Parameter]  [Module Information]  [R60TCTRT2TT2]  [Module Parameter]  [Base Setting] • "Control mode selection" Set "Control mode selection" as shown below. 7 OPERATION EXAMPLES 7.2 Program Examples...
  • Page 77 Configure the settings in "Application Setting" as follows. [Navigation window]  [Parameter]  [Module Information]  [R60TCTRT2TT2]  [Module Parameter]  [Application Setting] • "Control basic parameters" Set "Target Value(SV) Setting" of CH1 and "Unused channel setting" of CH2 as shown below. •...

  • Page 78: Appendix

    APPENDIX Appendix 1 External Dimensions The following shows the external dimensions of the temperature control module. R60TCTRT2TT2, R60TCRT4 27.8 (unit: mm) R60TCTRT2TT2BW, R60TCRT4BW (unit: mm) APPENDIX Appendix 1 External Dimensions...
  • Page 79 MEMO APPENDIX Appendix 1 External Dimensions...

  • Page 80: Index

    INDEX ......18 ......18 Accuracy Output signal .
  • Page 81 MEMO...

  • Page 82: Revisions

    Japanese manual number SH-081533-B This manual confers no industrial property rights of any other kind, nor does it confer any patent licenses. Mitsubishi Electric Corporation cannot be held responsible for any problems involving industrial property rights which may occur as a result of using the contents noted in this manual.

  • Page 83: Warranty

    6. Failure caused by reasons unpredictable by scientific technology standards at time of shipment from Mitsubishi. 7. Any other failure found not to be the responsibility of Mitsubishi or that admitted not to be so by the user. 2. Onerous repair term after discontinuation of production (1) Mitsubishi shall accept onerous product repairs for seven (7) years after production of the product is discontinued.
  • Page 84 TRADEMARKS The company names, system names and product names mentioned in this manual are either registered trademarks or trademarks of their respective companies.   In some cases, trademark symbols such as ' ' or ' ' are not specified in this manual. SH(NA)-081535ENG-C...
