Please file and use this manual together with service manual for Model No. CU-2E18SBU, CU-3E19RBU, CU-4E24RBU, CU-5E36QBU
Order No. PAPAMY1604017CE, PAPAMY1505100CE, PAPAMY1312037CE.
This service information is designed for experienced repair technicians only and is not designed for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to service
or repair the products dealt with in this service information by anyone else could result in serious injury or death.
In order to avoid frostbite, be assured of no refrigerant leakage during the installation or repairing of refrigerant circuit.
